- Page 1 USER MANUAL CONIC LASER >L8IP 40W RGB...
-
Page 2: Table Of Contents
CONTENT 1. Safety Guidance................3 2. Packing List..................4 3. Installation Notes................4 4. Technical Parameter.................5 5. Light Control Panel................6 6. Light Setting..................7 6.1 TFT LCD display control panel function menu setting....8 7. Light Control Mode................. 11 8. -
Page 3: Safety Guidance
1. Safety Guidance Thank you for choosing our products. For your safety, please read this manual carefully before operation. This manual includes installation and use information. The equipment is packaged in good condition when leaving the factory. Please operate according to the user manual. The machine failure caused by man-made reasons is not covered by the warranty. -
Page 4: Packing List
maintain the light regularly. 12．Do not touch the wire when the light is running to prevent electric shock. 13．Avoid entanglement of the power cord with other wires. 14．Do not open the light housing without authorization 15．Please cut off the power when the light is not used for a long time or for maintenance. -
Page 5: Technical Parameter
2．Before installation, please confirm whether the power supply voltage you are using matches the voltage marked by the light. 3．Make sure that the ventilation fan and exhaust passage are not blocked by other equipment or decorative materials, such as newspapers, tablecloths, curtains, etc. -
Page 6: Light Control Panel
5. Light Control Panel Interface Function NO light/ normal light,The device system is in the dead Red indicating state light Flash : The equipment system is running normally No light or all light:The device system is in a dead Green state indicating... -
Page 7: Light Setting
Menu display window ▼DOWN Touch key-press MENU Touch key- press ▲UP Touch key-press ●ENTER Touch key-press SP21-ILDA AC22V Power Indicator 220V power input XLR DMX-512（IN/OUT） Fuse Ground 6. Light Setting Using the touch button and LCD menu display function, the menu operation is simple and easy to use, and the system software is automatically loaded when the system is turned on, and the main menu interface is displayed. -
Page 8: Tft Lcd Display Control Panel Function Menu Setting
TFT LCD display control panel function menu setting ,as following ： Secondary Third Menu Menu Menu （1-512） DMX add Channel 5/17/18/27/52CH Dmx mode Change according to the selected channel Value mode (such as 27CH channel value display 1-27) Scene effects, beam effects show Special effects, animation loops Animations can be played individually... - Page 9 customize the value of each channel of the fixture) size 0-255 X axis 0-255 Y axis 0-255 Project X invert ON/OFF setting Y invert ON/OFF Invert XY ON/OFF color RGB/One 0-255 green 0-255 color Advance blue 0-255 setting dimmer 0-255 scanner K number selection, the lower the K number, the more flashing the pattern...
- Page 10 setting screen ON/OFF 180° rotation of the screen， reverse Motor reset ON/OFF Reset reset ON/OFF factory settings setting X-axis reset ON/OFF error The X/Y scanner motor is stuck in a certain position and an error occurs, and the device Y-axis reset ON/OFF will not emit light in any mode...
-
Page 11: Light Control Mode
Animation Current device Animation effect effect house Current device house current device temp current device temp 7. Light Control mode ①, DMX512 control mode: 1. After setting the DMX512 address code, the lamp will receive the standard DMX512 signal 2. -
Page 12: Dmx512 Control
button to return to the previous menu. ⑤ 、User mode: You can control the numerical lamps of each channel of the lamps through the operation interface. 8. DMX512 Control 8.1DMX512 Connect In order to reduce signal errors and avoid signal weakening or interference... -
Page 13: Dmx512 Chanel Setting
during transmission, a 120Ω resistance loop can be inserted between the 2 cores and the 3 cores of the DMX output terminal of the last machine. Connect the lamp with XLR signal, one end is connected to the output port of the lamp, and the other end is connected to the input port of the next lamp. -
Page 14: Dmx512 Chanel Display
Connect the XLR control line from the DMX output port of the controller to the DMX input port of each fixture, and so on, until all the fixtures are connected, and then connect the loop plug to the signal output port of the last fixture. - Page 15 be selected in console mode → channel mode setting), the modes and descriptions are as follows: When CH1=32~63, all channels are valid; When CH1=64~95, CH2 and macro function effect selection are valid; Channel value Content 0 ~ 31 OFF (blackout) 32 ~ 63 Manual choose cue Cue mode...
