- Page 1 USER'S GUIDE 83V5 SERIES 220-240V Thank You Safety Instructions Product View Assembly Operations 7-14 Maintenance and Care Troubleshooting 16-17 Replacement Parts Accessories and Formulas Warranty Consumer Care...
- Page 2 Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. Your BISSELL Healthy Home ProHeat deep cleaner is well made, and we back it with a limited two year warranty. We also stand behind it with a knowledgeable, dedicated Consumer Care department, so, should you ever have a problem, you’ll receive fast, considerate assistance.
-
Page 3: Important Safety Instructions
■ moistened by cleaning process Use only cleaning products formulated ■ by BISSELL for use in this appliance to Do not leave machine when it is plugged in ■ prevent internal component damage Do not service machine when it is plugged in ■... -
Page 4: Product View
roduct view Ergonomically Designed Handle Handle Assembly Heat Indicator Heater Switch: Light/Built-in Turn heat on or off Hot Water Heater as needed Lower Body Assembly Integrated Carry Handle ReadyTools Dial ™ Belt Access Door Removable Nozzle DirtLifter ™ EdgeSweep Brushes PowerBrush ™... -
Page 5: Cleaning Formula
Maneuver Wheels Cleaning formula: Keep plenty of genuine BISSELL 2X cleaning formula on hand so you can clean and protect whenever it fits your schedule. Always use genuine BISSELL cleaning formulas. Non-BISSELL cleaning formulas may harm the machine and will void the warranty. - Page 6 ssembly Your Healthy Home ProHeat deep WARNING: cleaner comes in four easy to assemble components: Do not plug in your cleaner • Handle assembly until you have completely • Upper hose rack assembled it per the • Lower body assembly instructions and are familiar • Lower hose rack with all instructions and operating procedures.
- Page 7 Heater Switch WARNING: To reduce the risk of fire, use only BISSELL advanced cleaning formula for full size machines in your deep cleaner. Use of cleaning formulas that contain lemon or pine oil may damage this appliance and void the warranty.
-
Page 8: Measuring Cup
To help restore this important protection, only BISSELL offers cleaning formulas with Scotchgard protector. This offers extra protection against dirt and tough stains to keep your carpets looking good longer. -
Page 9: Before You Clean
A. Using the BISSELL Tough Stain Precleaner, generously spray evenly over soiled area, do not overwet. B. Wait 3-5 minutes before deep cleaning. C. Clean as normal using your BISSELL deep cleaner. ATTENTION: Some Berber carpets have a tendency to fuzz with wear. - Page 10 perations Fill the 2-in-1 water tank 1. Remove the tank from the base of the machine by lifting the tank carry handle. 2. Carry like a bucket to the sink. Rotate the handle forward to unlatch the lid. Remove lid, turn over and locate built in measuring cup.
-
Page 11: Carpet Cleaning
3. While pressing the spray trigger, make one slow forward wet pass and another Heater Switch back. Let the built-in heater, BISSELL advanced deep cleaning formula and DirtLifter PowerBrush do the work for you. Caution: Do not overwet. - Page 12 perations Empty the 2-in-1 water tank/clean removable nozzle 1. Turn power switch off. Remove the 2-in-1 water tank from the base using the tank carry handle. Carry the tank like a bucket to a utility sink or outside where you will dispose of the collection water. Remove the top of the tank by rotating the handle for- ward to unlatch lid and lifting lid off tank.
- Page 13 perations ReadyTools™ continued 5. Vacuum thoroughly to pick up loose debris and pet hair. Use a vacuum with a brush attachment and a crevice tool to clean in fabric folds and tufts. 6. To begin cleaning with attachments, follow the instructions on page 10 for filling the 2-in-1 water tank.
-
Page 14: Hard Floor Cleaning
2-in-1 water tank. 2. Fill BISSELL Hard Floor Solutions to the indicated fill line in the built in measuring cup and pour into mouth of bladder. 3. Fill the bladder with clean hand hot tap water and set aside. -
Page 15: Maintenance And Care
aintenance and care Machine care For best results, a few simple steps can assure your machine is well maintained after cleaning is complete. 1. Turn power switch off. Unplug the machine and wrap the power cord. 2 . After emptying the 2-in-1 water tank, rinse it with running hand hot tap water, tak- ing care to clean underneath and around the heavy duty bladder. -
Page 16: Troubleshooting
If it is broken or missing, please refer to Replacement Parts on page 18. A replacement belt may be ordered by calling BISSELL Consumer Services Complete installation instructions will accompany the replacement belt. B. When replacing belt access door be sure to line up slots of belt access door with slots in machine, slide door into place and snap shut. - Page 17 7. The lint screen may be clogged. 7. Clean out lint screen. Refer to page 12. Other maintenance or service not included in the manual should be performed by an authorized service representative. Thank you for selecting a BISSELL product. Please do not return this product to the store. w w w . b i s s e l l . c o m...
-
Page 18: Replacement Parts
eplacement parts Item Part No. Part Name 203-0104 Tank Assembly Complete 203-0102 Tank Base 203-0124 Removable Nozzle 215-0628 Replacement Pump Belt (with instructions) 015-0621 Replacement Brush Belt (with instructions) 203-0105 Lint Screen ccessories Item Part No. Part Name 203-0149 Hard Floor Tool 203-6651 3"... - Page 19 User's Guide is not covered. BISSELL recommends that the original packaging be kept for the duration of the warranty period in case such need arises within the warranty period that the item need re-packing and transportation.
- Page 20 ISSELL consumer care If your BISSELL product should require service: Call BISSELL Consumer Care at the numbers below and we will give you the location of a BISSELL Authorized Service Center in your area. If you have questions about your warranty or need replacement parts please contact the numbers below.
