- Page 1 SSC2101&2102&2103-FH V100R001C10 Quick Installation Guide Issue: 03 Date: 2017-08-18 HUAWEI TECHNOLOGIES CO., LTD.
-
Page 2: Safety Precautions
The WARNING, CAUTION, and NOTE marks in the document do not cover all the safety precautions that must be followed; they only supplement general safety precautions as a whole. Huawei is not liable for any consequence that results from customers' violation of universal operation requirements or equipment design, manufacturing, and usage safety standards. - Page 3 Appearance and Structure Structure Front view Rear view SSC2101-FH Straight-through tray Shell Velcro tape Splicing tray Splicing tray base Splicing tray support Fixing component of Staple bolt optical cable Gasket Optical cable aperture...
-
Page 4: Installation Process
1 Opening the Dome-style Closure To open the closure, do as follows: a) Hold the latch on the staple bolt outwards. b) Open the staple bolt. c) Remove the staple bolt, the cap of the closure, and the velcro tape. SSC2101-FH... - Page 5 2 Stripping and Securing Optical Cables Stripping a Straight-through Optical Cable Mark the position where the optical cable will be stripped. Determine the length to be stripped for each section of the optical cable, and Handle the strength members carefully as strip the optical cable.
- Page 6 2 Stripping and Securing Optical Cables (Continued) Routing and Securing the Straight-through Optical Cable a) Route the optical cable into the heat shrink tubing from the end with more hot melt adhesive. b) Route the optical cable and secure the strength members. c) Coil the straight-through optical cable. (Straight-through optical cables for the SSC2103-FH are coiled in the straight-through area.
- Page 7 3 Splicing and Terminating Optical Fibers and Routing Pigtails (Continued) Splice the optical fibers. a) Strip optical fiber A until the bare fiber is exposed. b) Put the pigtail into a splicing protection tube. c) Strip the bare fiber until the fiber core is exposed. d) Strip optical fiber B until the bare fiber is exposed. e) Strip the bare fiber until the fiber core is exposed.
- Page 8 3 Splicing and Terminating Optical Fibers and Routing Pigtails (Continued) Splice the branching optical fiber of the feeder cable and the input fiber of SPL9102, and splice the optical fiber of the branching cable and the output fiber of SPL9102. a) Strip optical fiber A until the bare fiber is exposed. b) Put the pigtail into a splicing protection tube.
- Page 9 4 Sealing the Closure (Continued) Preparing for Heat Shrink Mark the point 120 mm away from Wrap the cable at the marked point Polish the tinfoil paper on the cable. the endpoint of the cable aperture at one round using a piece of tinfoil the bottom of the closure.
- Page 10 4 Sealing the Closure (Continued) Heat Shrinking Common Cable Apertures Remove the insulation tape from the cable aperture, and Heat shrink the bottom end of the heat shrink install a heat shrink tubing at the common cable aperture. tubing for about 60 mm. Ensure that the heat shrink is even.
- Page 11 7 Installing Closure Accessories Installing Wall-mounting Accessories Install expansion screws on the wall. Ø10 drill Install a wall-mounting accessory using a 45 mm M4 screw on the closure and tighten the screws. Rear view Wall-mounting accessory Attach the wall-mounting accessories to expansion screws on the wall and secure the closure to the wall.
- Page 12 7 Installing Closure Accessories (Continued) Installing Aerial Accessories a) Remove the wall-mounting accessory. b) Install an aerial accessory. Install a aerial accessory using a 45 mm M4 screw on the closure and tighten the screws. Rear view Install the aerial accessory on the steel wire and secure the closure.
- Page 13 Install a pole-mounting accessory using a 45 mm M4 screw on the closure and tighten the screws. Rear view Install the pole-mounting accessory on the pole and secure the closure. Huawei Technologies Co., Ltd Administration Building, Huawei Technologies Co., Ltd., Bantian, Longgang District, Shenzhen, P. R. China Postal code: 518129 www.huawei.com...
