- Page 1 HOW TO Install fold down seat on Handi-lift 7...
-
Page 2: Table Of Contents
Handi-lift 7 Table of contents Introduction Preparation. 2.1 Parts 2.2 Tools Step by step 3.1 Install the bracket 3.2 Make holes in the front cover 3.3 Install the fold down seat © 2017 Side 2... -
Page 3: Introduction
Handi-lift 7 1 Introduction If you for some reason must install a fold down seat on the unit after installation, the description below is explaining how you must carry this operation out. 2 Preparation. Before you install the fold down seat please read these instructions carefully. Check that you have all the necessary parts and tools to install the seat. -
Page 4: Parts
Handi-lift 7 2.1 Parts Fold down seat Mounting bracket 3 M8x16 bolts and nuts 4 x M6x20 cover screw 2 x M8 bolts (not incl.) (not incl.) Part no 0-0000-04 2.2 Tools Drilling machine 5 mm allen key 4 mm allen key... -
Page 5: Step By Step
Handi-lift 7 3 Step by step 3.1 Install the bracket Open the lift and remove the front cover from the lift. Mount the bracket on the lift frame with the 3 M8x16 bolts and nuts. © 2017 Side 5... -
Page 6: Make Holes In The
Handi-lift 7 3.2 Make holes in the front cover Now you need to mark the 2 holes in the front cover. We suggest that you screw 2 M8 bolts (e.g. part no 0-0000-04) in the bracket and place the front cover on the lift. -
Page 7: Install The Fold Down Seat
Install the front cover and the fold down seat. Please make sure that a warning sign is on the fold down seat, if not contact CAMA Lift in Denmark. If it is possible instruct the owner/user how to operate the fold down seat.
