  • Page 1 DFWX SERIES ENGLISH TECHNICAL MANUAL www.diniargeo.com...
  • Page 2: Extended String And Extended String

    © Dini Argeo. All rights reserved. Dini Argeo® is a registered trademark. Dini Argeo owns the copyright for the contents of this document (including artwork, illustrations, photographs, and written material). You may not copy, reproduce, modify, republish, or distribute any material from this document without permission.
  • Page 3: Table Of Contents

    TABLE of CONTENTS 1. INTRODUCTION AND WARNINGS 2. TECHNICAL SPECIFICATIONS FOR DFWX MODELS 3. TECHNICAL SPECIFICATIONS FOR DFWX-HGX MODELS 4. INDICATOR DIMENSIONS (MM) 5. INDICATOR COVER Remove Cover   11 Reinstall Cover   11 6. INDICATOR COMPONENTS 7. CPU BOARD OVERVIEW 8.
  • Page 4 17. DIGITAL INPUTS AND OUTPUTS Digital Inputs   31 Digital Outputs   32 Alibi/Clock Jumpers   33 18. DIGITAL OUTPUT SETPOINT MODE WITH HYSTERESIS 19. ETHERNET CONNECTION Ethernet Module Connection Configuration   34 PR80 Printer and Dini Labeler Ethernet Configuration  ...
  • Page 5 25. EXTERNAL LEVL3AX DEVICE (Optional) External Inclinometer   50 Configuration   50 External LEVEL3AX Module Cable   51 External LEVEL3AX Board Pinout   52 26. Metrology Information 27. PROGRAMMING 28. PROGRAMMING MENU   56 0.Cal   57 Grav   58 serial  ...
  • Page 6 32. COMMUNICATION COMMANDS 33. PROGRAMMING ERRORS 34. FAQ - FREQUENTLY ASKED QUESTIONS 35. BATTERY REMOVAL Alibi Battery Removal/Replacement   137 Battery Removal/Replacement   140...
  • Page 7: Introduction And Warnings

    1. INTRODUCTION AND WARNINGS This product is the best solution for multi-function weighing applications, offering ease of use, high precision in reading the weight, and many functions to speed up and simplify everyday work. This manual provides an overview of the potentials of the product. The configuration menu can be used to adapt the product functionality to the required weighing application.
  • Page 8: Technical Specifications For Dfwx Models

    2. TECHNICAL SPECIFICATIONS FOR DFWX MODELS Specification Model Description Material AISI 304 Stainless Steel Case Protection IP68 & IP69K Backlighting RGB, 7 selectable colours Brightness 5 intensity levels LCD Screen Digit height 25 mm Dimensions 136 x 40 mm Keypad 5 mechanical keys + 16 membrane keys Standard 3 x PG9...
  • Page 9: Technical Specifications For Dfwx-Hgx Models

    3. TECHNICAL SPECIFICATIONS FOR DFWX-HGX MODELS Specification Model Description Material AISI 316 Stainless Steel Case Protection IP68 & IP69K Backlighting RGB, 7 selectable colours Brightness 5 intensity levels LCD Screen Digit height 25 mm Dimensions 136 x 40 mm Keypad 5 mechanical keys + 16 membrane keys Standard 2 x PG9 (hygienic certified)
  • Page 10: Indicator Dimensions (Mm)

    4. INDICATOR DIMENSIONS (MM) 78.2 Cable glands vary depending on model.
  • Page 11: Indicator Cover

    5. INDICATOR COVER Remove Cover Use 7 mm wrench to remove M4 nuts. 7 mm Reinstall Cover Position cover on protruding threaded rods and secure with nuts in a star pattern. Torque M4 nuts to 7 N-m. 7 mm...
  • Page 12: Indicator Components

