Summary of Contents for Coleman 5300 LP Gas Series

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Coleman 5310 Owner's Manual Shop genuine replacement parts for Coleman 5310 Find Your Coleman Grill Parts - Select From 255 Models -------- Manual continues below --------...
  • Page 2 Keep this manual for future reference. If you have questions about assembly, operation, servicing or repair of this grill, please call Coleman at 1-800-835-3278 or C E R T I F I E D ®...

  • Page 3: Table Of Contents

    Contents WARNING General Safety Information ........2 F YOU SMELL GAS General Installation .

  • Page 4: General Installation

    General Safety Information cont. 36" General Installation • Installation must conform with local codes or, in the absence of local codes, with either the National Fuel Gas Code, ANSI Z223.1 (USA), CAN/CGA-B149.1, Natural Gas Installation Code or CAN/CGA-B149.2, Clear Propane Installation Code (Canada). To check local codes, see your local L.P.

  • Page 5: Electrical Attachments

    Electrical Attachments Natural Gas Connections WARNING When using an electric attachment with grill, follow specification and warning statements accompanying the attachment. IMPORTANT: If using an external electrical source, the installed • Gas supply system must be installed in accordance with the U.S. appliance must be electrically grounded according to local codes National Fuel Gas Code.

  • Page 6: L.p. Gas Cylinder

    Do not use another hose and regulator assembly other than the one supplied with the grill or a Coleman replacement pressure regulator assembly. The pressure regulator and hose assembly provided is factory set at an outlet pressure of 11 inches water column (1/2 psi).

  • Page 7: Filling And Purging Type 1 L.p. Gas Cylinders

    Transporting the Cylinder Filling and Purging Type 1 cont. L.P. Gas Cylinders cont. WARNING Handle a full cylinder with care. Gas is under high pressure. CGA-510 POL DANGER • NEVER store a spare L.P. gas supply cylinder under the grill body or inside grill enclosure or in the vicinity of any heat producing appliance.

  • Page 8: Assembly/Set Up

    Assembly/Set up Remove components from package. *Left Side Burner Electrode Hardware Firebox Blister Pack Left Side Burner Table Right Side Table Side Burner Knob Side Burner Grates Side Spacers Burner *Rear Trim Plate Grate Warming Rack Top Panel Grease Pan Grease Rear Panel Grease...

  • Page 9: Right Panel

    NOTE: Use a large piece of cardboard or a ground Hardware shown actual size cloth to protect the painted finish on the grill. Assemble the Right Panel and the Left Panel to the Step Grill Base. (TN) M6 x 15mm Screw (12) Qty.
  • Page 10 Assemble four Caster Brackets to the Grill Base. Hardware shown actual size Assemble two Locking Casters to the front of the Grill Base. Step Assemble two Non-Locking Casters to the rear of the (TN) Grill Base. M6 x 15mm Screw (12) Qty.

  • Page 11: Rear Panel

    3-B. Assemble the Cylinder Carefully turn the assembly Retaining Bolt to the Right-Side-Up. Cylinder Support. Assemble the Rear Panel. Step NOTE: On some Assemble the Cylinder models, the Cylinder Support. Retaining Bolt is pre-installed by the factory. Hardware shown actual size Hardware shown actual size (VP) (FA)
  • Page 12 Attach Electrode Module. Install Door Magnet. Step Hardware shown actual size Hardware shown actual size (BW) (AV) (TN) M5 Locking Hex Nut M5 x 10mm Screw M6 x 15mm Screw (2) Qty. (2) Qty. (2) Qty. AV (x2) TN (x2) Electrode Module BW (x2) Left...
  • Page 13 Assemble two Spacers to Assemble Firebox to the the Top Panel. Grill Cart. Assemble the Top Panel to NOTE: A second person is Step Step the Grill Cart. needed when aligning the Firebox to the Grill Cart. Hardware shown actual size Hardware shown actual size (TN) M6 x 15mm Screw...
  • Page 14 View of Grill from Front 6-B. While lowering the Firebox, route the fuel hoses through the large hole in the top panel. TN (x2) DY (x2) View of Grill from Front 6-C. Fasten the front side of the Firebox to the Grill Cart with two Flat Washers (DY) and two Screws (TN).

