- Page 1 PlanoCentro 201-A-230V PlanoCentro 201-E . . PlanoCentro 201-U . . PlanoCentro 300-A-230V PlanoCentro 300-E . . PlanoCentro 300-U . . Art. Nr. 203 0 3. . 203 0 4. . 203 0 5. . 203 0 6. . Bedienungsanleitung Notice d'utilisation Operating Manual Istruzioni per l'uso...
-
Page 2: Table Of Contents
English Operating Manual Presence detector PlanoCentro 201-A-230V PlanoCentro 201-E . . PlanoCentro 201-U . . PlanoCentro 300-A-230V PlanoCentro 300-E . . PlanoCentro 300-U . . Table of contents 1. Safety ......91 8. -
Page 3: Safety
Thank you for purchasing a Theben HTS presence detector and putting your trust in us. 1. Safety CAUTION! Danger of death through electric shock or fire! Installation should only be carried out by a qualified electrician! Work done on electrical installations may only be conducted by an authorised electrician or... -
Page 4: Function And Performance
2. Function and performance The presence detector series PlanoCentro is intended for ceiling mounting. ● Installation in suspended ceilings (false ceilings) ● Installation in flush-mounted junction box (set into concrete ceiling) Devices are available in the delivery unit with matching assembly sets for ceiling installation and flush-mount ceiling installation. - Page 5 Channels A, B light switch lighting on with presence and insufficient light, and off with absence or sufficient light. The light can also be switched on/off manually using push buttons or switches. Channel C light on the PlanoCentro 300 only controls lighting by presence, for example for switching on blackboard lighting in classrooms.
-
Page 6: Scope Of Delivery
2.1 Scope of delivery Ceiling installation 1 Presence detector with installation protection cover (removable) 2 PlanoCap (terminal cover) 3 PlanoFix E (installation frame) 4 Strap, 6 pieces 5 PlanoCover (frame) 6 Template for ceiling cut out 7 Operating Manual Flush-mounted installation 1 Presence detector with installation protection cover (removable) 2 PlanoFix U (installation plate) -
Page 7: Installation
3. Installation 3.1 Presence detection The ideal installation height is between 2.0 - 3.5 m. The sensitivity of the detector reduces with higher installation heights. The presence detector requires a clear view of people in order to clearly detect people. Offices, mobile partition walls, plants, hanging lighting etc. can hinder (shadowing) the pres- ence detector. -
Page 8: Light Measurement
3.2 Light measurement The detector measures artificial and natural light, which is reflected from surfaces below the detector (beam angle for each ± 30°). The presence detector has two targeted light measu- rements, which separately record the light from two lighting groups. -
Page 9: Ceiling Installation
3.3 Ceiling installation Ceiling installation of the presence detector takes place via the PlanoFix E installation frame and straps in the cut out ceiling element. PlanoFix E installation frame 1. Draw ceiling cut out (A hinge is integrated into the top of the packaging) ... - Page 10 Monitoring the presence detector 1. Connect wires, see technical data page 129. 2. Fasten cable to the strain relief clamps and remove the excess 3. Fasten the PlanoCap 4. Make sure the locks on the PlanoFix E are open ...
- Page 11 3.4 Flush-mounted ceiling installation Flush-mounted ceiling installation of the presence detector takes place via PlanoFix U in a flush mounted socket. Details about the flush mounted socket can be found in the technical data page 131, section flush mount installation. The screws included are intended for installation in the flush- mounted socked.
-
Page 12: Connection / Operation Mode
4. Connection / Operation mode The PlanoCentro presence detector can be combined as master and slave. ● Master in single unit operation ● Master in parallel switching mode ● Master - slave parallel switching 4.1 Single unit operation With individual switching, a PlanoCentro 201 controls two lighting groups as a «Master» as well as e.g. - Page 13 4.2 General parallel connecting The parallel signal is sent via P-terminal and also received. Every detector, regardless of whether it is master or slave, sends the presence signal via P-terminal. This allows a Master and Slaves, as well as several Masters, to be switched together with a parallel signal. See following chapter on parallel switching options.
- Page 14 4.3 Master-Slave parallel circuit operation PlanoCentro 201 Several detectors switch two lighting groups ● The Master has two individual brightness measurements for its two lighting groups. ● The Master switches the lighting. All other detectors are slaves. ● Presence detection through all detectors together. ●...
- Page 15 4.4 Master-Slave parallel circuit operation PlanoCentro 300 Several detectors switch three lighting groups ● The Master has two individual brightness measurements for its lighting groups. Lighting group C does not have a brightness measurement and only switches according to presence. ●...
- Page 16 4.5 Master-Master parallel circuit operation PlanoCentro 201 Several Masters switch more than two lighting groups ● Each Master has two individual brightness measurements for its two lighting groups. ● Each Master switches its lighting outputs according to the allocated brightness setpoint values.
