- Page 1 U S E R ’ S G U I D E 16N5 SERIES Safety Instructions Product View Assembly 6-9 Operation 10-15 Maintenance and Care 16-17 Troubleshooting 18 Consumer Services 19 Replacement Parts and Accessories 20 Warranty...
- Page 2 BISSELL Healthy Home Vacuum ™ We’re glad you purchased a BISSELL vacuum. Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. By purchasing this product you are helping BISSELL with our commitment to reducing our impact on the environment through an expanding range of sustainable design efforts.
-
Page 3: Important Safety Instructions
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord. D o not handle vacuum cleaner or plug with wet hands. D o not put any object into openings. Do not use with any opening blocked;... -
Page 4: Product View
roduct view TurboBrush Release Button Screen Dirt Container AireTight HEPA Filter Headlight Height Adjustment Dial Furniture Protection Brush Guard w w w . b i s s e l l . c a Fingertip Power Control Fingertip Brush On/Off Carrying Handle Long Reach Hose Quick Release... - Page 5 . b i s s e l l . c a caUTIoN: Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures. 1 - 8 0 0 - 2 6 3 - 2 5 3 5...
-
Page 6: Operation
Handle positions Use your foot to pull the handle release pedal back to recline the vacuum cleaner. Height adjustment There are seven height settings available for various floor surfaces. Turn the dial on the foot of the cleaner to the desired setting. - Page 7 Microban provides continuous antimicrobial product protection for the useful lifetime of the product keeping your vacuum cleaner and fresher. Note: This should not replace normal cleaning and maintenance procedures. Microban is a registered trademark of Microban products company.
-
Page 8: Crevice Tool
peration Using the tools Make sure the cleaner is in the upright position. Remove the hose wand from the wand base. This automatically diverts the suction to the hose. Unwrap the hose from the cleaner. Use the hose and wand alone or attach any of the tools to the end of the hose wand. TurboBrush Use rotating brush action for small areas such as stairs and upholstery. Note: press gently when using the Turbobrush to gain maximum cleaning. Too much pressure could cause the brush to stop rotating. -
Page 9: Emptying The Dirt Container
. b i s s e l l . c a caUTIoN: Make sure vacuum cleaner has been switched off and unplugged before removing dirt container. 1 - 8 0 0 - 2 6 3 - 2 5 3 5... -
Page 10: Cleaning The Pre-Motor Filter
aintenance and care Cleaning the dirt container additional steps can be taken to clean the dirt container as necessary. 1. Ensure the dirt container has been emptied. 2. Remove the lower portion by pressing the front latch on the upper portion as shown. 3. Clean the screen with a cloth or soft brush to remove dust or debris. 4. If desired, the lower dirt container may be washed in warm water. Make sure it is completely dry before reassembling. Do not put in dishwasher. 5. To reassemble, hold the carry handle and place the upper portion into the lower portion, lining up the front and back latches. Push down until both latches click into place. Make sure the dirt container is securely assembled before replacing it on machine. - Page 11 More or less frequent replacing may be required based on individual vacuuming habits and types of debris picked up. Note: To have the benefits of the airetight hEpa System, you must use the bISSEll hEpa filter cartridge. Remove the dirt container. To remove the HEPA filter cartridge, push in on the front of the filter door to unlatch. Lift up to access. To check or remove, unscrew the center screw.
-
Page 12: Clearing Clogs
If you notice a change in the sound of the motor or a reduction in the spinning action in the dirt container, check for a clog. -
Page 13: Thermal Motor Protection
Fix the problem by following the steps in the maintenance section of the user guide. When the motor cools for approximately 30 minutes, the thermal protector automatically resets and cleaning may continue. If the cleaner will not turn on or the thermal protector continues to activate, your cleaner may need servicing. Call BISSELL Consumer Services or visit the website to locate an authorized Service Center. Note: The thermal protector controls the main vacuum motor only, not the brush motor. If the thermal protector activates, the brush will continue to operate normally; however, there will be no suction. -
Page 14: Brush Maintenance
Do not attempt to disassemble the vacuum foot or to remove the brush roll. If you feel it needs to be checked or replaced, call bISSEll consumer Services or visit the website to locate an authorized service center. Belt maintenance... -
Page 15: Changing The Light Bulb
aintenance and care Changing the light bulb 1. Turn power switch off. 2. Unplug cleaner from electrical outlet. 3. Recline handle for easier access to light bulb and remove 2 screws to lift off lens. 4. Remove the bulb by grasping bulb and pull- ing straight out of the socket. Install the new bulb by pushing gently into the socket until the bulb snaps into place. TurboBrush maintenance The Turbobrush should be checked regularly for clogs or debris wrapping around the brush. 1. Remove tool from hose or front of vacuum. 2. Twist collar so opening is at the top and lift top cover to remove. 3. Remove the brush from the belt and clean debris. -
Page 16: Troubleshooting
4. Handle not fully attached brush not rotating possible causes 1. Brush switch turned to “Off” 2. Vacuum is in upright position 3. Brush is jammed 4. Brush needs to be reset 5. Handle not fully attached Vacuum cleaner won’t pick up or low suction possible causes 1. Incorrect height setting 2. Hose wand not properly positioned 3. Dirt container not installed properly 4. Dirt container full 5. Clog in cleaner 6. Filters are dirty 7. Hose not properly attached 8. Fiber door and or gasket missing... -
Page 17: Please Do Not Return This Product To The Store
Thank you for selecting a bISSEll product. please do not return this product to the store. for any questions or concerns, bISSEll is happy to be of service. contact us directly at 1-800-263-2535. w w w . b i s s e l l . c a Remedies 1. Turn dial to higher setting... - Page 18 For information about repairs or replacement parts, or questions about your warranty, call: Or visit the BISSELL website - www.bissell.ca When contacting BISSELL, have model number of cleaner available. Please record your Model Number: ___________________ Please record your Purchase Date: ___________________ NoTE: please keep your original sales receipt.
-
Page 19: Replacement Parts And Accessories
Replacement parts are available through bISSEll consumer Services, an authorized bISSEll Service centre or by visiting our website. below is a list of common replacement parts*. While not all of these parts may have come with your specific model, they are available for purchase if desired. -
Page 20: Limited Five Year Warranty
Subject to the *EXcEpTIoNS aND EXclUSIoNS identified below, upon receipt of the product, BISSELL Canada Corporation will repair or replace (with new or remanufactured components or products), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for five years any defective or malfunctioning part.
Need help?
Do you have a question about the Healthy Home Vacuum 16N5 series and is the answer not in the manual?
Questions and answers
How do I replace belt for the brush roller?
To replace the brush roller belt on a Bissell Healthy Home Vacuum 16N5 series:
1. Remove the old brush inside the belt.
2. Place the new brush into the belt and insert the ends into the slots on the sides as shown in the manual.
3. Reposition the top cover, ensuring the inside tab at the front aligns with the opening on the cover.
4. Twist the collar until the opening is at the bottom to lock it into place.