    6. INDICATOR COMPONENTS DFWX-ETH, DFWX-ETH-HGX, DFWXB-WIFI, DFWXB-WIFI-HGX ELEMENT DESCRIPTION DFWX-ETH DFWXB-WIFI Antenna Standard Ethernet/Wi-Fi Board with Analog Output Carrier Standard USB Type-C Port Standard Battery Charging Board Standard Battery Standard Alibi memory module can be installed in two positions, on the CPU Board (F) or on the optional Standard (F) / Optional (H) Digital Input Output board (H).
  • Page 13 DFWX, DFWX-HGX, DFWXB, DFWXB-HGX ELEMENT DESCRIPTION DFWX DFWXB USB Type-C Port Standard Battery Charging Board Standard Battery Standard Alibi memory module can be installed in two positions, on the CPU Board (F) or on the optional Standard (F) / Optional (H) Digital Input Output board (H).
  • Page 14 Internal Components Overview Brief descriptions of the hardware components displayed in this section follow. Component DESCRIPTION An Antenna with mounting hardware is included with the DFWXB-WIFI or Blue- Antenna tooth/RF options. DFWX-ETH and DFWX-WIFI models contain a board that provides Ethernet support or Wi-Fi (802.11b/g/n ).
  • Page 15: Cpu Board Overview

    7. CPU BOARD OVERVIEW This section briefly discusses the internal components of DFWX series instruments. The CPU board runs firmware that contains the configuration for the scale and processes the weight of measured objects. In addition, it provides the required connections for load cells, or junction boxes, keyboard and additional option boards.
  • Page 16 ELEMENT NAME DESCRIPTION COM1 RS-232 COM1 RS-232 (3 screw terminal connection) Power configuration DIP switches (left = ON) • 2: Automatic power on • 1: RS485 Termination Resistance 485 Socket Digital input output connection or Alibi connection (for systems without Alibi BOOT connection) COM4 TTL...
  • Page 17: Approval

    8. APPROVAL When the circuit is completed, the indicator is approved (legal for trade).
  • Page 18: Scale Connection Overview

    9. SCALE CONNECTION OVERVIEW Overview Load Cell Connection Diagrams Single load cell Cell Junction box with four load cells Cell 4 Cell 1 Cell 3 Cell 2...
  • Page 19: Load Cell Scale Connections

    Load Cell Scale Connections EXPANSION NOTE: • For 6-wire connection with “Sense”, set the dip switches to OFF. • For 4-wire connection, set the dip switches to ON. ANALOG OUTPUT (optional) WARNING: Make connections with indicator off and power supply disconnected. ETH/WIFI Comply with the electronic specifications on page 8.
  • Page 20: Wiring Diagrams

    10. WIRING DIAGRAMS CPU Board (DFWX, DFWX-HGX, DFWXB, DFWXB-HGX)
  • Page 21: Cpu Board (Dfw-Eth, Dwx-Eth-Hgx, Dfwxb-Wifi, Dfwxb-Wifi-Hgx)

    CPU Board (DFW-ETH, DWX-ETH-HGX, DFWXB-WIFI, DFWXB-WIFI-HGX)
  • Page 22: Maximum Allowed Cable Lengths

    11. MAXIMUM ALLOWED CABLE LENGTHS Load Cell, RS232 and Analog Output Load cell RS232 Analog output CURRENT: 100 metres with 2 x 0.25 mm cable; 50 metres with 150 metres with 2 x 0.5 mm cable; 6 x 0.25 mm cable;...
  • Page 23: Power Supply

    12. POWER SUPPLY The power supply is located inside the bottom of the enclosure and provides power to the CPU board. The instrument comes with power cord attached. This section illustrates various connections on the power supply. ITEM DESCRIPTION COLOR AC Line Brown (EU) or Black (USA) AC Neutral...
  • Page 24: Earthing

    13. EARTHING For correct earthing and optimal system operation, the instrument, load cells, junction box, and weighing structure must be earthed. INSTRUMENT The instrument must be powered by a dedicated power supply with an ground connection. Ground cables must be connected to the interior grounding stud from the power supply, power cable, and interior grounding stud on back cover.
  • Page 25: Example Of Rear Earth Stud