- Page 16 17CH： Channel Content OFF（ Blackout ） 0 ~31 32 ~63 Manual choose cue Cue mode 64 ~95 Auto trigger macro function 96 ~127 Sound trigger macro function 128 ~255 Reserved dimmer 0 ~255 0%- 100% 0 ~255 0%- 100% green 0 ~255 0%- 100%...
- Page 17 16 ~23 24 ~31 yellow 32 ~39 green 40 ~47 cyan 48 ~55 blue 56 ~63 purple 64 ~127 Each 8 value be 1 color effect, 8 effects total 128 ~143 Macro 1 144 ~159 Macro 2 160 ~175 macro 3 176 ~191 macro 4...
- Page 18 18CH Channel Content OFF（ Blackout ） 0 ~31 32 ~63 Manual choose cue Cue mode 64 ~95 Auto trigger macro function 96 ~127 Sound trigger macro function 128 ~255 Reserved dimmer 0 ~255 0%- 100% List List :each 32 value be 1 list, 8 lists (CH1: 32 ~ 63) total.
- Page 19 128 ~143 macro 1 144 ~159 macro 2 160 ~175 macro 3 176 ~191 macro 4 192 ~207 macro 5 208 ~223 macro 6 224 ~239 macro 7 240 ~255 macro 8 0 ~15 invalid 16~31 Each 15 value be 1 macro effect, total Deformation CH11 13 effects,（match CH7, CH16 zoom）...
- Page 20 161 ~192 macro 6 193 ~224 macro 7 225 ~255 macro 8 invalid 1 ~32 macro 1 33 ~64 macro 2 65 ~96 macro 3 97 ~128 macro 4 129 ~160 macro 5 CH16 Zoom 161 ~192 macro 6 193 ~224 macro 7 225 ~255...
- Page 21 27CH and 52CH Channel Content Channel value 27CH 27CH single pattern，52CH double 52CH pattern Blackout(off 0～31 Manual 32～63 play 64～95 Auto play macro function 95～255 Invali Dimmer Brightness 0% ～ 0～255 100% Red brightness 0% ～ CH28 0～255 100% Green brightness 0% ～...
- Page 22 CH40 CH15 0～255 From left to right (X rotation) CH41 CH16 0～255 From bottom to top(Y rotation) Choose color 0～7 Default color 8～ 7 pcs different color 64～127 Each 8 value be one effect，total 8 effect 128～143 Macro function 144～159 Macro function 2 CH42...
- Page 23 Macro Macro Macro 1～42 43～84 85～126 function function function 3 127～ Strobe mode( from slow to fast) X horizontal position ( when value=0 Invalid ) Macro Macro Invalid 1～32 33～64 function function 2 CH47 CH22 Macro Macro Macro 65～96 97～128 129～...
-
Page 24: Maintenance
function function 2 Macro Macro Macro 65～96 97～128 129～ function function function 5 Macro Macro Macro 161～ 193～ 225～ function function function 8 X Rotation ( when value=0 Invalid ) Macro Macro Invalid 1～32 33～64 function function 2 Macro Macro Macro CH51... -
Page 25: Warning And Declaration
2. Cooling fan cleaning: Use compressed air to clean the fan of the device. The fan position plays a vital role in the normal operation of the device. Please ensure the normal operation of the fan. 3. When the equipment is used frequently, the fan should be cleaned every 1 month, or in a dusty and oily environment, the number of cleanings should be increased. - Page 26 Product common breakdown comparative chart breakdown cause Major breakdown analysis and solution 1. Check the power cable whether to connect the light,whether the fuse does burn out The light no emitting 2. Check the input voltage whether to assign the voltage or no work match with the light.
- Page 27 reduced 2.Check whether the internal and external optical system is clean. If the fault cannot be eliminated according to the above method, please contact with dealer.
