Summary of Contents for WinSystems ITX-P-3800
- Page 1 ITX-P-3800 Pico-ITX Intel ® Atom™ E3800 Single Board Computer with Dual 10/100/1000 Ethernet, LVDS, Touchscreen, USB, COM Product Manual WinSystems, Inc. | 715 Stadium Drive, Arlington, Texas 76011 | 817-274-7553 | info@winsystems.com | www.winsystems.com...
- Page 2 No part of this document may be copied or reproduced in any form or by any means without the prior written consent of WinSystems, Inc. The information in the document is subject to change without notice. The information furnished by WinSystems, Inc. in this publication is believed to be accurate and reliable.
-
Page 3: Table Of Contents
ITX-P-3800 Table of Contents Before You Begin ......... 5 Warnings . - Page 4 ITX-P-3800 7.4.21 eDP1 - eDP Interface ........... . 27 7.4.22...
-
Page 5: Before You Begin
Practices” on page 46) when using and handling the WinSystems ITX-P-3800. Following these recommendations provides an optimal user experience and prevents damage. Read through this document and become familiar with the ITX-P-3800 before proceeding. FAILING TO COMPLY WITH THESE BEST PRACTICES MAY DAMAGE THE ITX-P-3800 AND VOID YOUR WARRANTY. -
Page 6: Features
ITX-P-3800 a great choice for small human machine interface (HMI) applications. Considering the small size of the ITX-P-3800, it is packed with I/O features often lacking from larger single board computers. It includes dual 10/100/1000 Ethernet controllers based on the Intel i211 family with wake on LAN and PXE capabilities, connectivity and controlling network devices. - Page 7 ITX-P-3800/Features Graphics • Intel Gen7 HD Graphics for Intel Atom processor • Fast graphics at high resolutions • Full-HD and 3D graphics acceleration BIOS • Insyde UEFI BIOS Video Interfaces • • 24/48-bit LVDS • Dual eDP Ethernet • Two Intel 10/100/1000 Mbps controllers using Intel i211-AT Storage •...
-
Page 8: General Operation
Watchdog timer, 0~255 sec programmable General Operation System Block Diagram The ITX-P-3800 Pico-ITX single-board computer (SBC) with dual Ethernet provides performance for industrial IoT applications and rugged design for demanding environments with fast, high-resolution graphics, secure data, embedded connectivity, and expansion options. The following figure is a simplified system block diagram of the ITX-P-3800. - Page 9 ITX-P-3800/General Operation The ITX-P-3800 features the Intel Atom (Bay Trail) dual core or quad core system on chip (SOC). Its robust design, small size, and extended operational temperature make it ideal for use in industrial IoT applications and embedded systems for industrial controls, transportation, Mil/COTS, and energy markets.
-
Page 10: Specifications
ITX-P-3800/Specifications Specifications The ITX-P-3800 adheres to the following specifications and requirements. Table 1: ITX-P-3800 specifications Electrical Supports a wide range DC input of 9V to 36V Models ITX-P-38XX-M-0 Processor Dual and quad core Intel Atom (formerly Bay Trail-I) E3800 series processor •... -
Page 11: Configuration
ITX-P-3800/Configuration Configuration This section describes the ITX-P-3800 components and configuration. Component Layout 7.1.1 Top View LVDS1 LVDS 18/24 bits Wide voltage 9V-36V PWROUT Voltage output +12V/+5V Mini Card JVL1 Panel PCIe/mSATA auto power for LVDS detect USB/I EDP1 eDP 2Lanes... -
Page 12: Watchdog Timer (Wdt)
WinSystems supports the ITX-P-3800 WDT in the System Management tools for the ITX-P-3800. Ask your sales representative for details of this software package. -
Page 13: Real-Time Clock/Calendar
CMOS RAM contained within the clock section. A battery must be enabled for the real-time clock to retain time and date during a power down. WinSystems has software available for manipulating the CMOS RTC from a high-level application. Connectors 7.4.1 PWR - DC Power Input... -
