Battery Maintainer
PLEASE READ before using Maintainer. The term battery will be used to reference a single battery or multiple
battery pack; wired in series or parallel. Contact Schauer Chargers with any questions prior to operation.
IMPORTANT! Reverse polarity connection will blow output fuse and may
permanently damage maintainer circuitry. Take care to correctly connect battery
clips to proper battery terminals – Red Positive clamp to first battery in series
Positive post and Black Negative clamp to last battery in series Negative post.
Incorrect connection not across complete battery pack will cause battery over
voltage on connected batteries and may cause damage, fire or explosion.
This unit is a battery maintainer (max. 2.5 amps), not a battery charger. This maintainer will keep a fully
charged battery at a proper maintenance charge voltage; it will not charge a large capacity (golf cart)
discharged battery.
Caution! Safety precautions must be observed to avoid injury, electrical shock and/or fire!
❖ For use with 120 Volts AC mains electrical service: USA, Canada. (not 240 VAC compatible)
❖ Always check for proper water level in battery prior to maintaining
❖
Be sure your battery is not drawing any load from equipment or instruments while you are maintaining.
❖ Before connecting or disconnecting maintainer to battery, turn power switch off and unplug from AC outlet
❖ Maintainer must be plugged into a grounded AC outlet
❖ Maintainer must be operated in an environment with proper ventilation
❖ Maintainer must not be operated in a damp or wet environment
❖ Do not use maintainer on 10 Ah or smaller battery
Caution! A battery charger should not be connected or operating while maintainer is in use.
Connection sequence:
1) Attach positive (Red) battery clip to Positive post of first battery in series
2) Attach Negative (Black) battery clip to Negative post of last battery in series
3) Plug maintainer into AC power
Battery Chargers
Models:
JAC0336MAN, 36 volt
JAC0348MAN, 48 Volt
Advertisement
Related Manuals for Schauer JAC0336MAN
Summary of Contents for Schauer JAC0336MAN
- Page 1 PLEASE READ before using Maintainer. The term battery will be used to reference a single battery or multiple battery pack; wired in series or parallel. Contact Schauer Chargers with any questions prior to operation. IMPORTANT! Reverse polarity connection will blow output fuse and may permanently damage maintainer circuitry.
- Page 2 4) Turn maintainer power switch on Since maintainer is connected directly to the battery Pos./Neg. post, a golf cart may be put in “tow” mode to avoid any load on the batteries while in maintenance. You may leave this maintainer on a good condition battery for months at a time and it will not overcharge your battery.
- Page 3 2. This warranty only applies to Products that (i) are operated in accordance with their technical and operational instructions, and (ii) have not been damaged or altered by repair or service not rendered by Schauer or by a Schauer authorized repair station. This warranty is contingent upon proper storage, handling and implementation of the Product and does not cover Products that have been subjected to physical abuse, electrical stress from improper handling or implementations inconsistent with Schauer’s technical directions.