- Page 17 4.6 Master-Master parallel circuit operation PlanoCentro 300 Several Masters switches more than three lighting groups ● Each Master has two individual brightness measurements for its three lighting groups. Lighting group C does not have a brightness measurement and only switches according to presence.
-
Page 18: Start-Up
5. Start-up The detector is delivered ready for operation with basic settings. The specifications are guide values. The management remote control SendoPro is available as an option for start-up. It enables remote setting of all parameter values. See chapter 6 page 114. 5.1 Basic settings The PlanoCentro has 6 basic settings. - Page 19 5.2 Activating the basic settings Parameter Value Presence detector Room correction factor lighting A PlanoCentro 201/300 Room correction factor lighting B PlanoCentro 201/300 Lighting time delay A, B, C 10 min PlanoCentro 201/300 Short presence channels A, B, C light PlanoCentro 201/300 Function channel H Presence...
- Page 20 The basic settings have to be activated after the rotary switch position SW1 has changed. Adjusting the rotary switch during operation (live) does not have an effect. Activation Description Powerup The rotary switch position SW1 is monitored during the first 5 hours of operation.
- Page 21 5.3 Behaviour on switching on Every time the voltage is switched on, the detector goes through the start-up phase, which is indicated by the LED. The presence detector runs through several tests during the start-up phase. If the tests run without any problems, then the presence detector switched to normal operation mode.
-
Page 22: Parameters
6. Parameters The basic settings are selected with a rotary switch on the back of the presence detector, see page 110. Parameters can be adjusted and optimised with the SendoPro Management remote control. The following parameters are available with the PlanoCentro 201 and PlanoCentro 300: Parameter Page Operation mode... -
Page 23: Operation Mode
6.1 Adjustment with the remote control The parameters are sent to the presence detector via SendoPro management remote control. The parameters can be selected before making changes. Changed parameters are immediately accepted and applied by the detector. Description Flickering during After pressing the send function on the management remote control, the presence detector 3 sec displays correct receiving by flickering for 3 sec... - Page 24 Presence detector is used as staircase time switch. Manual switching off with push-buttons or theSenda S not pos- sible.. 6.5 Brightness set point value channels A, B light The brightness level defines the minimum required brightness. The current prevailing brightness is measured separately below the presence detector to the window (A) and to the room interior (B).
- Page 25 The standard value is 0.3 and is suitable for most applications. Changes only make sense in extreme situations. Value range Adjustable values 0.05 - 10 Standard value, suitable for most applications. Adjustment of the detector brightness actual value Procedure: 1. Lux value below the presence detector to the window (A) or to the room interior (B) can be set separately via the lux meter 2.
-
Page 26: Setting Limits
Setting limits Set the room correction factor in such a way that room correction factor x brightness actual value is between 10 lx and 26000 lx. 6.7 Time delay channels A, B light or channel C light Value range Adjustable values 10 sec .. -
Page 27: Detection Sensitivity
The switch-off delay time is used according to set parameters. When entering an unoccupied room for a maximum of 30 seconds, the light switches off after two minutes. 6.9 Control inputs S1, S2, S3 (channels A, B, C light) Control inputs S1, S2, S3 for manually switching lights on/off (channels A, B, C light) automati- cally recognise push buttons or switches. - Page 28 By selecting the operation mode test presence, the set sensitivity level is not changed. The parameter can be changed during test presence. 6.11 Function channel H presence (PlanoCentro 201 only) The potential-free relay contact may be used either for presence depending HVAC control or the control of lighting.
- Page 29 6.13 Switch-off delay time channel H presence (PlanoCentro 201 only) The presence channel always switches, regardless of whether the function mode is set to full or semi- automatic. Set values remain unchanged (no self-learning effect). The relay contact only opens upon completion of the set switch-off delay time when presence is detected.
-
Page 30: Read-Out Data
6.16 Group address channels A, B, C light This parameter is used when using the theSenda S. Channels A, B light can be allocated a group address (basic setting is I for channel A, I I for channel B and I I I for channel C). Group addresses can be programmed with the theSenda S in the PlanoCentro or adjusted with the SendoPro. -
Page 31: Test Presence
8. Test-Mode The PlanoCentro has two test modes. ● Test presence, page 123 ● Test lighting, page 125 The test mode can only be started with voltage. 8.1 Test presence The test presence serves to test presence detection and parallel switching. The test presence can activated directly on the presence detector (without power up) or with the SendoPro management remote control. - Page 32 Test response - Brightness measurements deactivated, lighting outputs do not react to brightness - Detector does not respond as in fully-automatic function mode, also if semi-automatic is set. - Channels A, B, C lighting have a fixed switch-off delay time of 15 sec. - Channel H presence / room monitoring responds normally as in normal mode.
