FRENCH DOOR REFRIGERATOR
INSTRUCTION MANUAL
CATALOG NUMBER
BRF1600GIM/BRF1800GIM
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER purchase,
go to www.blackanddecker.com/instantanswers
If you can't find the answer or do not have access to the Internet, call 844-299-0879 from
10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an agent. Please have the catalog number
available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
ACTIVATE
WARRANTY
Advertisement
Table of Contents
Related Manuals for Black & Decker BRF1600GIM
Summary of Contents for Black & Decker BRF1600GIM
- Page 1 ACTIVATE WARRANTY FRENCH DOOR REFRIGERATOR INSTRUCTION MANUAL CATALOG NUMBER BRF1600GIM/BRF1800GIM Thank you for choosing BLACK+DECKER! PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON. If you have a question or experience a problem with your BLACK+DECKER purchase, go to www.blackanddecker.com/instantanswers If you can’t find the answer or do not have access to the Internet, call 844-299-0879 from...
-
Page 2: Product Registration
PRODUCT REGISTRATION Thank you for purchasing our _____________________________ BLACK+DECKER product. This Model number easy-to-use manual will guide you _____________________________ in getting the best use of your Serial number refrigerator. _____________________________ Remember to record the model and Date of purchase serial numbers. They are on a label on the back of the product. -
Page 3: Safety Information
SAFETY INFORMATION DANGER WARNING CAUTION DANGER - Immediate hazards WARNING - Hazards or unsafe CAUTION - Hazards or unsafe which WILL result in severe practices which COULD result in practices which COULD result in personal injury or death severe personal injury or death minor personal injury IMPORTANT SAFETY INSTRUCTIONS WARNING... -
Page 4: Gas Warnings
SAFETY INFORMATION 12. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. 13. Do not use electrical appliances inside the food storage compartments unless they are recommended by the manufacturer. 14. -
Page 5: Grounding Instructions
SAFETY INFORMATION GROUNDING INSTRUCTIONS ELECTRICAL REQUIREMENTS The electrical requirements are a 115 volt 60 Hz, AC only, 15 amp. It is recommended that a separate circuit serving only the product be provided. The product is equipped with a 3-wire cord having a 3-prong grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. - Page 6 SAFETY INFORMATION USE OF EXTENSION CORDS WITH REFRIGERATORS Only use a grounded extension cord that is rated at least 15 amps and has a third-wire ground. When a long extension cord is used to connect the refrigerator, a voltage drop occurs.
- Page 7 SET UP & USE INSTALLATION GUIDE Unpack your refrigerator by removing all packaging materials like carton, base, foams, adhesive tape, etc. 2. Remove all accessories, internal packaging material used to hold shelves, ice tray, etc. in place. 3. Clean the remains of all adhesive tape used and remove all printed material supplied. 4.
-
Page 8: Door Alignment
SET UP & USE DOOR ALIGNMENT Door Hinge Cover Remove the top hinge cover. 2. Loosen the top hinge screws using a Phillips head screwdriver. 3. Adjust the door and then tighten the screws. LEVELING THE REFRIGERATOR Adjust the two levelling feet at front of the unit. If the unit is not level, the doors and magnetic seal frame will not be aligned properly Page 8... -
Page 9: Parts And Features
SET UP & USE PARTS & FEATURES 1. Door Bin 3. Crisper 5. Freezer Lower Drawer 2. Glass Shelf 4. Freezer Upper Drawer 6. Ice Maker Parts Quantity Door bin 8pcs Crisper 2pcs Freezer upper drawer 1pcs Freezer lower drawer 1pcs Note: Products are subject to changes Glass shelf... -
Page 10: Safety Warnings
SET UP & USE SAFETY WARNINGS TIPS FOR USE OF REFRIGERATOR COMPARTMENT 1. The common temperature of food stored in refrigerator is from 39-46°F (4-8 °C). In this environment, cooked meat cannot be stored for more than 4 days, and fruits and vegetables should not exceed one week at most. -
Page 11: Handling And Placement
SET UP & USE HANDLING AND PLACEMENT • The refrigerator should be placed on a flat • Refrigerator should be placed in a dry, well and solid ground. If it needs to be placed high, ventilated place. The sides and back of the choose a stable, firm and non-inflammable pad. - Page 12 SET UP & USE RESPONSIBLE DISPOSAL OF THE APPLIANCE At the end of its working life, do not throw this appliance out with your household garbage.Electrical and electronic appliances contain materials and substances which, if handled or disposed of incorrectly, could be potentially hazardous to the environment and human health.
- Page 13 SET UP & USE INSTRUCTION FOR USAGE • All the packaging components, including the • After the power supply is switched on, the foam pad (which cannot be used to make the compressor will stay on for an extended period refrigerator higher) and the adhesive tape as the appliance reaches the predetermined used for fixing accessories, must be removed...
- Page 14 SET UP & USE • When the refrigerator is off, please open the • After turning off the power, wait at least 5 door to prevent the bad smell from the residue minutes before it is reenergized. of the food in the refrigerator. •...
