PDC-0038V4ACIOA Power Distribution
Unit Quick Guide
Issue: 02
Part Number: 31505549
Date: 2020-09-07
1
Precautions
Safety Precautions
■
To ensure safety of humans and the equipment, pay attention to the safety symbols on the
equipment and all the safety instructions in this document. The "NOTE", "CAUTION", and
"WARNING" marks in this document do not represent all the safety instructions. They are only
supplements to the safety instructions. When operating Huawei equipment, in addition to
following the general precautions in this document, follow the specific safety instructions
given by Huawei. Huawei will not be liable for any consequences that are caused by the
violation of safety regulations and design, production, and usage standards.
Local Safety Regulations
■
When operating Huawei equipment, you must follow the local laws and regulations.
Personnel Requirements
■
1. Only trained and qualified personnel are allowed to install, operate, and maintain Huawei
equipment, and they must understand basic safety precautions.
2. You can modify default parameters only after being granted approval from Huawei
technical support.
Symbols
■
Alerts you to a potentially hazardous situation that could, if not avoided, result in equipment
damage, data loss, performance deterioration, or unanticipated results.
Provides additional information to emphasize or supplement important points in the main text.
Human Safety
■
1. To prevent electric shocks, get tools insulated and wear insulation gloves when
connecting cables.
2.
In case of fire, use a dry power fire extinguisher to put out the fire. Using a fluid fire
extinguisher may cause electric shocks.
Copyright © Huawei Technologies Co., Ltd. 2020. All rights reserved.
1

Advertisement

loading

Related Manuals for Huawei PDC-0038V4ACIOA

Summary of Contents for Huawei PDC-0038V4ACIOA

  • Page 1 When operating Huawei equipment, in addition to following the general precautions in this document, follow the specific safety instructions given by Huawei. Huawei will not be liable for any consequences that are caused by the violation of safety regulations and design, production, and usage standards.
  • Page 2 Appearance PDC-0038V4ACIOA PDU Model PDC-0038V4ACIOA Applicable UPS2000-G- 15KRTL/20KRTL Weight 15 kg Dimensions 130 mm x 430 mm x 585 (H x W x D) Front panel (under the cover) (1) UPS 1 mains (2) UPS 2 mains input (3) UPS 1 bypass input...
  • Page 3 Rear panel (1) Maintenance (2) Dual in-line (3) Control area (4) Output ports bypass ports package (DIP) network (CAN) switch communications ports (5) Bypass input (6) Mains input (7) Output socket (8) Output ports ports group 1 (250 V AC, socket group 1 15 A) fuses...
  • Page 4 Check the PDU bar code and ensure that it complies with the order. Check against the delivery list that the types of fittings are complete and correct. If there is any discrepancy, contact your local Huawei office immediately. Device Movement Regulations Do not move the PDU by holding its mounting brackets, front panel, or terminal cover.

  • Page 5: Mechanical Installation

    Mechanical Installation Rack-mounting the PDU This document uses a 19-inch rack as an example. For other racks, see the related UPS quick installation guide. 1. Install mounting brackets. 2. Install adjustable guide rails and floating nuts. 1. Install adjustable guide rails when you rack-mount a device. For a 2 U device, install only adjustable guide rails and secure it with screws.
  • Page 6 Adjustable guide rail Mounting bracket notch Mounting bar Floating nut Flat-head screwdriver 3. Place the PDU on the guide rails. Secure the PDU to the rack using M6x16TM screws through the holes in the mounting brackets. Do not move the PDU by holding its mounting brackets, front panel, or terminal cover.When you move it, see the movement regulations.
  • Page 7 (Optional) 1 U STS 3 U PDC- 0038V4ACIOA 3 U UPS 1 3 U UPS 2 (Optional) 3 U battery pack 1 (Optional) 3 U battery pack 2 (Optional) 3 U battery pack 3 (Optional) 3 U battery pack 4 Tower-mounting the PDU 1.

  • Page 8: Cable Installation

    2. Assemble support bases. When you assemble two support bases, align connecting buckles with holes and insert the buckles vertically, as shown in the following figure. 3. Install two support bases for each group of devices. Place the support bases on the floor, determine the distance (greater than or equal to 280 mm) between the support bases, place devices on the support bases, and secure them.
  • Page 9 2. Loosen screws to remove the busbar cover. 3. Connect cables.  Power cable torque table for UPS2000-G-15 kVA or UPS2000-G-20 kVA (three-phase input three-phase output) Device Tool Screw Torque UPS2000-G-15 kVA M5x0.8p 1.5 N· m UPS2000-G-20 kVA M5x0.8p 1.5 N· m Torque screwdriver M5x0.8p...
  • Page 10 Item Appearance Specifications Remarks Prepared PDU AC output 10 mm² power cable onsite PDU bypass Prepared input power 10 mm² onsite cable PDU mains Prepared input power 10 mm² onsite cable Separately UPS 1 bypass delivered input power with the cable Separately UPS 1 mains...

  • Page 11: Power-On Procedure

    Mapping between cable connectors for CAN communications ports. Connecting cables to the PDU for 1+1 parallel system of UPS2000-G-15 kVA or UPS2000-G-20  kVA (three-phase input three-phase output) AC BYPASS AC MAINS AC OUTPUT INPUT INPUT The preceding figure shows how to connect cables when there are two mains inputs. In the case of one mains input, connect the mains input power cables to the AC BYPASS INPUT ports (the AC MAINS INPUT ports are not connected).
  • Page 12 Appendix Maintenance bypass usage (1) UPS 1 mains (2) UPS 2 mains input (3) UPS 1 bypass input (4) UPS 2 bypass input circuit breaker circuit breaker circuit breaker input circuit breaker (5) UPS 1 output (6) UPS 2 output (7) Maintenance bypass (8) Maintenance circuit breaker...
  • Page 13 4. Disconnect the hot-swap terminals between the PDU and the UPS. Hot-swap terminals 5. Use a multimeter to check that the UPS input and output voltages are 0. You can maintain the UPS. Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People's Republic of China www.huawei.com...