- Page 33 8.2 Test lighting The test light operating status is activated via the SendoPro management remote control. - Test lighting «On» with the SendoPro management remote control Activate The test lighting can always be activated. Terminate With subsequent restart: - Test lighting «Off» with the SendoPro management remote control - Power outage and thus power up - The presence detector automatically restarts after 10 minutes (see page 113) Without restart:...
- Page 34 Test response The presence detector behaves 100% as in normal operation, only the reaction to light/dark is faster. Thus the brightness threshold and the adaptive response is tested. All selected functions and parameters remain unchanged. Commands and adjustable parameters During test mode the following commands are possible with the SendoPro management remote conrol: - Terminate test lighting - Activate basic settings (Reset) - Change detection sensitivity...
-
Page 35: Control Commands
9. Control commands Control commands are available as follows: Teach-in channel A The actual measured brightness value is applied to the brightness level channel A. Teach-in channel B The current measured brightness value is accepted as brightness setpoint value. Teach-in channels A, B The current measured brightness value is accepted as brightness setpoint value. -
Page 36: Malfunction Information
10.2 Malfunction information Malfunction information can be read with the SendoPro management remote control. Error display Solution Hardware malfunction Send in device for repairs with a short description of the problem to the responsible specialised dealer. Parameter error Change and send parameter set Combination of brightness set point and Change and send brightness set point value or room-correction factor room correction factor is not valid. -
Page 37: Troubleshooting
11. Troubleshooting Fault Cause Light does not switch on and/or off Lux value is set too low; detector set on semi-automatic; light was switched off when presence and darkness manually via push-buttonor or with theSenda S; person not within detection range;... -
Page 38: Led Display
11.1 LED display Description Blinking in 1 second The presence detector is in the start-up phase. See page 113. tact Flickering during The command sent from the management remote via infrared is rejected by the presence 3 sec detector. lights up shortly The command sent from the management remote via infrared is rejected by the presence detector. -
Page 39: Technical Data
12. Technical data Presence detector PlanoCentro 201-A-230V PlanoCentro 300-A-230V Detection angle horizontal 360° Recommended installation height 2.5 - 3.5m Detection range 3.5m installation height 64 m (8 x 8 m) seated persons 100 m (10 x 10 m) moving Light measurement Mixed light Brightness range approx. - Page 40 Channels A, B, C light Type of contact Relays 230V/10A Upstream protection device cos ϕ 1 Maximum switching capacity, Total of all contacts 2300W resistive cos ϕ 0.5 1150VA Maximum switching capacity see respective manufacturer cos ϕ Maximum switching capacity LED LED lamp <...
- Page 41 "Presence" switch-on delay 0 sec. - 10min. Room monitoring monitoring Ceiling installation (false ceilings) Installation type PlanoFix E installation frame Ceiling cut out 100 x 100 mm ± 1 mm Ceiling strength up to approx. 26 mm Flush-mounted installation (concrete ceiling) Installation type PlanoFix U , flush-mounted junction box...
-
Page 42: Item Numbers
Item numbers PlanoCentro 201-EWH, Ceiling installation set, white 203 0 502 PlanoCentro 201-EBK, Ceiling installation set, black 203 0 503 PlanoCentro 201-ESR, Ceiling installation set, silver 203 0 504 PlanoCentro 201-UWH, flush-mounted installation set, white 203 0 602 PlanoCentro 201-UBK, flush-mounted installation set, black 203 0 603 PlanoCentro 201-USR, flush-mounted installation set, silver 203 0 604... - Page 43 Management remote control SendoPro 868-A 907 0 675 theSenda S user remote control 907 0 690 PlanoCover EWH-112x112, white 907 0 677 PlanoCover EBK-112x112 , black 907 0 678 PlanoCover ESR-112x112 , silver 907 0 679 PlanoCover UWH-123x123 , white 907 0 680 PlanoCover UBK-123x123 , black 907 0 681...
-
Page 44: Dimension Drawings
13. Dimension drawings 13.1 Ceiling installation PlanoCentro 201/300-E.. 100 x 100 ± 1 13.2 Flush-mount installation PlanoCentro 201/300-U.. -
Page 45: Warranty Declaration
Theben HTS presence detectors are manufactured and tested for quality with greatest of care and most modern technology. Theben HTS AG thus guarantees smooth function with correct use. Should a malfunction appear, Theben HTS AG guarantees within the scope of the General Terms and Conditions: Please notice specifically: ●... - Page 46 Fax +49 (0) 74 74 692 - 207 hotline@theben.de Theben HTS AG Im Langhag 7b, CH - 8307 Effretikon Tel. +41 (0)52 355 17 00 Fax +41 (0)52 355 17 01 www.theben-hts.ch Please find the contact addresses for additional countries on www.theben.de...
