- Page 1 SBC-472-TS570-2 Industrial Single Board Computer with ® 11th Gen. Intel Core™ Processor Product Manual WINSYSTEMS, Inc. | 2890 112th Street, Grand Prairie, Texas 75050 | 817-274-7553 | info@winsystems.com | www.winsystems.com...
- Page 2 WINSYSTEMS, Inc. The information in the document is subject to change without notice. The information furnished by WINSYSTEMS, Inc. in this publication is believed to be accurate and reliable. However, WINSYSTEMS, Inc. makes no warranty,...
-
Page 3: Table Of Contents
SBC-472-TS570-2 Table of Contents Before You Begin........... 3 1.1 Warnings . - Page 4 SBC-472-TS570-2 9.16 LVDS Video [P13] [J3] ...........23 9.17 External SATA Ports [P17A, P17B] [P6, P7] .
-
Page 5: Before You Begin
ESD seal on the product bag is broken. 2. Introduction This manual provides configuration and usage information for the SBC-472-TS570-2. If you still have questions, contact Technical Support at +1-817-274-7553, Monday through Friday, between 8 AM and 5 PM Central Standard Time (CST). - Page 6 BIOS settings and layout, or request a custom branded configurable BIOS to support specific project requirements. The SBC-472-TS570-2 supports Microsoft® Windows 11 IoT Enterprise Microsoft® Windows 10 IoT Enterprise and Linux (Ubuntu) operating systems. Drivers are available from the WINSYSTEMS website at http://www.winsystems.com.
-
Page 7: Product Features And Specifications
SBC-472-TS570-2/Product Features and Specifications 4. Product Features and Specifications Carrier Board Features and Specifications Compatibility COM Express Type 6 Modules PICMG COM Express® COM.0 R2.0 Processor Intel® Xeon® W-11155MRE 4-core processor with 2.4GHz base frequency. Up to 4.4GHz on turbo boost. -
Page 8: Part Numbers / Ordering Information
SBC-472-TS570-2/Part Numbers / Ordering Information Carrier Board Features and Specifications I/0 Connectors All low-profile shrouded locking ruggedized 2mm pitch headers. Can be mated to panel mountable cable set or MIL type connectors. Mechanical 125mm x 95mm x 52.03mm (x-y-z dims) -
Page 9: Product Overview
SBC-472-TS570-2/Product Overview 6. Product Overview 6.1 Block Diagram Optional Optional v1.0 www.winsystems.com Page 7... -
Page 10: Connector Locations
SBC-472-TS570-2/Connector Locations 7. Connector Locations This section describes the SBC-472-TS570-2 components and configuration. Carrier Top View GPIO Console Serial RS-232 RS-422/485 Ports 0-1 Ports 3-4 LVDS LVDS POWER Jumpers SATA-1 mini PCIe/mSATA Slot 0 USB2.0 SATA-0 Ports 0-1 MULTI Jumper Block... - Page 11 SBC-472-TS570-2/Connector Locations COM Bottom View SODIMM Sockets Carrier Bottom View (Showing Options Below) micro SD Card Slot SIM Card Socket for mini PCIe/mSATA (See NOTE Below) NOTE SIM’s Card option requires a WAN interface controller card that allows the device to connect to a wide area network.