    Example of Rear Earth Stud NOTE: The back panel earthing stud extends from the interior to the exterior of the back panel. The external earthing stud must connect a earth cable to an earth bar (cables must have a cross-section of at least 16 mm2). The the earth bar must be connected to the earth post using cable having with a cross-section of at least 50 mm2.
  • Page 26: Example Of Grounding A Weighbridge

    Example of Grounding a Weighbridge Instrument Junction box placed on the side wall of the pit Load cell Weighbridge Earth cables Ø 8 - sec. 50 mm Ø 11.3 - sec. 100 mm Drilled copper plate positioned on the side wall Weighbridge Earth post Load cell bypass jumper...
  • Page 27: Example Of Grounding A Silo

    Example of Grounding a Silo Protective earth by- pass for the load cell Load cell...
  • Page 28: Optional Communication Cables

    14. OPTIONAL COMMUNICATION CABLES Serial RS232\RS485 cable with USB connector for PC connection TYPE USB TO RS232 USB TO RS485 Part Number RSCBPCUSB3P RSCBPCUSB485 (1) RX - Orange (1) A+ - Orange Pinout (2) TX - Yellow (2) B- - Yellow (3) GND - Black (3) GND - Black PC side...
  • Page 29: Cable Gland Torque Specifications

    15. CABLE GLAND TORQUE SPECIFICATIONS SIZE METAL CASE PLASTIC CASE PG 7/M12 6.25 Nm 2.5 Nm PG 9/M16 6.25 Nm 3.75 Nm PG 11/NPT3/8 6.25 Nm 3.75 Nm PG 13.5/M20/NPT1/2 6.25 Nm 3.75 Nm PG 16 7.5 Nm 5.0 Nm PG 21/M25/NPT3/4 10 Nm 7.5 Nm...
  • Page 30: Digital Inputs And Outputs

    17. DIGITAL INPUTS AND OUTPUTS The optional Digital Input Output board supplies the DFWX with digital inputs and outputs. The card is mounted in the lower corner of the case, across from the power supply. NOTE: The Digital Input Output board provides a secondary connection for ALIBI if the ALIBI/CLOCK/DFIO connector on the CPU Board is occupied.
  • Page 31: Digital Inputs

    Digital Inputs Specifications: Voltage Range 12 Vdc \ 24 Vdc The following connection diagrams illustrate two methods for connecting digital inputs: INPUTS 12 ÷ 24 V ALIBI/CLOCK TO CPU INPUTS 12 ÷ 24 V ALIBI/CLOCK TO CPU Configuration: menu (see page 107) provides configuration for each input with a specific function. INPUTS...
  • Page 32: Digital Outputs

    Digital Outputs Specifications: Voltage Range Up to Max 48 Vdc \ 60 Vac Max Current Max 500 mA Applicable Load Max 10 Ω The following connection diagrams illustrate two methods for connecting digital outputs: OUTPUTS 48 Vac / 60 Vdc 500 mA Max ALIBI/CLOCK TO CPU...
  • Page 33: Alibi/Clock Jumpers

    Alibi/Clock Jumpers EXTERNAL BOARD Alibi JP1 JP2 TO CPU Clock 18. DIGITAL OUTPUT SETPOINT MODE WITH HYSTERESIS When digital outputs (see page 108) are configured as setpoints on gross or net weight, Hysteresis parameters provide activation and deactivation of independent thresholds for each digital output. Also, it avoids output connection issues due to instability and pro- vides independent thresholds for turning on and turning off the digital outputs.
  • Page 34: Ethernet Connection