Page 14: Exbatt - External Battery Power-In
ITX-P-3800/Configuration 7.4.3 EXBATT - External Battery Power-In EXBATT: External battery 1x2 pin (1.25 mm) connector Layout and Pin Reference pin 1 Description Matching Connectors • Molex 053047-0210 Cable Housing • Molex 51021-0200 7.4.4 PWROUT - DC+12V/+5 Voltage Power Output PWROUT: +12V/+5V DC voltage output 4 pin (2.0 mm) connector... -
Page 15: Fph - Front Panel Pin Header
ITX-P-3800/Configuration 7.4.5 FPH - Front Panel Pin Header FPH: Front panel header 2x5 pin (2.0 mm) connector Layout and Pin Reference pin 1 Description Description Power button pin Power button GND Reset pin Reset GND Power LED- Power LED+ HDD LED-... -
Page 16: Lvds1 - Lvds Connector
ITX-P-3800/Configuration 7.4.6 LVDS1 - LVDS Connector LVDS1: LVDS 2x15 pin (1.25 mm) connector Layout and Pin Reference LVDS1 Description Description PWM dimming +LCD (5V or 3.3V) +LCD (5V or 3.3V) Channel-1-DATA3+ Channel-0-DATA3+ Channel-1-DATA3- Channel-0-DATA3- pin 1 Channel-0-DATA2+ Channel-0-CLK+ Channel-0-DATA2- Channel-0-CLK-... -
Page 17: Bklt - Backlight Panel Power
ITX-P-3800/Configuration 7.4.7 BKLT - Backlight Panel Power BKLT: Backlight power 5-pin (2.0 mm) connector Layout and Pin Reference pin 1 Description +12V PWM dimming ENBKL (3.3V) ENBKL (5V) Note: Pin 3 back light dimming controls, provided 200 Hz / 275 Hz / 380Hz / 20 kHz / 25 kHz /100 Hz and adjust PWM duty cycle by software program. - Page 18 ITX-P-3800/Configuration 8-wire type pin define Description Description Bottom Bottom sense Top sense Right Right sense Left Left sense Note: To configure for 8-wire touch setup, short pins 3 and 4 together. 4-wire type pin define Description Description Bottom Right Left Note: To configure for 4-wire touch setup, short pins 3 and 4 together.
-
Page 19: Audio - Audio Interface
ITX-P-3800/Configuration 7.4.9 AUDIO - Audio Interface AUDIO: Line-out/line-in/mic-in/SPDIF-out 2x5 pin (2.0 mm) connector Layout and Pin Reference pin 1 Description Description Line-out-R MIC-IN Line-in-R SPDIF-OUT Line-in-L Line-out-L MIC-IN Matching Connectors • JST B10B-PHDSS Cable Housing • JST PHDR-10VS 7.4.10 AMP - Audio Amplifier AMP: Amplifier line-out right/left channel 4-pin (1.25 mm) connector... -
Page 20: Com1-Com4 - Com Interface
ITX-P-3800/Configuration Cable Housing • Molex 51021-0400 7.4.11 COM1-COM4 - COM Interface COM1-COM4: 2x5 pin (2.0 mm) connector (RS232 mode) Layout and Pin Reference pin 1 Description Description Matching Connectors • JST B10B-PHDSS Cable Housing • JST PHDR-10VS 7.4.12 VGA - Analog VGA Display VGA: Analog VGA 2x5 pin (2.0 mm) connector... -
Page 21: Dio - Digital Input/Output
ITX-P-3800/Configuration Matching Connectors • JST B10B-PHDSS Cable Housing • JST PHDR-10VS 7.4.13 DIO - Digital Input/Output DIO: DIO 0-3 2x5 pin (2.0 mm) connector Layout and Pin Reference pin 1 Description Description DI-0 DO-3 DI-1 DO-2 DI-2 DO-1 DI-3 DO-0 Notes: 1. -
Page 22: I2C - I2C Interface
ITX-P-3800/Configuration 7.4.14 I2C - I2C Interface I2C: I C 4-pin (1.25 mm) connector Layout and Pin Reference pin 1 Description +3.3V C clock C DATA Matching Connectors • Molex 53047-0410 Cable Housing • Molex 51021-0400 7.4.15 LAN1/LAN2 - LAN 10/100/1000 Ethernet Interface LAN1: Ethernet port 2x4 pin (2.0 mm) connector... -
Page 23: Led1/Led2 - Ethernet Leds
ITX-P-3800/Configuration LED1/LED2 - 10/100/1000 Ethernet LED Speed 10 Mbps 100 Mbps 1000 Mbps Indicate Side Back Front Back Front Back Front Link Link Link LAN light Orange Orange Orange Green Orange Orange Orange Orange Matching Connectors • JST B8B-PHDSS Cable Housing •... - Page 24 ITX-P-3800/Configuration USB5: USB 3.1 Gen 1 port 1x5 pin (1.25 mm) connector USB6: USB 2.0 port 1x4 pin (1.25 mm) connector Layout and Pin Reference USB1, 2, 3, 4, 6: USB 2.0 port 1x4 pin (1.25 mm) connector pin 1...
