KoamTac KDC80 Mini-Manual

What's in the Box?
• KDC80 • Protective Rubber Boot
• USB Type-C Cable • Mini Guide
• KDC Lanyard • KOAMTACON Guide
Basic Operation
Press the SCAN button. HID inputs data directly into an application.
SPP requires the KOAMTAC KTSync® app or integration of the
KOAMTAC SDK to input data into an application.
A successful scan (A) will sound 1 beep, show a green LED, and
display the scanned info on the screen. An unsuccessful scan
(B) will sound 5 beeps, show a red LED, and display "Read
Failed" on the screen.
Powering On/Off
To power on the KDC80, press and hold the SCAN and DOWN
buttons for 3 seconds.
To power off the KDC80, press and hold the SCAN and DOWN
buttons for 3 seconds again.
Bluetooth Profiles Explained
Allows one-way Bluetooth communication with
an Android or iOS host device. The KDC only
transmits data to the host device.
Allows two-way Bluetooth communication. The
KDC transmits data to the host device and the
host can transmit data back to the KDC.
Allows one-way Bluetooth communication with a
Windows PC. The KDC only transmits data to the
Windows PC.
HID inputs data directly into an application. SPP requires the
KOAMTAC KTSync® app or integration of the KOAMTAC SDK to
input data into an application.
Additional Accessories
• Type-C USB Cable • Protective Rubber Boot
• KBLED50 BLE Dongle
KDC80 Models
• KDC80L 1D Laser Bluetooth Barcode Scanner & Data Collector
• KDC80D 1D CCD Bluetooth Barcode Scanner & Data Collector
100 Village Blvd Ste 300, Princeton, NJ 08540
Pairing & Connecting
1. Navigate to the Bluetooth setting on the host PC, Mac,
Smartphone, or Tablet.
2. Ensure that Bluetooth is enabled on the host device and
searching for devices.
3. Using the KDC, scan the pairing barcode that corresponds to
your desired Bluetooth profile. If you are unsure which Bluetooth
profile is right for you, please refer to previous panel.
4. Check the list of available Bluetooth devices on your host
device. In iOS, the application will need to search devices.
5. From the list, select the KDC80 listed by serial number in
brackets that matches the serial number found on the back side
of the KDC80.
6. In HID Mode, KDC80 is ready to use.
7. To complete connection in SPP Mode, launch KTSync or your
application and select KDC80 to connect.
KDC80
Mini Guide
Pairing Barcodes
HID
HID Windows
SPP