    19. ETHERNET CONNECTION DFWX-ETH includes an ETHERNET TCP \IP interface and a PG13 cable gland for installation of a standard Ethernet cable. Ethernet Ports WAN LAN Specifications: Protocols TCP, UDP, IP, ARP, ICMP, Ethernet Mac. 1 LAN for configuration Ethernet ports 1 WAN for use Speed 10-100 Mbps...
  • Page 35: Pr80 Printer And Dini Labeler Ethernet Configuration

    PR80 Printer and Dini Labeler Ethernet Configuration Open the Internet browser and navigate to the IP Address configured in the -> ETH ->WANIP parameter. SER IAL Enter login credentials when prompted. Username: admin, Password: admin Set the IP Addr parameter to connect the indicator to the printer or labeller. NOTE: The IP Address parameter is set as the same IP Address as the printer's except for the last number For example, if the printer's IP address is 192.168.16.100 the value could be configured as 192.168.16.101.
  • Page 36: Wi-Fi Connection

    20. WI-FI CONNECTION DFWXB-WIFI includes a Wi-Fi card that connects to a wireless network through a variety of protocols. Wi-Fi Card Wi-Fi Specifications: Protocols IEEE 802.11b/g/n, WEP, WPA e WPA2-PSK(AES/TKIP) 1 LAN for configuration Ethernet ports 1 WAN for use Speed 10-100 Mbps Default IP...
  • Page 37: Wi-Fi Module Configuration Overview

    Wi-Fi Module Configuration Overview The Wi-Fi configuration is comprised of two sections: • Access Wi-Fi Configuration • Setting up Wi-Fi Configuring Access Wi-Fi Configuration Power on the indicator. Open the PC's Wi-Fi connection settings and Locate the Wi-Fi module's SSID broadcast. The Wi-Fi broadcast is in the format of: "Hi-Link_XXXX", where XXXX is the last four characters of the LAN Wi-Fi MAC address.
  • Page 38 Open an internet browser and then navigate to the IP address of the module: http://192.168.16.254/ NOTE: This is the default IP address and varies if the configuration is changed. Enter user credentials to sign in to the configuration. NOTE: The default credentials are: Username = admin and Password = admin Select Sign in.
  • Page 39: Typical Wi-Fi Configuration

    Typical Wi-Fi Configuration Typically the Wi-Fi module is set with a static (user defined) IP Address. This ensures the IP address of the module does not change. NOTE: A static IP address is not used by the DHCP service. Select the Network Mode drop-down menu. Select WIFI(STA).
  • Page 40 Set the SSID: Enter the SSID in the STA SSID Field. If unknown, select Scan near the STA SSID field. The system populates a list of SSIDs in proximity to the PC. Copy the name of the desired SSID. Return to the Wi-Fi configuration page. Paste the SSID name into the STA SSID field. If needed enable security encryption: •...
  • Page 41 When configuration is complete, select Apply. The settings are applied and a countdown timer is displayed before the Wi-Fi module automatically reboots. NOTE: Don't forget if you changed IP addresses to enter the new one when revisiting.
  • Page 42: Reset Ethernet And Wi-Fi Module Configuration

    21. RESET ETHERNET AND WI-FI MODULE CONFIGURATION There are two methods for resetting the Ethernet/Wi-Fi configuration: Via the reset Parameter in Technical menu: Access the Ethernet reset parameter (see page 76). Perform the Reset function. Via the ESO button: Press and hold the ESO button for 10 seconds. The Ethernet Port LEDs blink twice indicating the module is reset.
  • Page 43: Rf Module Connection (Optional)

    22. RF MODULE CONNECTION (OPTIONAL) When the RF2G4X-x Radio module is installed, it sends and receives information over low power radio communication. The radio mod- ule works in a transparent mode, sending and receiving any standard string without the need for extra characters. When RF2G4X-x module is installed, a specific antenna is installed on top of the case.
  • Page 44: Bluetooth Connection (Optional)

