- Page 1 All manuals and user guides at all-guides.com User Manual Page 1...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com User Manual Table of Contents Table of Contents .........................2 Operating Instructions ......................3 About Your S5E Radio ....................3 S5E Specification ......................3 Safety Information ........................4 Unpacking Information ......................5 S5E Features ........................6 Description of Radio Components ...................6... -
Page 3: Operating Instructions
We urge you to thoroughly read this manual before operating the radio The application of some of the functions described in this manual is determined by the system you use. Your Maxon Dealer will program your radio so that you have the greatest number of functions possible relative to your needs. -
Page 4: Safety Information
When used in a vehicle, do not mount the radio unit on or near the Airbag or Airbag activation device. The use of an accessory not recommended or supplied by Maxon may cause damage to equipment or injury to personnel, and will invalidate warranty. -
Page 5: Unpacking Information
Remove and carefully inspect the contents of your package(s) for the following items: 1. Radio 2. Battery Pack 3. Battery Charger 4. Spring Belt Clip 5. Jack Cover 6. Battery Charger Power Supply 7. User Manual * If any items are missing, please contact your Dealer or Maxon Page 5... -
Page 6: S5E Features
All manuals and user guides at all-guides.com User Manual S5E Features 500mW output power 12.5KHz channel spacing Full scanning Password protect Emergency call CTCSS/DCS/tone signalling Li-ion Battery Busy Channel lockout Time-out timer Priority Channel Edit Description of Radio Components (Please see drawing on page 7) 1. - Page 7 All manuals and user guides at all-guides.com User Manual Page 7...
-
Page 8: Installing And Removing The Battery Pack
All manuals and user guides at all-guides.com User Manual Installing and Removing the Battery Pack To Install: Position the guides of the battery in line with the radio battery guide rails and slide the battery into position until a click is heard. To Remove: Holding the radio in one hand, push and hold the battery latch button located in the upper central part of the battery pack, held as if looking at the back of the unit. -
Page 9: Attaching And Removing The Belt Clip
All manuals and user guides at all-guides.com User Manual Attaching and Removing the Belt Clip To Install: Install belt clip onto the belt clip holder located on the upper part of the battery, held whilst looking at the back of the unit. Locate the slot on the battery and push belt clip downward until a click is heard. -
Page 10: Battery Charging And Care
CHL100L-02 Desktop Charger provides 2 hours charging to one radio and one battery. Before using your S5E for the first time a full two hour charge will be required for the best performance. -
Page 11: Status Indicators And Audible Alert Tones
User Manual Status Indicators and Audible Alert Tones Your S5E has a sophisticated microprocessor control which provides a series of audible alert tones. Upon initial power up, a quick melody indicates that the self-test of the microprocessor functions has been completed satisfactorily. A series of tones may be sounded with any of the following... -
Page 12: Operation Mode
This section provides general descriptions of the operating modes of the S5E Radio. Power off Mode The S5E shall enter Off mode when the On/Off Volume knob is rotated to the most counter- clockwise position, beyond the detent. Upon entering off mode, the radio shall store its current channel (if Power On Channel function is enabled via PC Programmer). -
Page 13: Scanning
All manuals and user guides at all-guides.com User Manual Scanning Scanning is a Dealer programmable feature that allows you to monitor a number of channels. Your Dealer will help you define a scanning mode and your channel "scan list". Normal Channel Scan Once the scan list has been established, initiate scanning by pressing the scan key or holding the monitor button and rotate the channel switch to scan the enabled channels. -
Page 14: Service Information
For further information on how to safely dispose of your used batteries, contact your Maxon Dealer. Maintenance Your S5E Radio is designed to be maintenance free. To keep your radio in good working condition: Clean external surfaces with a clean cloth dampened in a solution of dishwasher detergent diluted in water. -
Page 15: Chl100L-02 Desktop Charger
CHL100L-02 Desktop Charger Product description The CHL100L-02 is the standard charger for Maxon's S5E two-way radio batteries. The charger has been designed to fully charge only the Li-ion, 1500mAh battery, the front charging slot charges a battery while connected to the radio, the back charging slot charges a battery that has been removed from the radio. - Page 16 To reduce the risk of shock or injury, familiarize yourself with the correct and safe operating procedures defined in this manual. Only charge Maxon's batteries in this charger – other battery types may burst causing personal injury or damage to the charger, battery or radio.
- Page 17 All manuals and user guides at all-guides.com User Manual This equipment is intended for use in:- Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Russia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey &...
- Page 18 All manuals and user guides at all-guides.com User Manual Maxon House, Cleveland Road, Hemel Hempstead, Hertfordshire, United Kingdom, HP2 7EY Tel: + 44 (0) 1442 267 777 Fax: + 44 (0) 1442 215 515 info@maxoncic.co.uk www.maxoncic.co.uk Page 1...