-
Page 12: Carrier Jumper And Connector Summary
SBC-472-TS570-2/Carrier Jumper and Connector Summary 8. Carrier Jumper and Connector Summary Item Description Reference Display Port page 11 USB 2.0 Ports 0, 1 page 12 USB 2.0 Ports 2,3 Micro SD card (Optional) page 13 +12VDC Power In page 14... -
Page 13: Detailed Feature Pinouts And Descriptions
9. Detailed Feature Pinouts and Descriptions 9.1 DisplayPort ++ Video [P2A,P2B] The SBC-472-TS570-2 Carrier features two DisplayPort++ connectors. This can be configured to output Display Port and HDMI/DVI. The configuration of each interface is setup via the COM Express module's BIOS settings. -
Page 14: Hdmi / Dvi / Vga From Displayport
Winsystems. 9.3 USB 2.0 Ports [P3A,P3B] The SBC-472-TS570-2 board houses 4 x USB 2.0 ports on 20-pin headers and 2 x USB 2.0 ports on 8-pin headers. Below is a description of the 20-pin USB 2.0 headers on the CCGOl 1 carrier. -
Page 15: Microsd Card [P4] (Optional)
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.4 MicroSD Card [P4] (Optional) The SBC-472-TS570-2 provides a Micro SD Card Slot at P4. This Micro SD Card slot sources the SDIO interface from the COM Express modules GPIO pins. NOTE This SD card slot will ONLY operate if the COM Express module provides the SDIO interface over the GPIO pins. -
Page 16: Input Power [P5]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.5 Input Power [P5] The SBC-472-TS570-2 is designed to be powered from a regulated single +12VDC power supply. The carrier board features a 5mm screw terminal style connector. The COM Express carrier generates all of the necessary voltages on board from this single input. -
Page 17: Rtc Battery [J1, J2]
Clear CMOS 9.7 Asynchronous Serial Ports [P8, P1O] The SBC-472-TS570-2 features four “external” serials ports. Portl and Port2 are standard RS-232 and Port3 and Port4 can be configured as RS-422/485. These serial ports are generated from on-board PCie 4-port UART the Exar 17V358 9.8 Software Support for the Exar 17V358... -
Page 18: Serial Connector Rs-232 [P8]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.9 Serial Connector RS-232 [P8] Function RS232 Serial Location Type FCI 98424-G52-20LF, 2x10 Pinout Description Description Port A, DCD Port A, DSR Port A, RXD Port A, RTS Port A, TXD Port A, CTS Port A, DTR... -
Page 19: Rs485 Control Jumpers
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.11 RS485 Control Jumpers The RS485 Control Jumpers are used for implementing the following RS485 modes of operations: • 1/2 Duplex Multidrop • Full Duplex Multidrop The UART RTS signals can used for TX/RX control and can be enable via the MULTI jumper block. -
Page 20: Gpio And Console Serial Port [P9]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.12 GPIO and Console Serial Port [P9] The SBC-472-TS570-2 provides additional functionality of COM Express Type-6 specification. Function Console RS-232 / GPIO Location Type FCI 98424-G52-20LF Pinout Description Description GPIO Input 0 GPIO Output 3... -
Page 21: Vga Video [P11]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.13 VGA Video [P11] The COM Express Ultra-Lite carrier provides additional functionality of COM Express Type-6 specification. Function Console RS-232 / GPIO Location Type FCI 98424-G52-20LF Pinout Description Description GPIO Input 0 GPIO Output 3... -
Page 22: Minipcie & Msata Slots [P12A, P12B]
9.14 miniPCIe & mSATA Slots [P12A, P12B] Dual Function miniPCIe mSATA Slots The SBC-472-TS570-2 has two special dual purpose functionality mini PCIe / mSATA slots. Each of these slots can accept either a mini PCIe module or a mSATA SSD module. These slots have special circuitry that allows for the selection between connecting PCIe lanes or SATA lanes. -
Page 23: Half And Full Length Mini Pcie/Msata Installation [P12A, P12B] [P15A, P15B]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.15 Half and Full Length mini PCIe/mSATA Installation [P12A, P12B] [P15A, P15B] The SBC-472-TS570-2 comes with its latches in the full length position. Function mini PCle / mSATA Slots Location P12A, P12B Type Standard miniPCle Slots v1.0... - Page 24 SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions Position v1.0 www.winsystems.com Page 22...
-
Page 25: Lvds Video [P13] [J3]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.16 LVDS Video [P13] [J3] Function LVDS Video Location Type Hirose DF20G-40DP-1V(56) Pinout v1.0 www.winsystems.com Page 23... - Page 26 SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions The LVDS Panel VCC voltage is selected via the J3 jumper block. The current is limited to 1.5A Function LVDS Panel VCC voltage Location Type Pinout Location Description 3.3V v1.0 www.winsystems.com Page 24...