    23. BLUETOOTH CONNECTION (OPTIONAL) When the BLTX-x module is installed, it sends and receives information over low power Bluetooth communication (BLE). The Bluetooth module sends and receives any standard string without the need for extra characters. When the BLTX-x module is installed, a specific antenna is installed on top of the case that does not impact the IP rating of the indicator.
  • Page 45: External Communication Devices (Optional)

    NOTE: The cable is attached to the receiver box from the factory through a included metal cable gland. REMOTE Configuration Configure the Remote parameter (see page 104) to enable the type of remote and communication port. For remote control pairing information, see the DFWX Series User manual.
  • Page 46: External Bluetooth Module

    External Bluetooth Module An external Bluetooth module is available for the DFWX. Typically this module is used by customers with DFWX-ETH / DFWXB-WIFI models that also require Bluetooth. This module connects to Com1 or Com2 on the CPU board. NOTE: The cable is attached to the Bluetooth module from the factory. NOTE: The cable is attached to the receiver box from the factory (typically to COM2 in the DFWX).
  • Page 47: External Radio Module

    External Radio Module An external radio module is available for the DFWX. Typically this module is used by customers with DFWX-ETH / DFWXB-WIFI models that also require radio. This module connects to Com1 or Com2 on the CPU board. NOTE: The cable is attached to the receiver box from the factory (typically to COM2 in the DFWX). Specifications: Frequency 2.4 Ghz...
  • Page 48: External Module Cable

    External Module Cable This cable connects the Bluetooth or Radio module board in external box to the CPU board. NOTE: The cable is attached to the receiver box from the factory (typically to COM2 in the DFWX). NOTE: The external Bluetooth and Radio boards contain the same terminal block connection. DESCRIPTION Part Number 14CAVOOBRFX...
  • Page 49: External Bluetooth And Radio Module Board Pinout

    External Bluetooth and Radio Module Board Pinout The external Bluetooth and Radio connect to the CPU board via typically COM2 and supplied cable. To access the Bluetooth or Radio board remove the 4 bolts and cover. NOTE: The external Bluetooth and Radio boards contain the same terminal block connections. +5 V G N D R TS...
  • Page 50: External Levl3Ax Device (Optional)

    25. EXTERNAL LEVL3AX DEVICE (OPTIONAL) External Inclinometer An inclinometer is available for the DFWX and installed in an external enclosure. The inclinometer connects to a communication port in the DFWX (typically COM2) and reads the inclination of the weighing surface and compensates the weight, increasing precision with inclination conditions.
  • Page 51: External Level3Ax Module Cable

    External LEVEL3AX Module Cable This cable connects the inclinometer module board in external box to the CPU board. NOTE: The cable is attached to the receiver box from the factory (typically to COM2 in the DFWX). + 5 V G N D DESCRIPTION CPU board side 6 pin connector...
  • Page 52: External Level3Ax Board Pinout

    External LEVEL3AX Board Pinout The external LEVEL3AX connects to the CPU board typically on COM2. To access the LEVEL3AX board remove the 4 bolts and top cover, and then 3 screws and PCB cover.
  • Page 53: Metrology Information

    26. METROLOGY INFORMATION How to access metrogy informatino 1. Turn off the scale 2. Follow the procedure: Turn on the scale and press while power messages are displayed. 888888 2 sec Prefix: instrument model xx .yy xx .yy Version: legal software -off- Weighing program aa .
  • Page 54: Programming

    27. PROGRAMMING How to access the programming menu 1. Turn off the scale 2. Follow the procedure: Turn on the scale and press while the power messages are displayed. 888888 2 sec Programming Menu -off- How to save and exit the menu To save the programming changes made, press button repeatedly while navigating the menu backwards, until the message appears: press...
  • Page 55: Programming Menu

    28. PROGRAMMING MENU Calibration ▼ C Zeroing the pre-tare (zero calibration) ▼ a Area of gravity of the place of use ▼ al Serial ports configuration ▼ la Print customisation ▼ l Inclinometer configuration ▼ l Weighing filter ▼ C Adjusting the display ▼...
  • Page 56: Cal

