RiDom Ri-GBD-1 Installation Manual

Glass break detector
«Ri-GBD-1»
Installation guide
1 GENERAL INFORMATION
1.1 Glass break detector «Ri-GBD-1» (hereinafter referred to as the Detector)
detects the destruction of sheet glass and double-glazed windows blocks.
1.2 The Detector works as part of the smart home security system RiDom
and transmits the following notifications via radio channel to the «Ri-HUB-1»
control center (hereinafter referred to as the Hub):
- «Norm» - in absence of destructive effects on the secured glass;
- «Alarm» – upon detection of destructive effects on the secured glass;
- «Opening» – when the Detector case is opened;
- «Battery discharge» - when the battery supply voltage drops.
1.3 The Detector does not require a permit for purchasing and use and is not
subject to registration and licensing.
1.4 The Detector is resistant to electromagnetic interference.
1.5 The Detector is designed for continuous round-the-clock operation.
1.6 According to the number of detection zones, the Detector belongs to
two-zones type of the detectors.
2 FIELD OF APPLICATION
The Detector can be used in offices, shops, museums, showrooms, banks,
residential areas, etc.
3 SPECIFICATIONS
Table 1
Параметр
Frequency range
Radiation power
Maximum range, not less than:
- with the area of protected glass 0.1 m
- when the area of protected glass is more than 1 m
Viewing angle
Installation height, not less than
Battery type
Dimensions
Weight
The degree of protection provided by the shell
Average service life
Operational conditions
Operating temperature range
Relative air humidity at +25 °C
4 SCOPE OF SUPPLY
Table 2
Name
Glass break detector «Ri-GBD-1»
Lithium battery CR123A
Installation guide for the «Ri-GBD-1»
* Included
5 VIEW AND DESIGN
The Detector consists of a cover with a light window and a base (1) with a
printed circuit board (2).
The printed circuit board (2) is fixed on the base (1) with two screws (3).
The printed circuit board (2) contains: antenna (4), «RESET» jumper (5),
tamper sensor (6), two-color LED indicator (7), battery holder (8) and
microphone (9).
The base (1) has two mounting holes (10) for attaching the Detector to the
place of installation.
1
8
10
6
2
9
3
Picture 1 Top view with removed cover
–
Значение
868.7... 869.2 MHz
25 mW
; 6 m
2
9 m
2
120
о
2 m
(according to piсtuгes 4 - 8)
CR123A, 1 pc.
80x80x38 mm
0.1 kg
IP30
8 years
from -20 to +55 °C
up to 98%
7
10
LINE
RESET
3
4
5
6 INDICATION
The indication will automatically turn off 10 minutes after the lid is closed.
Open the case cover again to resume the indication.
Table 3
Detector status
«Normal»
«Obstruction»
«Alarm»
«Opening»
«Linking»
«Identification»
«Connection
quality»
7 CHOOSING PLACE OF INSTALLATION
Before installing the sensor, please read the following requirements:
- it is recommended to install the sensor at a height of at least 2 m (see
installation examples in figures 4-8);
- when choosing the installation location, take into account the radiation
pattern of the sensor (Figure 2);
Side view
90 о
- the distance (L) from the Detector to the most remote point of the secured
glass should not exceed 6 m;
- when operating together with an active ultrasonic detector, the distance
between them must be at least 1 m;
- all sections of the secured glass must be within the line of sight of the
Detector.
The Detector must be in the radio visibility zone of its Hub, so it is
recommended to evaluate the quality of communication with the Hub from
the place where the Detector is planned to be installed.
Do not install the Detector under the following conditions:
1. In close proximity to electrical wiring.
2. Near metal objects and mirrors that cause attenuation of the radio
signal or shield it.
3. Outdoors.
4. In rooms with temperature and humidity beyond the permissible values.
8 COONECTION TO THE SYSTEM
8.1 Open the RiDom application. In the My Devices tab, click
. Select the «Ri-GBD-1» detector from the list of devices and follow
Qty
the prompts of the application.
1 pc.
8.2 When prompted by the application, remove the battery isolator.
1 pc.* 8.3 The Detector will periodically turn on the green indicator; it shows that
it is in the «Linking» mode.
1 copy
8.4 Upon successful connection to the Hub, the indicator of the Detector
will turn red for 2-3 seconds, then you can see the Detector in the application,
as well as all the information about the Detector. Linking mode time is limited
to 100 seconds. To resume the «Linking» mode, it is necessary to briefly close
the «RESET» contacts.
8.5 Install the Detector case cover.
9 MOUNTING
Remove the case cover to install the Detector.
Having chosen the location for the installation of the Detector, make markings
for drilling the mounting holes. A base can be used for marking (see Figure 3).
Fix the base to the place of installation with screws.
Dimensions
(mm)
80
Indication
Off
Green LED is ON
Single red light for 3 seconds
See «Connection quality assessment»
Intermittent green light
Alternating red and green lights
See «Connection quality assessment»
L
Picture 2 – Detection zone
2 holes.
Ø 3,6
35
Picture 3 – Case base view
Notes
For the duration of the
interference
Registration of the sensor
in the Hub
The corresponding
command was received
from the hub
Top view
120 о
, and then
56