-
Page 27: External Sata Ports [P17A, P17B] [P6, P7]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.17 External SATA Ports [P17A, P17B] [P6, P7] The SBC-472-TS570-2 provides two SAT A HDD connections as well as external power connectors for each drive. Function SATA host Location P17A- SATA- 0 Type P17B - SATA-1... -
Page 28: Cpu Fan [P18]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.18 CPU Fan [P18] Function Fan Power Locations Type Molex 22-23-2031 Pinout Signal Fan Tach 9.19 Miscellaneous Control [P19] This misc header can be used to connect power button, reset button, PC speaker, I2C device and monitor other power rails. As well it provides the option of jumping the +5V rail to the +5VSB rail which may be needed by some modules. -
Page 29: Sim Socket [P20] (Optional)
9.20 SIM Socket [P20] (Optional) Function SIM Socket Location Type Molex 0475530001 Pinout 9.21 Audio Interface [P21] The SBC-472-TS570-2 features HD Audio capabilities. 1 input (microphone) and 1 output (headphone) are available. Function Audio Connector Location Type FCI 98414-G06-08LF, 2x4 2mm Pinout... -
Page 30: Usb 2.0 Ports [P22]
SBC-472-TS570-2/Detailed Feature Pinouts and Descriptions 9.22 USB 2.0 Ports [P22] The SBC-472-TS570-2 has 6 external USB 2.0 ports. Each of these are directly sourced from the COM Express Type 6 module and do not go through any external hubs or bridges. -
Page 31: Software Support For The Intel 82574
+Controller 9.25 Multifunction Jumper Block [P23] The SBC-472-TS570-2 has a multi-function jumper that provides control for various interfaces and features. The "MULTI" jumper is located at P23. Below are the full details of the MULTI jumper block functionality. Position... -
Page 32: Typical Hardware Installation For +12V Power Input
SBC-472-TS570-2/Typical Hardware Installation for +12V power input 10. Typical Hardware Installation for +12V power input 15. Ensure all external system power supplies are off. 16. Install the necessary cables for the application. At a minimum, this would include: a) + 12V Power cable to the input power connector. -
Page 33: Pci Express Allocation Details
SBC-472-TS570-2/PCI Express Allocation Details 12. PCI Express Allocation Details Below is a listing of how the PCI Express Links are allocated on the carrier board. COM Express PCI Express Link Peripheral Connection PCle x1 -0 PCle UART (Exar 17V354) PCle x1 -1... -
Page 34: Best Practices
SBC-472-TS570-2/Best Practices Appendix D. Best Practices The following paragraphs outline the best practices for operating the SBC-472-TS570-2 in a safe, effective manner, that does not damage the board. Read this section carefully. Power Supply Avoid Electrostatic Discharge (ESD) Only handle the circuit board and other bare electronics when electrostatic discharge (ESD) protection is in place. -
Page 35: Power Down
Power Supply OFF—Always turn off the power supply before connecting to the embedded system. Do not hot-plug the SBC-472-TS570-2 on a host carrier board that is already powered. I/O Connections OFF—Turn off all I/O connections before connecting them to the embedded computer modules or any I/O cards. -
Page 36: Conformal Coating
Conformal Coating Applying conformal coating to a WINSYSTEMS product does not in itself void the product warranty, if it is properly removed prior to return. Coating can change thermal characteristics and impedes our ability to test, diagnose, and repair products. -
Page 37: Mechanical Drawings
SBC-472-TS570-2/Mechanical Drawings Appendix E. Mechanical Drawings SBC-472-TS570-2 v1.0 www.winsystems.com Page 35... - Page 38 SBC-472-TS570-2/Mechanical Drawings v1.0 www.winsystems.com Page 36...
-
Page 39: Warranty Information
Products or licensing of Software hereunder. In the event this Order is placed in the hands of an attorney or collection agency by WINSYSTEMS to collect any sums due hereunder to WINSYSTEMS, Customer shall pay all reasonable attorney's fees, expenses, collection and court costs incurred by WINSYSTEMS.
