- Page 1 INSTALLATION MANUAL FOR HANDI-LIFT 7...
-
Page 2: Table Of Contents
Install the rails Column installation: Upper and lower rail installation: Installing the lift unit Place the lift unit on the rail: Connect the electrical: Load cell adjustment: Handicap symbol Installation Test Certificate Cama Lifts © 2010 Page 1 Version 1.0... -
Page 3: Introduction
Handi-lift 7 1 Introduction 1.1 Check the parts and drawing: Before you start installing please read this installation manual. Check the received parts for transport damage. Next, study carefully the installation drawing that comes with the lift to ensure that all angels and dimensions are correct and all dimensions are there. -
Page 4: Forces On The Building
Handi-lift 7 2 Forces on the building Wall Mounted Rail 1. The top (Main) rail fixings are M10x160mm studs & 'Rawl' R-KF2 Kemfast Resin into the wall. 2. The Lower rail fixings must be made using No.12x75mm csk screws & rawlplugs. -
Page 5: Install The Rails
Handi-lift 7 3 Install the rails 3.1 Column installation: If the Handi-Lift is installed on columns you have to start with them. Place the columns after the measurements on the drawing they are usually numbered with the lowest number at the foot of the stairs. - Page 6 Handi-lift 7 Mark measurement B Mark measurement C from the first and last raise parallel with the staircase. Note! Measurement C is the upper edge of the inner profile. Make a line through mark A-A and D. And make a line through mark C-C.
- Page 7 Handi-lift 7 Note! For wall installation we recommend that you use M10 glue bolts for the upper rail when mounted on a wall with the threaded rod minimum 90mm into the wall. And for the lower rail, we minimum recommend ø10 raw plugs with M8x70mm screws.
- Page 8 Handi-lift 7 Install and tighten the support rail for the lower rail fig. 10 Install the aluminium rail on the support rail using the M5x10mm countersunk screws. fig. 11 After letting the glue set for a half-hour in 20 you can tighten the nuts on the glue bolts.
-
Page 9: Installing The Lift Unit
Handi-lift 7 4 Installing the lift unit 4.1 Place the lift unit on the rail: Hand wind platform in it’s down position and remove the front cover from the lift unit. Install the loose carrying arms © 2010 Page 8... - Page 10 Handi-lift 7 Please use tape to protect the rail. Optional: To make the lift easier to handle you can disassemble the platform, if necessary. We recommend you install the lift with the platform assembled. Before inserting the lift to the rail make sure that the upper limit switch is removed.
- Page 11 Handi-lift 7 fig. 16 fig. 17 fig. 18 Plug the remote lead into the control board. Drive the lift to the lowest part of the rail and commence the programming operation. Dismount the carrying arms and install the barrier arms to the unit.
-
Page 12: Connect The Electrical
Handi-lift 7 4.2 Connect the electrical: Wire all required charging points to the upper rail section ensuring that all cables are free from any damage. Charging points are placed at all the lifts stops and wires are connected. Wire back to charging unit and electrical test operation. -
Page 13: Installation Test Certificate Cama Lifts
Rated load: ____________ kg Stairlift serial no: ______________________ Rated speed: ___________ m/s Type and year of manufacturer: _________________________ Manufacturer: CAMA Lift ApS, Ellehammervej 6, DK 9900 Frederikshavn Contract electrical supply: _________ V _________ Phase _________ Hz Mains supply fuse rating: _________ A √... - Page 14 Handi-lift 7 Verify that the polarity of the mains supply connection is correct Test to verify the functional operation of the overspeed detection device and safety gear Verify that the mechanism for emergency/manual operates correctly The alarm device when activated operates correctly All notices, etc.
