- Page 1 INSTALLATION MANUAL BOILIN G CHILLED SPARKLING HOT & COLD QT553/MAYA - 07172024...
-
Page 2: Table Of Contents
• QUATREAU TOUCHTAP TYPICAL INSTALLATION • QUATREAU TOUCHTAP PRE-INSTALLATION CHECK • SECTION A: UNPACKING YOUR EQUIPMENT • SECTION B: INSTALLING THE QUATREAU TAP • SECTION C: INSTALLING THE WATER HEATER • SECTION D: CONNECTING YOUR TAP • SECTION E: INSTALLING THE CHILLER CARBONATOR •... -
Page 3: Quatreau Touchtap Typical Installation
QUATREAU TOUCHTAP™ TYPICAL INSTALLATION TYPICAL INSTALLATION... -
Page 4: Quatreau Touchtap Pre-Installation Check
Always check with the work surface manufacturer and ask what type of cutting tool can be used. Note that the TouchTap™ control panel is on the right-hand side of the tap. Ensure that the location you choose is suitable and that you can reach the controls without needing to stretch. -
Page 5: Section A: Unpacking Your Equipment
Installation Kit including Carbon Filter Unscrew the stainless steel housing and insert CS20-A Chiller Carbonator ✓ the filter into the housing. Quatreau TouchTap™ Faucet Package ✓ ✓ CO2 Canisters Position both the stainless steel filter housing and filter to fit the filter into the manifold. -
Page 6: Section B: Installing The Quatreau Tap
SECTION B carbonator must be located underneath the tap/sink or in an adjacent cupboard. The base INSTALLING THE QUATREAU of the tap should be no further than 1 meter/3 ft away from the left side of the water heater control unit. This is to ensure the communica- 1. -
Page 7: Section C: Installing The Water Heater
4. Position the tap so that the control panel faces forward towards the user position (180 degrees to the sink). Then tighten the bolts until you have a firm fusing on both sides. The comms cable hangs The thermostatic mixing valve will set the down and will connect hand-hot temperature to the system. - Page 8 3 bar/45 psi output valve. Cut a length of 3/8” blue tubing to run from the RO system to the Quatreau system. from the reducer outlet to the MAINS COLD Some RO units have a maximum pressure of...
-
Page 9: Section D: Connecting Your Tap
SECTION D CONNECTING YOUR TAP Once the tap is in position, you are now ready to connect the tap to the water heater unit. 1. Remove the end cap prior to installing the silicon by compressing the gray collar and lifting up the cap. -
Page 10: Section E: Installing The Chiller Carbonator
This enables ventilation and air movement, INSTALLATION PLEASE CONTACT without which the system will not chill correctly. THE LOCAL OFFICE FOR YOUR AREA LISTED UNDER WWW.QUATREAU. COM/CONTACT-US INSTALLING THE CHILLER CARBONATOR... -
Page 11: Quatreau ® Installation Record
E-mail: Address: Installer Name: Installer E-mail & Phone Number: QUATREAU UNIT INFORMATION: Location of Quatreau Unit: (address) Type of Site & Installation: e.g. office, residence, yacht, kitchen, wet bar, gym, pantry, etc., Elevation at Site: Incoming Water Pressure to Unit:... - Page 12 Distributed by: Global Water Solutions Find out more at: www.Quatreau.com © gws July 2024...
