INSTALLATION INSTRUCTIONS
CARE AND MAINTENANCE
SERIN BATHTUB SERIES
Model 3581
Model 3582
Model 3583
Model 3584
Model 3585
Thank you for selecting our American Standard product. To ensure that your
installation proceeds smoothly, read these instructions carefully before you
begin. Also, review the recommended tools and materials section. Carefully
unpack and examine your new plumbing fixture.
All product names listed herein are trademarks of AS America Inc. unless otherwise noted.
© AS America Inc. 2008
Serin Soaker Tub 5' x 32"
Serin Soaker Tub 5-1/2' x 36"
Serin Soaker Tub Oval
Serin Soaker Tub 6' x 42"
Serin Soaker Tub 5' x 32"
with Integral Tile Flange
INTRODUCTION
754150-100
