A
x1
Top frame
x1 Cadre supérieur
x1 Armazón superior
E
∅
x8 Flat Washer
1/4"x16mm
∅
x8 Rondelle plate
1/4"x16mm
∅
x8 Arandela plana
1/4"x16mm
Page 1 of 3
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
PRODUCT NAME / NUMBER(S) : P307DJ257
Description if Available / Needed : Catalina stone top console table / Console / Consola
B
x1 Bottom frame
x1 cadre inférieur
x1 marco inferior
F
∅
x8 Lock washer
1/4"
∅
x8 Rondelle de blocage
1/4"
∅
x8 Arandela de Seguridad
1/4"
Assembly Instructions-Instructions d'assemblage-Instrucciones para el ensamblaje
C
x2
Side Frame
x2
Traverse en métal
x2
Armazón lateral
G
∅
x8 Bolt
1/4"x50mm
∅
x8 Boulon
1/4"x50mm
∅
x8 Perno
1/4"x50mm
Made in VietNam / Fabrique en VietNam / Hecho en VietNam.
D
x1 Stone Tops Ships Seperately
H
x1 Allen Key 4mm
x1 Clé hexagonale 4mm
x1 Llave Allen 4mm
*
Replaceable part
