Setting Up Your MX452 In
Default Mode (Tel Priority Mode)
With An Answering Machine
DSL/Cable Modem Connection
Next

Advertisement

loading
Need help?

Need help?

Do you have a question about the MX452 and is the answer not in the manual?

Questions and answers

Related Manuals for Canon MX452

Summary of Contents for Canon MX452

  • Page 1 Setting Up Your MX452 In Default Mode (Tel Priority Mode) With An Answering Machine DSL/Cable Modem Connection Next...
  • Page 2 Fax Easy Setup Click Next to step through this image-friendly version of Fax Easy Setup. If you started Fax Easy Setup, on the fax machine’s operation panel, and prefer to go through this image-friendly version… Step 1 Step 2 Press the FAX button at any screen Click Next to proceed...

  • Page 3: Connecting The Phone Lines

    Connecting The Phone Lines Previous Next...
  • Page 4 Connecting Your Phone/Answering Machine Is your answering machine built into your phone? Click Here or Go To Page 13 Click the Next Button Previous Next...
  • Page 5 Fax to Phone Line Connection Before Hand Set (Phone) (Existing Phone Cord) (Existing Phone Cord) Answering  Machine DSL/Cable Modem Wall jack Hand Set (Phone) After Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 6 Fax to Phone Line Connection • Plug the provided phone cord into the DSL/Cable Modem. Hand Set (Phone) Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 7 Fax to Phone Line Connection • Plug the provided phone cord into the “LINE” jack located on the  rear of the multifunction. Hand Set (Phone) Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 8 Fax to Phone Line Connection • Remove the white plug from the upper jack labeled “EXT.” Hand Set (Phone) Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 9 Fax to Phone Line Connection • Plug the second phone cord into the “EXT.” jack located on the rear  of the multifunction. Hand Set (Phone) Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 10 Fax to Phone Line Connection • Plug the second phone cord into the answering machine. Hand Set (Phone) Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 11 Fax to Phone Line Connection • Plug the third phone cord into the answering machine. Hand Set (Phone) Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 12 Fax to Phone Line Connection • Plug the third phone cord into the phone. Hand Set (Phone) Answering  Machine (Phone Cord included  (Existing Phone Cord) with Canon printer) (Existing Phone Cord) DSL/Cable (Existing Phone Cord) Modem Wall jack Previous Next...
  • Page 13 Fax to Phone Line Connection Before Hand Set (Existing Phone Cord) (Existing Phone Cord) (Phone) DSL/Cable Modem Wall jack After Hand Set (Phone) (Phone Cord included with  Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
  • Page 14 Fax to Phone Line Connection • Plug the provided phone cord into the DSL/Cable Modem. Hand Set (Phone) (Phone Cord included with  Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
  • Page 15 Fax to Phone Line Connection • Plug the provided phone cord into the “LINE” jack located on the  rear of the multifunction. Hand Set (Phone) (Phone Cord included with  Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
  • Page 16 Fax to Phone Line Connection • Remove the white plug from the upper jack labeled “EXT.” Hand Set (Phone) (Phone Cord included with  Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
  • Page 17 Fax to Phone Line Connection • Plug the second phone cord into the “EXT.” jack located on the rear  of the multifunction Hand Set (Phone) (Phone Cord included with  Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...
  • Page 18 Fax to Phone Line Connection • Plug the second phone cord into the phone. Hand Set (Phone) (Phone Cord included with  Canon printer) (Existing Phone Cord) (Existing Phone Cord) DSL/Cable Wall jack Modem Previous Next...

  • Page 19: Setting Up The Receive Mode

    Setting Up The Receive Mode Previous Next...
  • Page 20 Step 1 Step 2 Turn on the MX452 by pressing the Press the FAX button. ON button, if it is not powered on already. Previous Next...
  • Page 21 Step 3 Step 4 The fax standby screen will appear. Press the Menu button. Previous Next...
  • Page 22 Step 5 Step 6 The FAX menu screen will appear. Use the LEFT or RIGHT button to select “Receive mode set”. Previous Next...
  • Page 23 Step 7 Step 8 Press the OK button. Use the LEFT or RIGHT button to select “TEL priority mode”. Previous Next...
  • Page 24 Step 9 Step 10 Press the OK button. Use the LEFT or RIGHT button to select “Yes” at Make adv. settings screen. Previous Next...
  • Page 25 Step 11 Step 12 Press the OK button. Use the LEFT or RIGHT button to select “User-friendly RX”. Previous Next...
  • Page 26 Step 13 Step 14 Press the OK button. Use the LEFT or RIGHT button to select “ON”. Previous Next...
  • Page 27 Step 15 Step 16 Press the OK button. You will return to the “Fax standby screen” and the receive mode will appear on the screen. Previous Next...

  • Page 28: Receiving A Fax

    • If fax tones are heard by the MX452 it will take over the call and receive the fax document. IMPORTANT: In order to receive a fax, you must either pick up the handset on a phone that is connected to the MX452 or let your answering machine answer the call. Previous...