-
Page 25: Sata1 - Serial Ata Interface
ITX-P-3800/Configuration 7.4.18 SATA1 - Serial ATA Interface SATA1: SATA port 1x7 pin connector Layout and Pin Reference Description Notes: 1. SATA1 supports SATA 2.0 (3 Gb/sec.). 2. PWROUT provides SATA HDD power +12V, GND, +5V. 3. SATA1 and MC1 share the same SATA channel. Only one can be used at a time. -
Page 26: Mc1/Mc2 - Pci Express Mini Card
ITX-P-3800/Configuration Matching Connectors • Molex 53047-0610 Cable Housing • Molex 51021-0600 7.4.20 MC1/MC2 - PCI Express Mini Card • MC1: Full-size Mini Card port 1 (PCIe/mSATA, USB) • MC2: Half-size Mini Card port 2 (mSATA, USB) Layout and Pin Reference... -
Page 27: Edp1 - Edp Interface
ITX-P-3800/Configuration 7.4.21 eDP1 - eDP Interface eDP1: eDP 2x10 pin (1.25 mm) connector Layout and Pin Reference eDP1 Description Description Lane-0-DATA- +12V or +5V Lane-0-DATA+ +12V or +5V Lane-1-DATA- pin 1 Lane-1-DATA+ Backlight enable PWM dimming for C data +LCD (5V or 3.3V) C clock +LCD (5V or 3.3V) -
Page 28: Additional Information
To install a mini PCIe/mSATA into MC1 or MC2: 1. Insert the mini PCIe/mSATA. 2. Push the free end of the card toward the circuit board and then secure it with two (2 mm) screws (WinSystems P/N G527-0000-400). Jumpers 7.5.1 JCMOS - CMOS Data Clear Jumpers can be used to reset the BIOS CMOS settings to the factory default. -
Page 29: Jvl1 - Lcd Panel Power Select
ITX-P-3800/Configuration NOTE Do not clear the CMOS except in these circumstances: 1) Troubleshooting; 2) Forgotten password; 3) You fail over-clocking system. Layout and Pin Reference *Normal Clear Description *1-2 Normal set CMOS data clear 7.5.2 JVL1 - LCD Panel Power Select Select the appropriate VCC setting using this jumper. -
Page 30: Bios Functionality
BIOS Functionality General Information The ITX-P-3800 includes a UEFI BIOS from Insyde stored in Flash ROM. Access setup information through the BIOS setup utility to modify basic system configuration. The configuration is stored in CMOS RAM (it is retained during power off). When power is... -
Page 31: Bios Screens
ITX-P-3800/BIOS Functionality BIOS Screens The following BIOS screens contain the options and sample settings for the ITX-P-3800. Your actual configuration may differ from the screens shown here. NOTE Use care when modifying BIOS settings. 8.4.1 Main Menu The Main page of the BIOS displays general information related to the current BIOS build, including the BIOS revision, the build date and time, and processor type. -
Page 32: Advanced Menu
ITX-P-3800/BIOS Functionality – System Memory Speed, value 1066 MHz or 1333 MHz – L2 Cache RAM, value 2048 KB – Total Memory, value up to 4096 MB • System Time. Displays the current time in HH/MM/SS format. To set or change the... - Page 33 ITX-P-3800/BIOS Functionality PCI Express Configuration • Control the PCI Express Root Port for ports 1, 2, 3, and 4. Options are Enabled (default), Disabled. • Select PCI Express Port Speed. Options are Gen1 (default), Gen2. • Select PCIE TXE ROM support. Options are Disabled (default), Enabled.
- Page 34 ITX-P-3800/BIOS Functionality • IGD - DVMT Pre-Allocated. Use this item to select DVMT 5.0 total graphics mem- ory size used by the internal graphics device. Options are 64 (default), 96, 128, 160, 192, 224, 256, 288, 320, 352, 384, 416, 448, 480, 512MB.
