- Page 1 User Manual TBZ1240 Conicdesigns.com...
-
Page 3: Table Of Contents
Tabla de Contenido Unpacking ..........................1 Fixture size ..........................2 Safety instructions ........................3 Operations Instructions ......................4 Mounting and Installation .....................4 DMX-512 control connections ....................6 DMX Channels ........................7 Key Features ........................10 Maintenance and Cleaning ....................11... -
Page 4: Unpacking
1. Unpacking Thank you for choosing our product. For your own safety, please read this manual before installing the device. This manual covers the important information on installation and applications. Please install and operate the fixture with following instructions. Meanwhile, please keep this manual well for future needs. -
Page 5: Fixture Size
2. Fixture size... -
Page 6: Safety Instructions
3. Safety Instructions This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. If the device has been exposed to temperature changes due to environmental changes, do not switch it on immediately. -
Page 7: Operations Instructions
4. Operation Instructions -The fixture is for beam effect purpose. -Don’t turn on the fixture if it’s been through severe temperature difference like after transportation because it might damage the light due to the environment changes. So make sure to operate the fix- ture until it is in normal temperature. - Page 8 Never stand directly below the device when mounting, removing, or servicing the fixture from a peri- odic safety inspection of all installation material and the fixture. If you lack these qualifications, do not attempt the installation yourself. Improper installation can result in bodily injury. Be sure to complete all rigging and installation procedures before connecting the main power cord to the appropriate wall outlet.
-
Page 9: Dmx-512 Control Connections
6. DMX-512 control connections Connect the provided XLR cable to the female 3-pin XLR output of your controller and the other side to the male 3-pin XLR input of the moving head. (5-pin connect way is similar) You can chain multiple Moving heads be connected together through serial linking. The cable needed should be two core, screened cable with XLR input and output connectors. -
Page 10: Dmx Channels
7. DMX Channels 56 channels... - Page 11 40 channels...
-
Page 13: Key Features
9. Key Features Voltage: AC110-240V 50/60Hz Max Power: 500 W Source: 12pcs 40W RGBW 4in1 led Beam degree: 1:7 zoom range from 5°-35 Tilt: 220 degree+ fine LED Lifetime: Average 50,000 hours Led: pixel control Strobe: 20 times one second Dimmer:0-100% linear dimmer Channel: 20/57 two channel mode Control mode: DMX-512,Auto-run, Sound activated Cooling system: fan forced cooling system Working environ- ment: indoor Net weight: 15 KG... -
Page 14: Maintenance And Cleaning
10. Maintenance and Cleaning The following points have to be considered during the inspection: All screws for installing the devices or parts of the device have to be tightly connected and must not be corroded. There must not be any deformations on the housing, color lenses, fixations and installation spots (ceiling, suspension, trussing).
