TOP MOUNT REFRIGERATOR
INSTRUCTION MANUAL
CATALOG NUMBER
BR2010JIMW, BR2010JIMB,
BR2010JIMS, BR2400JIMW,
BR2400JIMB, BR2400JIMS
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER purchase,
go to www.blackanddecker.com/instantanswers
If you can't find the answer or do not have access to the Internet, call 844-299-0879 from
10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an agent. Please have the catalog number
available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
ACTIVATE
WARRANTY
Advertisement
Table of Contents
Related Manuals for Black & Decker BR2010JIMW
Summary of Contents for Black & Decker BR2010JIMW
- Page 1 ACTIVATE WARRANTY TOP MOUNT REFRIGERATOR INSTRUCTION MANUAL CATALOG NUMBER BR2010JIMW, BR2010JIMB, BR2010JIMS, BR2400JIMW, BR2400JIMB, BR2400JIMS Thank you for choosing BLACK+DECKER! PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON. If you have a question or experience a problem with your BLACK+DECKER purchase, go to www.blackanddecker.com/instantanswers...
-
Page 2: Product Registration
PRODUCT REGISTRATION Thank you for purchasing our _____________________________ BLACK+DECKER product. This Model number easy-to-use manual will guide you _____________________________ in getting the best use of your Serial number refrigerator. _____________________________ Remember to record the model and Date of purchase serial numbers. They are on a label on the back of the product. -
Page 3: Safety Information
SAFETY INFORMATION DANGER WARNING CAUTION DANGER - Immediate hazards WARNING - Hazards or unsafe CAUTION - Hazards or unsafe which WILL result in severe practices which COULD result in practices which COULD result in personal injury or death severe personal injury or death minor personal injury IMPORTANT SAFETY INSTRUCTIONS WARNING... - Page 4 SAFETY INFORMATION 10. Do not operate your refrigerator in the presence of explosive fumes. Keep ventilation openings, in the appliance or enclosure or in the built-in structure, clear of obstruction. 12. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
-
Page 5: Grounding Instructions
SAFETY INFORMATION GROUNDING INSTRUCTIONS ELECTRICAL REQUIREMENTS The electrical requirements are a 115 volt 60 Hz, AC only, 15 amp. It is recommended that a separate circuit serving only the product be provided. The product is equipped with a 3-wire cord having a 3-prong grounding plug. - Page 6 SAFETY INFORMATION USE OF EXTENSION CORDS WITH REFRIGERATORS Only use a grounded extension cord that is rated at least 15 amps and has a third-wire ground. When a long extension cord is used to connect the refrigerator, a voltage drop occurs.
-
Page 7: Setup And Use
SET UP & USE INSTALLATION GUIDE Unpack your refrigerator by removing all packaging materials like carton, base, foams, adhesive tape, etc. 2. Remove all accessories, internal packaging material used to hold shelves, ice tray, etc. in place. 3. Clean the remains of all adhesive tape used and remove all printed material supplied. 4. -
Page 8: Door Alignment
SET UP & USE PROTECTION FROM HEAT AND MOISTURE • Do not install your refrigerator in any location where heavy moisture is present or if the location is not properly insulated. This refrigerator is not designed to operate in temperature settings below 50°... -
Page 9: Parts And Features
SET UP & USE PARTS AND FEATURES Ice Probe Freezer Door Ice Maker Ice Storage Bin Freezer Bottle Rack Temperature Control Panel Temperature Control Device Refrigerator Bottle Rack Glass Shelf Fruit and Vegetable Compartment Glass Shelf Fruit and Vegetable Compartment Leveling Foot Refrigerator Door Some features and accessories of the refrigerator you purchased may not be... - Page 10 SET UP & USE Temperature Control Panel Operation Temperature Control Panel 1. Temperature Control Panel Display Upon initial power-up, the default temperature for the refrigerator section is set to 4°c, with the corresponding display icon illuminated. Normal operation display During regular operation, the temperature display icon indicates the set temperature level of the refrigerator section.
- Page 11 SET UP & USE 4. Temperature and Function Setting of Refrigerator Section Press the temperature control button to adjust the temperature of the refrigerator section. Each press of the temperature control button increases the temperature by one level. Once the temperature reaches 8°C, pressing the temperature control button cycles it back to 2°C.