    MENU C A. Quick Calibration (1000+F) How to enter How to How to save browse and exit NOTE: For advanced calibration\Multirange\Multidivision see pages 1. Off ▲ 112, 115 and 116. For silo calibraiton, see page 126. 2. On ▼ ▲ Start of the calibration procedure: Page 54 Page 54...
  • Page 57: Cal

    MENU Cal B. Zeroing the Dead Load (1003+F) How to enter How to How to save browse and exit 1. Off ▲ This procedure zeroes the dead load and changes all calibration point pro- 2. On portionally while keeping the same calibration curve. ▼...
  • Page 58: Grav

    MENU a C. Area of gravity of the place of use How to enter How to How to save browse and exit 1. Off ▲ This parameter allows you to correct the gravity acceleration value. 2. On ▼ Before calibration, set the acceleration due to gravity (g m/s2). ▲...
  • Page 59: Serial

     B ▼  aaC Transmission at the press   k  ▼    For Dini Argeo repeater a aC ▼ m See dedicated manual ▼  TPR Thermal Printer ▼ PR80 Counter-top Ther- p8 mal Printer ▼...
  • Page 60 MENU Selection of the data string: How to enter How to How to save browse and exit Visible only if (D-1-1) = C, al, , or k.  1. Off ▲ 2. On ▼ ▲ C D-1-2 Page 54 Page 54 x...
  • Page 61 MENU Configuration of the serial bits How to enter How to How to save browse and exit  D-1-4 1. Off ▲  8 1 2. On ▼ ▲ ▼ Page 54 Page 54   82 ▼  C a...
  • Page 62 MENU Printer power supply / Radio-frequency module pwp How to enter How to How to save D-1-6 browse and exit 1. Off ▲ Vaux is active when indica-  tor is powered on 2. On ▼ ▲ ▼ Page 54 Page 54 VAUX output active when pw...
  • Page 63  ▼ B  aaC Transmission at the press k  ▼    For Dini Argeo repeater a ▼ aC m See dedicated manual ▼ TPR Thermal Printer  ▼ PR80 Counter-top Ther- p8 mal Printer ▼...
  • Page 64 MENU Selection of the protocol: How to enter How to How to save browse and exit Visible only if (D-2-1) = C, al, 485, , or  1. Off ▲ K. 2. On ▼ ▲ C D-2-2 Page 54 Page 54 x...
  • Page 65 MENU Computer to Screen (C) Printer control signal How to enter How to How to save browse and exit Visible only if (D-2-1) = p, , or al.  p8 1. Off ▲ 2. On ▼ ▲ C D-2-5 Page 54 Page 54 ...
  • Page 66 a  transmission ▼ h  a Transmission at the press pk    aaC C  For Dini Argeo repeater p pwp  ▼ m  See dedicated manual  ▼ a  TPR Thermal Printer aC ▼...
  • Page 67 MENU Selection of the protocol: How to enter How to How to save browse and exit Visible only if (D-3-1) = C, k, or K.  1. Off ▲ 2. On ▼ C ▲ D-3-2 Extended string Page 54 Page 54 x...
  • Page 68 MENU C How to enter How to How to save D-3-5 browse and exit  1. Off ▲ ▼ 2. On ▼ ▲ m Free adjustment Page 54 Page 54 ▼ 1 Characters Cha sent (...999)  C 3 m a...
  • Page 69 h pC Transmission at the press    k B C  aaC ▼    For Dini Argeo repeater  ▼ a m See dedicated manual aC ▼  TPR Thermal Printer ▼ PR80 Counter-top Ther- p8...
  • Page 70 MENU Selection of the protocol: How to enter How to How to save browse and exit Visible only if (D-5-1) = C, al, or k.  1. Off ▲ 2. On ▼ ▲ C D-5-2 Page 54 Page 54 x Extended string x...
  • Page 71 MENU a Radio Configuration How to enter How to How to save browse and exit 1. Off ▲ Port connection of radio-frequency module 2. On ▼ ▲ Page 54 Page 54 Visible only if a radio module is installed. Channel Configuration ...
  • Page 72 l C3 ▼ C4 C   k Transmission at the press a  ▼  a   For Dini Argeo repeater  h CN    ▼  DVC C m See dedicated manual  C...
  • Page 73 MENU Selection of the protocol: How to enter How to How to save browse and exit Visible only if (D-5-12) = C, al, or k.  1. Off ▲ 2. On ▼ ▲ C D-6-3 Page 54 Page 54 x Extended string x...
  • Page 74: Ethernet Port

