User Manual 12 Volt Battery Charger 1/4/6 Amp & 1/8/12 Amp Battery maintainer and Rejuvenator Plus Model No. CM6A (0757-14CEC) / CM12A (0757-15CEC) THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS READ ENTIRE INSTRUCTION BEFORE USE... -
Page 2: Personal Precautions
WARNING - RISK OF EXPLOSIVE GASES WORKING IN VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. EXPLOSIVE GASES DEVELOP DURING NORMAL BATTERY OPERATION. IT IS IMPORTANT THAT EACH TIME BEFORE USING YOUR CHARGER, YOU READ THIS MANUAL AND FOLLOW THE INSTRUCTIONS EXACTLY. ... -
Page 3: Preparing To Charge
Be extra cautious to reduce risk of dropping a metal tool onto battery. It might spark or short-circuit battery or other electrical part that may cause explosion. When working with a lead-acid battery, remove personal metal items such as rings, bracelets, necklaces, watches, etc. -
Page 4: Main Features
gauge metal part of the frame or engine block. Connect charger AC supply cord to electric outlet. When disconnecting charger, turn switches (if supplied) to off, disconnect charger from AC power, remove clip from vehicle chassis, and then remove clip from battery terminal. See operating instructions for length of charge information. -
Page 5: Temperature & Safety Protection
this feature is fully automatic and subjected to the internal impedance of the battery. Charge & Maintain - Automatic Maintenance: The battery charger could be left unattended and it is full time managed by program; when the battery is charged to "full"... -
Page 6: Battery Types & Capacity
During ECO mode, the power drawn is less than 0.7W, equal to power consumption of 0.02kWh per day; after the battery is fully charged and during long term maintenance stage, the total power consumption is around 0.06kWh per day. RAPID CHARGE / SILENT CHARGE (NIGHT MODE) AND MAINTENANCE: Rapid charge mode: Uses the rated maximum charging current to ensure the fastest charging time, the fan of the unit will turn on to ensure the maximum charging current. -
Page 7: Environmental Characteristics
Storage Temperature: -25 to 85°C Operating Humidity Range: 90% RH Max Cooling: Fan or natural cooling depends on charge mode selection TECHNICAL SPECIFICATIONS: Model Number CM6A (0757-14) CM12A (0757-15) Type Smart Smart Input Voltage Range 100-120Vac 100-120Vac... -
Page 8: The Charging Process
STEP 2 - Connecting the Battery charger to your Battery If the Battery is out of the vehicle: o Connect the Red lead from the charger to the positive (+) battery terminal. o Connect the Black lead from the charger to the negative (-) battery terminal. ... - Page 9 process, a high voltage equalizing and peak pulse reconditioning charge is used to repair the sulphated battery, this unique patented feature will break down and dissolve the lead-sulphate crystal built up on the battery plates, balance out the high concentrations of acid, which is to extend your battery life and performance.
- Page 10 The Yellow Charging LED is ON (if above situation occurred) o Float Mode (Safe voltage level of 13.6V) Full Green LED is ON. The Float Mode allows the charger to effectively be left connected to your batteries; it works at a safe level of 13.6V, and ready for use. o Maintenance mode (Special pulse for long term maintenance) ...
- Page 11 Status Descriptions 1. Press to select the charge rate 2. Green Maintenance charge mode is selected 3. Green Silent charge mode is selected 4. Green Rapid charge mode is selected Status Descriptions 5. Fault LED – Red Short circuit / Reverse polarity or Rejuvenation failed if Bulk LED also flashing fast Over temperature protection mode / Soft start charging timed out if Blue Flashing...
-
Page 12: Troubleshooting
TROUBLE SHOOTING Types Indication Possible Causes Suggested Solution Problems Charger - No AC power - Check AC connections does not Indicator and make work? lights on sure Power Point is switched ON - Output is short circuited - Check DC connection Charger has Fault RED - Reverse polarity connection...
