- Page 1 JC450 series 4G AI Dashboard Camera Quick Start Manual V1.4 Before using this product, please read this manual carefully in order to use this product correctly. With the purpose of performance improvement, this manual is subject to changes without notice.
-
Page 2: Table Of Contents
CONTENTS ..Overview of Product Appearance 1.1 Appearance Description 1.2 Description of Work Indicators ..Packaging List 2.1 Standard configuration 2.2 Optional 2.3 Selection of product accessories ..Overview of product functions 3.1 Product Features 3.2 Product configuration and parameters 3.3 Product performance .. -
Page 3: Appearance Description
Making connections simpler 01/Overview of Product Appearance 1.1. Appearance Description Front camera Memory card slot 1 Speaker Memory card slot 2 Wire harness External camera interface USB port Status indicator Microphone Upgrade operation hole Device cooling area Reset hole SIM card slot Mounting support 1.2. -
Page 4: Optional
Making connections simpler 2.2. Optional External camera with Mounted in the vehicle, it is used for recording the internal recording internal environment of the vehicle. Pull-out waterproof Mounted outside the vehicle, it is used for recording camera the external environment of the vehicle. Mounted in the center console and facing the driver, Pull-out DMS camera it is used for performing fatigue state analysis. -
Page 5: Product Features
Making connections simpler 03/Overview of product functions JC450 Pro is a 4G dashboard camera specially designed for commercial vehicles. It is equipped with ve recording cameras, which can record video footage for multi views and multi scenes during driv- ing. Provided with the visual AI function, it can support simultaneous computation of ADAS and DMS, so that it can analyze the early warning of the road conditions in front of the vehicle and the status of the driver in the vehicle and thus provide an alarm, so as to ensure driving safety and prevent poten- tial hazards. -
Page 6: Product Performance
Making connections simpler Wireless network Wi-Fi 2.4G Weight 323g Bluetooth BT4.0 Size 106×113×33 (mm) 3.3. Product performance Performance Parameter Performance Parameter Undervoltage Working voltage 9-30V protection Working Overvoltage –20˚C-70˚C temperature protection Storage Reverse connection –30˚C-85˚C Support temperature protection Air ±14KV; ESD protection Flame retardant UL94 V-0... -
Page 7: Product Wiring Diagram
Making connections simpler 4.4. Product wiring diagram RS232 Camera 1 AV OUT INPUT-1 INPUT-2 Camera 5 Camera 4 Camera 3 B+ (Red) Camera 2 GND (Black) POWER ACC (Yellow) Relay (White) SOS KEY Installation description ① The description of all harnesses is shown in the Figure above. Please check the procured accessories and connect and install them according to actual conditions. -
Page 8: Camera Installation
Making connections simpler Step 1: Connect the power cable of the device with the B+, ACC and GND power from the vehicle fuse box. For locations, please refer to Figure ①. Step 2: Install the power cable onto the top center of the front windshield along the A-pillar of the vehicle. -
Page 9: Device Testing
Making connections simpler 3. R232 installation (optional) It is used for connecting an external device. When the device itself cannot meet the application scenes, it can be connected with external professional device through the serial port to achieve the expansion function. 4.8. -
Page 10: Main Functions
Making connections simpler ● Shutdown When the device power is disconnected, it will be shutdown automatically. The device cannot be shutdown during normal operation. ● Sleep When ACC OFF is detected, the device will turn off recording, positioning and etc. to enter the sleep mode for low power consumption. 5.2. -
Page 11: Special Note
Making connections simpler ② If it is an IoT network card, the APN may not be adapted automatically. So you need to add the APN configuration manually. 4. The device cannot perform positioning, and the green LED indicator is flashing. ①... -
Page 12: Warning
Making connections simpler 7.3. Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to pro- vide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer- ence to radio communications. -
Page 13: Customer Information
Making connections simpler 08/Warranty Card Customer Information: Customer Name IMEI No. Mailing Address Phone Product Model Date of Purchase Invoice No. Purchased From Address Phone Maintenance Record Service Start Date Problem and Solution Service End Date Customer Signature Important Please keep this warranty card in a safe place, as it is the proof for one-year free warranty services.