-
Page 12: Door Reversal
SET UP & USE DOOR REVERSAL List of tools needed (not included) Allen wrench set Philips head screwdriver Socket wrench set 1) Remove articles from the door body. 2) Remove the top hinge cover, left top hinge cover, and the top hinge. 3) Take off the freezer door carefully (ensure not to lose small parts on the door). - Page 13 SET UP & USE 5) Freezer door replacement: Install the sleeve on the other side; Remove the self-lock, stopper, and sleeve from the freezer door, flip and install the self-lock on the left side of the bottom end cover of the freezer door, and move the stopper and sleeve to the left side of the freezer door.
- Page 14 SET UP & USE 7) Install the replaced refrigerated door on the bottom hinge, then install the middle hinge and cover with the cross beam hole cover. 8) Place the freezer door on the middle hinge and install the top hinge; install the left top hinge cover on the right top side;...
- Page 15 SET UP & USE Connecting Water Supply List of supplies needed (not included) 1 ) Unplug the refrigerator; 2) Shut off the main water supply system. Choose the faucet closest to the refrigerator, 3) Use the faucet or a similar valve in the household. (Note: To ensure sufficient water flow to the refrigerator it is recommended to use at least a 1/2”...
- Page 16 SET UP & USE 7) Place the other end of the water supply tube into an empty container or sink, and open the main water supply system to flush the water supply line until the water runs clear. Close the faucet (Note: Before connecting to the faucet interface, ensure the water supply line is purged.) 1) Disconnect the refrigerator from the power source and turn off the water supply.
-
Page 17: Food Storage
SET UP & USE FOOD STORAGE • When storing fresh food that is not prepackaged, be sure to wrap or store food in airtight and moisture proof material unless otherwise noted. This will ensure proper shelf life and prevent the transfer of odors and tastes. -
Page 18: Cleaning And Care
CLEANING & CARE CLEANING AND CLEANING METHOD MAINTAINING Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed with warm water. Use The refrigerator should be cleaned and sponge or soft cloth, dampened with the cleaning maintained once a month. Before doing so, you solution to wipe down your refrigerator. -
Page 19: Energy Saving Tips
CLEANING & CARE ENERGY SAVING TIPS • The refrigerator should be located in the coolest area of the room, away from heat-producing appliances or heating ducts, and out of direct sunlight. • Let hot foods cool to room temperature before placing in the refrigerator. Overloading the refrigerator forces the compressor to run longer and thus increase energy consumption. -
Page 20: Troubleshooting & Warranty
TROUBLESHOOTING & WARRANTY BEFORE YOU CALL FOR SERVICE IF THE REFRIGERATOR FAILS TO OPERATE: A) Check to make sure that the refrigerator is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds and plug it in again securely. B) Check for a blown circuit fuse or a tripped main circuit breaker. - Page 21 TROUBLESHOOTING & WARRANTY TROUBLESHOOTING Troubleshoot your problem by using the chart below. If the refrigerator still does not work properly, contact W Appliance Co. customer service center or the nearest authorized service center. Customers must never troubleshoot internal components. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Refrigerator does not...
-
Page 22: Limited Warranty
LIMITED WARRANTY ACTIVATE WARRANTY Any repair, replacement, or warranty service, and all questions about this product should be directed to W Appliance Co. at 844-299-0879 from the US, including Puerto Rico, or Canada. Some issues can be addressed without service. Before contacting regarding your warranty, please visit the “Troubleshooting”... -
Page 23: Disclaimer Of Implied Warranties
LIMITED WARRANTY WHAT IS NOT COVERED / EXCLUSIONS 1. Commercial, non-residential or multiple family use or use 12. Travel or transportation expenses for service in remote inconsistent with the product instructions and manuals. locations where an authorized servicer is not available. 2. - Page 24 EXTENDED WARRANTY COVERAGE Protect Your Appliance with Extended Warranty Coverage Thank you for purchasing your new appliance! Your product comes with our one-year limited warranty, but why stop there? With our Extended Warranty and Accidental Damage Protection Plan, provided by Mulberry, you can ensure your appliances are covered for longer—without worrying about unexpected breakdowns or accidents.
- Page 25 BLACK & DECKER, BLACK+DECKER, the BLACK & DECKER and BLACK+DECKER logos and product names are trademarks of The Black & Decker Corporation, used under license. All rights reserved. BLACK & DECKER, BLACK+DECKER, les logos et noms de produits BLACK & DECKER et BLACK+DECKER sont des marques commerciales de The Black &...