-
Page 15: Door Handle Installation
SET UP & USE DOOR HANDLE INSTALLATION • Before the refrigerator door handle is installed • Screw the locating bolt into the bolt hole of the (note: the anchor bolts of the handle are in door body and secure it. the accessory bag, and all steps should be performed at the right and left two mounting positions simultaneously). - Page 16 SET UP & USE DOOR TRAY INSTALLATION Install Uninstall • Place the tray above the mounting position and slide down as far as it will go. To uninstall, slide up. Overturning beam • When the overturning beam as shown in Figure 1, the door is unable to close normally, You must press the top guide block of the overturning beam as shown in Figure 2.
-
Page 17: Connect Water Supply
SET UP & USE CONNECT WATER SUPPLY What you need: 1. Basic tools (NOT INCLUDED): adjustable wrench , flat head screwdriver,and Phillips screwdriver. 2. Access to a household cold water line with water pressure between 20 and 120 psi. 3. A water supply line made of 1/4inch(6.4mm) outside diameter, copper tubing. - Page 18 SET UP & USE Ice Maker After turning on your refrigerator, the ice will start to be made between 12 and 24 hours. The ice maker produces 3.5 lbs ice per day, depending on the temperature of the freezer, the times in which the door opens, and other usage conditions (amount of food in the freezer, etc).
-
Page 19: Display Operation
SET UP & USE DISPLAY OPERATION The below picture is a schematic diagram of an electronic display Button instruction • “Fridge” button: Use to adjust refrigerator temperature. • “Freeze” button: Use to adjust the freezer temperature. • “Select” button: Press and the corresponding Quick Freezing or Smart icon will light. If no operation setting within 5 seconds, light will go off. - Page 20 SET UP & USE SETTING OF THE FUNCTIONS • The LED display turns bright when the door is open. Push the “Select” button for setting functions. • Entering the quick freezing mode: Push the “Select” button. When the quick freezing icon turns bright, it is in the quick freezing mode.
- Page 21 SET UP & USE LIGHTING AND ITS REPLACEMENT • When the door of refrigerator opens, the LED light turns on. • When the lighting is damaged, please remove protective cover first and then replace the LED light. • The specific operations are shown in the following diagram: 1.
-
Page 22: Cleaning And Care
CLEANING & CARE CLEANING AND CLEANING METHOD MAINTAINING Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed with warm water. Use The refrigerator should be cleaned and sponge or soft cloth, dampened with the cleaning maintained once a month. Before doing so, you solution to wipe down your refrigerator. -
Page 23: Energy Saving Tips
CLEANING & CARE ENERGY SAVING TIPS • The refrigerator should be located in the coolest area of the room, away from heat-producing appliances or heating ducts, and out of direct sunlight. • Let hot foods cool to room temperature before placing in the refrigerator. Overloading the refrigerator forces the compressor to run longer and thus increase energy consumption. -
Page 24: Troubleshooting & Warranty
TROUBLESHOOTING & WARRANTY BEFORE YOU CALL FOR SERVICE IF THE REFRIGERATOR FAILS TO OPERATE: A) Check to make sure that the refrigerator is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds and plug it in again securely. B) Check for a blown circuit fuse or a tripped main circuit breaker. - Page 25 TROUBLESHOOTING & WARRANTY TROUBLESHOOTING Troubleshoot your problem by using the chart below. If the refrigerator still does not work properly, contact W Appliance Co. customer service center or the nearest authorized service center. Customers must never troubleshoot internal components. TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY Refrigerator does not...
-
Page 26: Limited Warranty
LIMITED WARRANTY ACTIVATE WARRANTY Any repair, replacement, or warranty service, and all questions about this product should be directed to W Appliance Co. at 844-299-0879 from the US, including Puerto Rico, or Canada. Some issues can be addressed without service. Before contacting regarding your warranty, please visit the “Troubleshooting”... -
Page 27: Disclaimer Of Implied Warranties
LIMITED WARRANTY WHAT IS NOT COVERED / EXCLUSIONS 1. Commercial, non-residential or multiple family use or use 12. Travel or transportation expenses for service in remote inconsistent with the product instructions and manuals. locations where an authorized servicer is not available. 2. - Page 28 EXTENDED WARRANTY COVERAGE Protect Your Appliance with Extended Warranty Coverage Thank you for purchasing your new appliance! Your product comes with our one-year limited warranty, but why stop there? With our Extended Warranty and Accidental Damage Protection Plan, provided by Mulberry, you can ensure your appliances are covered for longer—without worrying about unexpected breakdowns or accidents.
- Page 29 BLACK & DECKER, BLACK+DECKER, the BLACK & DECKER and BLACK+DECKER logos and product names are trademarks of The Black & Decker Corporation, used under license. All rights reserved. BLACK & DECKER, BLACK+DECKER, les logos et noms de produits BLACK & DECKER et BLACK+DECKER sont des marques commerciales de The Black &...
