AJ Enjoy AJ1182 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

SKU No.: AJ1182
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage,personal injury,or loss of life.
WARNING
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Refer to the owner's information manual provided with this appliance.
For assistance or additional information consult a qualified installer, services agency or
the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
Owner's Manual
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
•
Extinguish any open flame.
•
If odor continues, leave the area immediately.
•
•
After leaving the area, call your gas supplier
or fire department.
Failure to follow these instructions could
result in fire or explosion, which could cause
property damage, personal injury, or death.
WARNING
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance. An LP-cylinder not connected
for use shall not be stored in the vicinity of
this or any other appliance.
WARNING
Installation and service must be performed
by a qualified installer, service agency,
or the gas supplier.
For outdoor use only.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AJ1182 and is the answer not in the manual?

Questions and answers

Related Manuals for AJ Enjoy AJ1182

Summary of Contents for AJ Enjoy AJ1182

  • Page 1 Owner’s Manual SKU No.: AJ1182 DANGER FIRE OR EXPLOSION HAZARD If you smell gas: Shut off gas to the appliance. • Extinguish any open flame. • If odor continues, leave the area immediately. • • After leaving the area, call your gas supplier or fire department.

  • Page 2: Safety Information

    SAFETY INFORMATION Before you assemble or operate this unit, please carefully read this entire manual. Failure to do so WARNING • The installation of this unit must adhere to local codes or Propane Storage and Handling Code, CSA B149.2. • THIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used outdoors, in a ventilated space and shall not be used in any enclosed area.
  • Page 3 SAFETY INFORMATION • Combustible material should not be within 60 inches of the top of the unit, or within 48 inches around the entire unit. • Keep the appliance area clear and free fr vapors and liquids. • • Do not add water into the unit. •...
  • Page 4 SAFETY INFORMATION Only use the regulator and hose assembly provided with this unit. Replacement parts must be supplied directly by supplier. Inspect the burner before use of this unit. If the burner shows any kind of damage, do not operate the appliance.

  • Page 5: Parts List

    PARTS LIST （ ）...
  • Page 6 ASSEMBLY INSTRUCTIONS Item Description Table Top Door Panel with legs Panel Panel with legs Metal Stand Cross Tube Item Description M6 x 10 Screw M8 x 10 Hexagons Screw M6 x 40 Hexagons Screw Adujstable pad Screwdriver Washer Wrench...
  • Page 7 ASSEMBLY INSTRUCTIONS Do not lock the screws until the assembly is complete. 1. Check that the control knob (10) for the gas supply system is turned to the “OFF” position before starting any assembly. 2 . Attach 4 pcs adjustable pads(DD) to the legs. 3.Attach 4pcs panel together by using 8pcs screws(AA)
  • Page 8 4.Put the metal stand(G) on the base tube of side panels then attach it to the legs by using 2pcs screws(CC) 5.Attach the door panel(C) to the metal stand(G) and cross tube(H) 6. Attach the corss tube(H) to the legs by using 4pcs screw(AA)
  • Page 9 7.Attach the assembled base to table top by using 4pcs screws(BB) 8.Pour the box of lava rock into the fire bowl then put the lid in place. Place propane gas tank (not included) into the metal stand (J) . Make sure the gas tank sits on the metal stand completely.
  • Page 10 Ignition Instructions Remove the rubber cap on the electronic igniter by unscrewing and slide battery into the battery slot.Make sure the positive side of the battery faces outwards. Screw the electronic igniter cap over the battery tightly. WARNING WARNING Do Not Cover the Ignition Screen when placing the rocks into the fire bowl.

  • Page 11: Operation

    OPERATION To Extinguish 1. Turn control knob clockwise to the “HIGH” position; let the knob pop up and continue turning the control knob to the “OFF” position. 2. Close the cylinder valve on the propane gas tank if you don’t intend to use it for a long time. MAINTENANCE Before performing any maintenance always disconnect propane gas tank.

  • Page 12: Troubleshooting

    TROUBLESHOOTING Problem: Burner will not light using igniter Possible Cause 4: Residue on Igniter Pin. Problem: Burner will not light with match Problem: Sudden drop in gas flow Venturi Problem: Irregular flame pattern Problem: The fire table emits a lot of black smoke when in use...
  • Page 13 Problem: Sudden drop in gas flow, or a reduced flame height Problem: Irregular flame pattern, flame does not run the full length of the burner Problem: Flame blow out Problem: Sudden drop in gas flow Problem: Flame seems to lose heat when burning in cold weather - temperature below 50°F vaporization process is too low.
