- Page 1 USER MANUAL LB612FC LASER BAR FULL COLOR...
-
Page 2: Checking Parts
LB612FC LASER BAR FULL COLOR Professional Stage Lights Introduction Thank you for purchasing this product. To ensure proper operation, please read this manual carefully before using the product. After reading it, keep it in a safe place for future reference. -
Page 3: Installation
1 x Light 1 x Power cable 1 x User manual Danger Light Radiation! Avoid direct eye exposure! Light radiation can cause eye damage or skin damage All protective measures for a safe operation of this light must be applied. Installation 1. -
Page 4: Mode Select
7. Please keep that there's no other equipment or decorating materials obstructed the exhaust fan and the vent-pipe when the equipment was working. 8. Before connect power, check the plug is immobility or not, power cable should be connect well. 9. - Page 5 Slave 2 Auto 0-16 Auto Run mode Speed 0-9 Sound mode Show 0-16 Sound sense 0-100 Back lights On/Off Pan Inverse Yes/No Tilt Inverse Yes/No Auto Test Test Fixture Time 0-9999 Software Version Version Motor Reset Yes/No Default Reset DMX Setting Input DMX signal, DMX daisy chain picture as follow DMX control, each light should has its own address.
-
Page 6: Master-Slave Setting
Number Address LCD display(No.) 15 or 36 or 43 015 or 036 or 043 29 or 71 or 85 029 or 071 or 085 ┇ ┇ ┇ Master-slave Setting Link the lights as the following picture (the light which does not receive signal, only output signal, will be the master light)，... -
Page 7: Technical Specifications
1.Input rated voltage 2.Fuse 3.Power switch button 4.Ground marking 5.DMX IN/ DMX OUT: DMX signal output and input Technical Specifications 1.Power Supply: AC100~240V 50/60Hz 2.Rated Power: 250W 3.light color: □W2000C（R500mW+G500mW+B1000Mw)*6 □W500C(R200Mw+G100Mw+B200Mw)*6 4.Y axis rotation angle: 0-240° 5.Z axis rotation angle: 0-140° 6.Working Mode: Sound/Automatic/DMX512/Master-Slave 7.Auto mode: 16 kinds of automatic dynamic effect/ 16 kinds of sound trigger dynamic effect... - Page 8 DMX-512 Channel Introduction 35CH / 42CH mode as following Channel Value Function 000-007 Black, motor controllable 008-255 001-255 Strobe（speed from slow to fast） 000-007 Invalid 008-247 Each 14 value be one Y/Z axis macro effect, total 16 effects (motor controllable) 248-255 Sound trigger（motor controllable）...
- Page 9 Y, Z axis rotation speed（only valid CH10 CH11 001-255 CH7/CH9） CH11 CH12 001-255 light 1 Z axis rotation CH13 001-255 light 1 Z axis fine rotation CH12 CH14 001-255 light 1 Red on/off CH13 CH15 001-255 light 1 Green on/off CH14 CH16 001-255...
- Page 10 CH30 CH36 001-255 light 5 Blue on/off CH31 CH37 001-255 light 6 Z axis rotation CH38 001-255 light 6 Z axis fine rotation CH32 CH39 001-255 light 6 Red on/off CH33 CH40 001-255 light 6 Blue on/off CH34 CH41 001-255 light 6 Green on/off 000-128 Invalid...
-
Page 11: Maintenance
Black，motor controllable 000-007 (CH10\CH11\CH12\CH13\CH14) 008-255 CH2-CH14 on 000-255 Red brightness ( 0% - 100%) 000-255 Green brightness ( 0% - 100%) 000-255 Blue brightness ( 0% - 100%) 001-255 Strobe （slow - fast） 000-007 Invalid 008-247 Each 14 value be one Y/Z axis macro effect , total 16 effects（motor controllable）... - Page 12 Maintenance should be performed every 15day period, by using a sponge which is dipped with alcohol, rather than wet cloth or other chemical liquid, to clean the mirror. Always disconnect from the power when the device is not in use or before cleaning it.
- Page 13 1. Check the address or the display whether No sound control establishes according to the instruction booklet is the sound trigger mode. 1.Please check the fixture DMX address setting The fixture can bright correctly or not. normally, but it not 2.