-
Page 35: Security Menu
ITX-P-3800/BIOS Functionality 8.4.3 Security Menu Supervisor Password To set up a supervisor password: 1. Select Set Supervisor Password. A Create New Password dialog opens. 2. Type your desired password using no fewer than 3 characters and no more than 10 characters. -
Page 36: Power Menu
ITX-P-3800/BIOS Functionality 8.4.4 Power Menu • Wake on LAN. Determines the action taken when the system power is off and the PCI power management Enable wake up event occurs. Options are Enabled, Dis- abled (default). • Power Button. Options are: –... -
Page 37: Boot Menu
ITX-P-3800/BIOS Functionality 8.4.5 Boot Menu • Boot Type. Options are Dual type (default), Legacy boot type, UEFI boot type. • Quiet Boot. Options are Enabled (default), Disabled. • EFI/Legacy Device order. Determine whether the EFI device boots first or the leg- acy device. -
Page 38: Exit Menu
ITX-P-3800/BIOS Functionality 8.4.6 Exit Menu • Exit Saving Changes. This item allows the user to reset the system after saving the changes. • Save Change Without Exit. This item allows the user to save the changes, but doesn’t restart. •... -
Page 39: Super I/O Settings
ITX-P-3800/BIOS Functionality Super I/O Settings Press the F10 key during boot up to enter the Super I/O Settings menu. Serial Port 1/2 Configuration (SIO FINTEK81801U) • Serial Port 1/2 Configuration. Use this item to enable or disable the serial port (COM1 or COM2). - Page 40 ITX-P-3800/BIOS Functionality – RS485 driver: When hardware set to RS485 mode, select the RS485 driver. It is the auto flow function for RS485. • Power Failure. This item specifies whether your system reboots after a power fail- ure or interrupt occurs. Options are: –...
-
Page 41: Glossary
Software Description This section provides details on the Insyde BIOS components to be used in the implementation of the ITX-P-3800 BIOS firmware. 8.7.1 Software Design Specification: UEFI Operating System Support The BIOS supports the booting of the following UEFI compliant OSes: •... -
Page 42: Software Design Specification: Legacy Operating System Support
ITX-P-3800/BIOS Functionality • Ubuntu 16.XX x32/x64 8.7.2 Software Design Specification: Legacy Operating System Support • Compatibility Support Module (CSM) • Legacy boot support required • Legacy option ROM support required The BIOS supports the booting of the following legacy OS: •... -
Page 43: Bios Update With Uefi Shell
1. Insert a USB flash drive containing the BIOS update program into a USB socket on the ITX-P-3800 platform. 2. Turn on the ITX-P-3800 and press the ESC or DEL key during the boot process, which starts the BIOS setup utility. -
Page 44: Accessories And Cables
• One passive heat spreader • One power cable adapter • One power supply Accessory List WinSystems cables simplify connection to the ITX-P-3800. The following table lists available items. Table 3: Cable specifications Part Number Connection Description CBL-PWR-J03-04A See “PWR - DC Power Input” on page 13 1x4 pin (2.0 mm) to 5.5 x 2.5 mm barrel connector... -
Page 45: Software Drivers
See “KBMS - PS2 Keyboard/Mouse” on page 25 1x6 pin (1.25 mm) to PS2 keyboard and PS2 mouse connectors Standoff kits are available and recommended for use with the ITX-P-3800. The following table lists the items contained in each kit. -
Page 46: Best Practices
The ITX-P-3800 requires +9V to +36V (+- 5%) to operate. Verify the power connections. Incorrect voltages can cause catastrophic damage. The ITX-P-3800 has a single power connector at J17. A single 9V-36V DC input and ground is required to power the board. - Page 47 —Always turn off the power supply before connecting to the I/O Module. ower Supply OFF Do not hot-plug the ITX-P-3800 on a host platform that is already powered. I/O Connections OFF—Turn off all I/O connections before connecting them to the embedded computer modules or any I/O cards.
- Page 48 Conformal Coating Applying conformal coating to a WinSystems product does not in itself void the product warranty, if it is properly removed prior to return. Coating can change thermal characteristics and impedes our ability to test, diagnose, and repair products. Any coated product sent to WinSystems for repair will be returned at customer expense and no service will be performed.
-
Page 49: Mechanical Drawings
ITX-P-3800/Mechanical Drawings Appendix B. Mechanical Drawings ITX-P-3800 Mechanical Drawings v1.0 www.winsystems.com Page 49... -
Page 50: Warranty Information
WinSystems, provided that the warranty, if any, may be assigned. The sole obligation of WinSystems for any breach of warranty contained herein shall be, at its option, either (i) to repair or replace at its expense any materially defective Products or Software, or (ii) to take back such Products and Software and refund the Customer the purchase price and any license fees paid for the same.