  • Page 15: Right Side Panel

    NOTE: The Grill Lid Hardware shown actual size should be opened for Steps 7 and 8. Step Assemble Right Side Table to the Grill. (UO) (TN) (DY) M6 Locking Hex Nut M6 x 15mm Screw M6 Flat Washer (1) Qty. (5) Qty.
  • Page 16 View of Grill from Rear 7-D. Assemble one Screw (TN), one Flat Washer (DY) and one Locking Hex Nut (UO) through the Firebox into the Right Side Table. Tighten all fasteners.
  • Page 17 Assemble Left Side Hardware shown actual size Burner to the Grill. Step (UO) (TN) (DY) M6 Locking Hex Nut M6 x 15mm Screw M6 Flat Washer (1) Qty. (5) Qty. (1) Qty. Left Side Burner Table Left Side Firebox Panel 8-A.
  • Page 18 View of Grill from Rear 8-D. Assemble one Screw (TN), one Flat Washer (DY) and one Locking Hex Nut (UO) through the Firebox into the Left Side Burner Table. Tighten all fasteners.
  • Page 19 Fasten the Rear Trim Plate to the Grill Cart. NOTE: On some models, Step the Rear Trim Plate is pre- installed by the factory. Hardware shown actual size (VP) Self Tapping Screw (2) Qty. Firebox Rear Trim Plate Rear Trim Plate VP (x2) 9-B.
  • Page 20 Fasten both Left and Right Hardware shown actual size Doors to the Grill Cart. Attach the Tool Hook to the Right Door. Step Fasten the Door Handles to the Doors. (BW) (XR) (EZ) NOTE: M4 x 5mm Screws M5 Hex Nut M5 x 15mm Flat M4 X 5mm (EZ) are factory installed...
  • Page 21 11-B Install four Heat Tents™. Heat Install four Cooking Grates. Tents™ Install the Warming Rack. Step 11-B. Install four Heat Tents™ over the Burners. The Heat Tents™ are located using the alignment pins. 11-A Warming Rack 11-C Standard Power Standard Cooking Grate Grates...
  • Page 22 Install the Side Burner Hardware shown actual size Valve. NOTE: On some models, Step the M4 x 10mm Screws (WQ) are pre-installed on (WQ) the bracket by the factory. M4 X 10mm Screw (2) Qty. 12-B 12-A Side Burner Valve Large Hole 12-D View...
  • Page 23 Assemble the Side Burner Hardware shown actual size to the Left Side Table. Assemble the Electrode to Step the Side Burner. (ZT) (WQ) (YS) NOTE: On some models, Hair Pin M4 X 10mm Screw M4 Hex Nut the Electrode is pre-installed (1) Qty.
  • Page 24 Assemble the Electrode Wires and the Battery to the Electrode Module. Step Note: The fuel hoses are not shown in this step, for simplicity. 14-A 14-A. Slip the Top Burner Wires through the Top Burner Wires large hole in the Top Panel. Slip the Side Burner Wire through the large hole in the Left Panel.
  • Page 25 Install Side Burner Knob Assemble the Grease Cup and Side Burner Grate onto Support to the Grease Pan. the Left Side Burner. Note: The Grease Pan is shown Step Step up-side-down during this step. Hardware shown actual size (VP) Self Tapping Screw (2) Qty.

  • Page 26: Grease Cup

    Install the Grease Pan. Install the Grease Cup. Step 17-A Grease Pan Grease Pan Support 17-A. Slide the Grease Pan Assembly into the back of the grill. 17-C 17-B Grease Cup 17-B. Place the Grease Cup into the Grease Cup Support. Note: Pull the Grease Pan outward slightly for easier access when installing/removing the Grease Cup.
  • Page 27 NOTE: Step 18 applies to you only if your grill is set up from the factory to use LP GAS. If your grill is set up from the factory to use NATURAL GAS, skip to Step 19. Attach an LP Cylinder to the Grill.
  • Page 28 NOTE: Step 19 applies to you only if your grill is set up from the factory to use NATURAL GAS. If your grill is set up from the factory to use LP GAS, skip back to Step 18. Attach a NATURAL GAS line to the grill.

