- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. DYNA-GLO RA18LPDGD-1 Owner's Manual Shop genuine replacement parts for DYNA-GLO RA18LPDGD-1 Find Your DYNA-GLO HVAC Parts - Select From 146 Models -------- Manual continues below --------...
- Page 2 PROPANE CONSTRUCTION HEATER USER’S MANUAL AND OPERATING INSTRUCTIONS MODEL # RA18LPDG, RA18LPDGD, RA18LPL RA18LPDGP, RA18LPA, RA18LPB, and RA18LPC ANS Z83.7-2011 CSA 2.14-2011 Adequate ventilation must be provided. GHP Group, Inc. 6440 W Howard St Niles, IL 60714-3302 IMPORTANT: READ AND UNDERSTAND GENERAL HAZARD WARNING: THIS MANUAL BEFORE ASSEMBLING, FAILURE TO COMPLY WITH THE...
-
Page 3: Table Of Contents
PROPANE CONSTRUCTION HEATER TABLE OF CONTENTS General Safety Information ................3 - 4 Specifications ......................Product Features ..................... Unpacking and Assembly .................... Propane Supply ......................Connecting Heater to Gas Supply ................Propane Safety ......................Checking For Leaks ....................Lighting & Shutdown Instructions ............... 10 – 11 Storage of Heater ...................... -
Page 4: General Safety Information
PROPANE CONSTRUCTION HEATER GENERAL SAFETY INFORMATION Radiant Propane Construction Heaters The heater is designed and approved for use as a construction heater under ANS Z83.7 CSA 2.14. CHECK WITH YOUR LOCAL It is hard to anticipate every use which may be made of this heater. FIRE SAFETY AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS. -
Page 5: General Safety Instructions
PROPANE CONSTRUCTION HEATER GENERAL SAFETY INSTRUCTIONS Accidents are always tragic especially because so many of them could have been prevented with little care and judgment. There are some basic good practices, we hope you will follow for safe use of your heater. IMPORTANT SAFETY INFORMATION •... -
Page 6: Specifications
PROPANE CONSTRUCTION HEATER SPECIFICATIONS Vent Free Radiant Heater - Propane Vapor Only Fuel Type ....................... Propane Vapor Only Ignition Type ...................... Piezo Electric/ODS Pilot Min Operating Temperature ....................0 ° F (-18 ° C) Clearances to Combustibles ....Front: 3’ (92cm), Top: 2’ (60cm), Sides: and Rear: 1’ (30cm), Floor: Combustible, not for use on finished floors. -
Page 7: Unpacking The Heater
PROPANE CONSTRUCTION HEATER CONTENTS 1. Unit 2. Rear Guard 3. Manual 4. Hardware Kit Includes: M8 Flat Washers(4) Locking Casters(2) Non Locking Casters(2) 14 mm Wrench(1) Estimated Assembly Time: Tools Required: 10 Minutes 14 mm Wrench (Included) UNPACKING THE HEATER 1. -
Page 8: Propane Supply
PROPANE CONSTRUCTION HEATER PROPANE SUPPLY You must provide the propane gas and cylinder(s). Use this heater only with a propane vapor withdrawal supply system. Refer to Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas, ANSI/NFPA 58. Your local library or fire department will have this booklet. •... -
Page 9: Connecting Heater To Gas Supply
PROPANE CONSTRUCTION HEATER CONNECTING TO GAS SUPPLY UNPACKING THE HEATER IMPORTANT! ALWAYS USE A PROPANE (LP) CYLINDER THAT HAS A CONNECTION DEVICE THAT IS COMPATIBLE WITH THE HOSE AND REGULATOR ASSEMBLY SUPPLIED. CAUTION THE PROPANE (LP) GAS PRESSURE REGULATOR AND HOSE ASSEMBLY SUPPLIED WITH THE HEATER MUST BE USED WITHOUT ALTERATION. -
Page 10: Propane Safety
PROPANE CONSTRUCTION HEATER PROPANE SAFETY Propane is safe to use when properly handled. Careless handling of the Propane gas tank could result in fire and/or an explosion. Therefore: • Always keep tank/cylinder securely fastened in an upright position. • Avoid tipping tank on its side when connected to a regulator since this may cause damage to diaphragm in regulator. -
Page 11: Lighting & Shutdown Instructions
PROPANE CONSTRUCTION HEATER LIGHTING INSTRUCTIONS 1. STOP! Read and head warnings and cautions on the side of the heater. 2. Check that the gas supply to the heater is on. 3. Push in gas control knob slightly and turn clockwise to OFF ( ) position. -
Page 12: Shutdown Instructions
PROPANE CONSTRUCTION HEATER SHUTDOWN INSTRUCTIONS 1. Push in gas control knob slightly and turn clockwise to OFF ( ) position. Do not force. (A) 2. Turn gas supply off by turning propane tank valve clockwise to close. Turning burner only OFF (pilot stays lit). Turn control knob clockwise to PILOT ( ) position. -
Page 13: Maintenance
PROPANE CONSTRUCTION HEATER MAINTENANCE Repair should be done by a qualified service person. The appliance should be inspected before use and at least annually by a professional service person. More frequent cleaning may be required due to excessive debris. It is imperative that control compartments, burners and circulating air passageways of the heater be kept clean. -
Page 14: Troubleshooting
PROPANE CONSTRUCTION HEATER TROUBLESHOOTING Problem Possible Cause What To Do 1. Ignitor electrode positioned wrong. 1. Reposition ignitor electrode. 2. Ignitor electrode broken. 2. Replace electrode. When ignitor is depressed there is no spark 3. Ignitor cable pinched or broken. 3. - Page 15 PROPANE CONSTRUCTION HEATER TROUBLESHOOTING (continued) Problem Possible Cause What To Do 1. Gas leaks. Refer to front of page Gas odor even when control knob is 1. Locate and correct leaks immediately. Warnings. in OFF position. 2. Replace gas control 2.
-
Page 16: Replacements Parts List
PROPANE CONSTRUCTION HEATER REPLACEMENT PARTS LIST RA18 SERIES Item/Model Number Part No. Item/Model Number Part No. 1. Lower Shield PT-N11B-8 10. Tilt Switch 2. Guard Assembly PT-N11B-3 11. Gas Pipe PT-N11B-7 3. Front Panel PT-N11B-1 12. Regulator & Hose Assembly KR-106-01 (HW-350) 4. -
Page 17: Exploded Parts Drawing
PROPANE CONSTRUCTION HEATER EXPLODED PARTS DRAWING 18.Knob 7.Gas Valve 6. Burner Assembly 8. Piezo Ignitor 4. Reflector 9. Knob Base 3. Front Panel 10. Tilt Switch 2. Guard Assembly 11. Gas Pipe 1. Lower Shield 5. ODS Assembly 13. Rear Chassis 17. -
Page 18: Warranty
WARRANTY LIMITED WARRANTY: This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any defect in materials and workmanship for a period of one (1) year from the date of retail sale. GHP Group, Inc., at it’s option, will either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers as directed by GHP Group, Inc., within one (1) year of retail purchase. - Page 19 WARRANTY REGISTRATION IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14) days of date of purchase. You can also register your warranty on the internet at www.ghpgroupinc.com. Complete the entire serial number. Retain this portion of the card for your records.
