RiDom Ri-DO-1 Installation Manual

Opening detector «Ri-DO-1»
Installation guide
1 GENERAL INFORMATION
1.1 The «Ri-DO-1» opening detector (hereinafter referred to as the
Detector) sends alarm notifications via a two-way radio channel in
accordance with the «Ri-Contact-R» protocol in case if windows, doors
and other structural elements where the Detector is installed are being
opened or moved and to shifted.
1.2 The Detector works as part of the RiDom smart home protection
system, communicating with the «Ri-HUB-1» control center (hereinafter
referred to as the Hub), which supports the «Ri-Contact-R» radio
channel exchange protocol.
1.3 Control of opening or displacement is carried out by the monitoring
of the status of the built-in reed switch.
1.4 The Detector does not require permission and registration as the
radio frequency device.
1.5 Two frequencies are used for the exchange of radio signals
between the Detector and the Hub - the main and the backup. The
transition to the backup frequency happens automatically.
1.6 The Detector generates and provides radio transmission of seven
types of notifications:
- the normal status;
- the alarm;
- the opening the case or removal from the place of installation;
- the battery discharge;
- the working in the «Linking» mode;
- the working in the «Identification» mode;
- the quality of communication.
1.7 The radio exchange is initiated by the Detector with a period of
10 s, 15 s, 30 s, 60 s, 2 min, 5 min, 10 min. The frequency of radio sessions
is set when configuring the Detector. Alarms and case opening
notifications are transmitted immediately.
1.8 The Detector is designed for continuous round-the-clock operation.
1.9 The Detector is resistant to electromagnetic interference.
2 SPECIFICATIONS
Table 1
Parameter
Frequency range
Radiation power, no more
Distance between sensor and magnet:
- to open the contacts of the reed switch
- to close the contacts of the reed switch
Standby mean time to failure
Protection class
Battery type
The duration of the sensor operation from one
battery under normal climate
conditions and with communication period of at
least 30 s
Dimensions
Weight
Average service life
Operational conditions
Operating temperature range
Permissible air humidity at a temperature
of +25 °C, without moisture condensation
3 SCOPE OF SUPPLY
Table 2
Name
Opening detector «Ri-DO-1»
Magnetic element
Pad 5 mm
Pad 9 mm
Screw 3-3x30.016
Lithium battery CR123A
Installation guide for the «Ri-DO-1»
* Included
circuit board (1) mounted inside. There are fixing holes for the convenient
mounting in the bottom (8) and on the side (9). The printed circuit board
contains: built-in reed switch (2), RESET contacts (3), tamper switch (4),
battery holder (5) and antenna (7).
built-in reed switch.
Hub);
appropriate command from the Hub and remains active for 15 minutes
or until the case is opened;
15 minutes after the case is closed in the absence of any other types
of indication, provided that during this time the «Tamper» notification
is not generated or the command is not transmitted from the Hub to
disable the indication.
Value
868,7...869,2 MHz
25 mW
More than 20 mm
Less than 5 mm
60 000 hrs
IP30
CR123A, 1 pc.
5 years
97х25х22 mm
reed switch.
50 g
8 years
-20... +55 С
о
Magnet
Up to 98 %
Pad
Qty.
1 pc.
1 pc.
When installing on metal surfaces, use the pads (included).
1 pc.
1 pc.
conductive material must be at least 10 mm.
4 pc.
1 pc.*
Detector and the magnet should not experience any mechanical
1 copy.
impacts (compressions, shocks, etc.).
4 VIEW AND DESIGN
The Detector consists of a case cover and a case base with a printed
A magnetic element (10) from the delivery set is used to control the
8
7
1
2
3
4
6
5
Picture 1 – «Ri-DO-1» view
5 INDICATION
The Detector generates the following types of indication:
- indication of the «Linking» mode (registration of the Detector in the
- indication «Identification» turns on
- indication of the sensor status turns on and remains active in the first
The LED indicating modes are shown in Table 3.
Table 3
LED status Indication
intermittent green indicator
«Linking»
Completion of
turning on the indicator light
«Linking»
in red for 2–3 s
alternating red and green
«Identification»
indicator light
single red indicator light with
«Alarm»
a period of 4 s
Connection
quality «Assessing the quality of communication»
«Normal»
6 CHOOSING THE PLACE OF INSTALLATION
6.1 The Detector should be installed indoors only.
6.2 The magnet should be places on the side of the Detector's built-in
a) with the pad
9 mm
5 mm
Picture 2 – Installation variants
6.3 It is not recommended to install the Detector on metal surfaces.
6.4 The distance from the Detector or magnet to the magnetically
6.5 In any acceptable positions of the controlled structure, the
10
upon the receipt of the
Notes
registration of the
light Detector in the Hub
the corresponding
command was recei-
ved from the Hub
Status indication is on
and «Identification»
indication is off
see the section
Off
b) without the pad
9
9