  • Page 29: Connecting Type 1 L.p. Gas Cylinders

    3. Stop a leak by tightening the loose joint, or by replacing the valve outlet. Be sure the nipple is centered in the valve outlet. faulty part with a replacement part recommended by Coleman. Hand-tighten the coupling nut, taking care not to cross-thread DO NOT attempt to repair the cylinder valve if it should the connection (see Fig.

  • Page 30: Start-Up Check List

    Fixing A Fuel Leak Lighting Instructions (cont.) WARNING CAUTION THE FOLLOWING RULES MUST ALWAYS BE Inspect the gas supply hoses before each use. If there are FOLLOWED IN THIS ORDER (Fig. 18): cuts, damage, excessive abrasion or wear, replace the hoses prior to operating the appliance.

  • Page 31: Lighting Main Burners

    Lighting Main Burners Shutting Off the Grill 1. Turn on any or all burner gas control knobs to high. (Fig. 19) CAUTION 2. Press the igniter switch until the flame ignites. 3. If the flame doesn’t immediately light, turn off control knob and DO NOT touch hot grill parts with bare hands! You MUST wait five minutes for gas to clear.

  • Page 32: Grilling Tips And Hints

    L.P. cylinder, cylinder valve, regulator, gas supply hose, burner valve(s) and burner(s). 5. If any of the above mentioned components are damaged, Blue Yellow seek replacement from Coleman before operating the grill again. Locate your nearest service center by calling 1-800-835-3278. Blue Note: •...

  • Page 33: Cleaning The Venturi

    Cleaning the Venturi Cleaning and Maintenance WARNING CAUTION All cleaning and maintenance should be done only when Spider’s nests or wasp’s mud inside the venturi may cause fire grill is cool & with the fuel supply turned off at the cylinder. at valve.

  • Page 34: Moving And Storage

    Cleaning and Maintenance Moving and Storage cont. CAUTION A collision with the grill, as with any metal object, could cause injury. Use care when moving a portable gas grill. DANGER Moving the grill: NEVER attempt to operate your grill without orifices in the •...

  • Page 35: For Your Additional Safety

    For Your Additional Safety Troubleshooting cont. cont. Problem: Flame blows out on low setting or YOUR NEW GAS GRILL IS EQUIPPED WITH A has uneven heat distribution. TYPE 1 CONNECTION DEVICE WHICH HAS 3 SAFETY FEATURES: Possible Causes and Solutions: (SEE TYPE 1 CONNECTION ILLUSTRATION) 1.

  • Page 36: Registration Card

    ¨ warranty. PROTECT YOUR PRODUCT: We will keep the model number and date of purchase of your new Coleman ¨ product on file to help you refer to this information in the event of an insurance claim such as fire or theft.
  • Page 37 Porcelain or stainless steel cooking grates Thank you for filling out this questionnaire. Your answers are important to us. Please check here [ ] if you prefer not to learn more about Coleman ® Outdoor Cooking Products or obtain information on new interesting opportunities from other companies.

  • Page 38: Recipes

    Recipes Asian-flavored eggplant Chili-orange pork loin Cooking time: 8-10 minutes Cooking time after marination: 6-7 minutes 2 large eggplant, peeled and sliced into 1/2 inch 2 pounds boneless pork loin, cut into 16 thin slices rounds 1/2 cup orange juice 2 Tb olive oil juice of one lime 4 cloves garlic, minced...
  • Page 39 Recipes Spice-rubbed spareribs Grilled tuna steaks with olive vinaigrette Cooking time: 45 minutes to partial boil; 16-20 min- Cooking time after marination: 10 minutes utes to grill 4 6-8 oz. Tuna steaks 6 pounds baby back pork spareribs water to cover For the marinade: 2 Tb olive oil For the spice mixture:...
  • Page 40 Recipes Lemongrass beef skewers with peanut dipping Lamb grilled with rosemary and Dijon sauce Cooking time after marination: 30-40 minutes Cooking time after marination: 4-5 minutes 2 pound boneless lamb leg, trimmed and butterflied 2 pounds boneless sirloin 8 cloves garlic, minced For the Marinade: 2 tsp fresh rosemary leaves, minced 3 cloves garlic, minced...

  • Page 41: Warranty

    (see label on cylinder for cylinder manufacturer’s warranty) or the paint finish of the product. Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the war- ranty period.