    ▼  aaC pC Transmission at the press   k  C ▼     For Dini Argeo repeater a p aC ▼ mC See dedicated manual ▼ TPR Thermal Printer  ▼ PR80 Counter-top Ther- p8...
  • Page 75 MENU Selection of the protocol: How to enter How to How to save browse and exit Visible only if (D-7-1) = C, al, or k.  1. Off ▲ 2. On ▼ C D-7-2 ▲ x Extended string Page 54 Page 54 x...
  • Page 76: Bluetooth Module

    MENU Resets the Ethernet/Wi-Fi module to default settings where the How to enter How to How to save access point SSID is HI-LINK_XXXX and the LAN port IP address is browse and exit 192.168.16.254. 1. Off ▲ 2. On ▼ ▲...
  • Page 77 l ▼ C3 C C4 Transmission at the press   k a  ▼  a   For Dini Argeo repeater h  ▼ B  m aaC See dedicated manual     ▼ ...
  • Page 78 MENU Selection of the protocol: How to enter How to How to save browse and exit Visible only if (D-8-2) = C, al, or k.  1. Off ▲ 2. On ▼ C D-8-3 ▲ x Extended string Page 54 Page 54 x...
  • Page 79: Advanced Settings

    MENU aac Advanced Settings How to enter How to How to save browse and exit 1. Off ▲ Management of the external radio frequency module (OBRF2G4X). 2. On ▼ D-9-1 f ▲ Set port the external module is ff Page 54 Page 54 connected to.
  • Page 80 MENU Choose the printout line terminator character How to enter How to How to save browse and exit m 1. Off ▲ D-9-3 2. On ▼ Carriage return C ▲ (ASCII 13 Character) ▼ Page 54 Page 54 Clf Carriage return (ASCII 13 Character) ▼...
  • Page 81: Layout

    MENU lay E. Print Customisation How to enter How to How to save browse and exit 1. Off ▲ Parameters for ticket/label mode 2. On ▼ ▲ HEADER Page 54 Page 54 HEADER ha HEADER HEADER  C a h WEIGHS N.
  • Page 82 MENU a Language Settings How to enter How to How to save browse and exit 1. Off ▲ Select the desired language 2. On ▼ la ▲ l Page 54 Page 54 l  fa ▼ pa  C p ▼...
  • Page 83 MENU Cha Character Settings How to enter How to How to save browse and exit 1. Off ▲ 2. On ▼ Font dimensions ▲ Label mode Ticket mode Cha1 E-2-1 Page 54 Page 54 Main font f 1 mal 1 x 1,5 mm ...
  • Page 84 Additional parameter details: To differentiate information in print, this parameter provides text with two different character dimensions with . The Cha 1 Cha 2 character dimensions for each of the following print lines can be configured: • Line 1 Header •...
  • Page 85 MENU a Header Settings How to enter How to How to save browse and exit 1. Off ▲ Enables header printing 2. On ▼ al E-3-1 ▲  Page 54 Page 54 ▼ y  C ▼ al a al ▼...
  • Page 86 MENU Select character dimension How to enter How to How to save browse and exit 1. Off ▲ l1 First row of header E-3-2 2. On ▼ N Visible only on l l 3 ▲ l 4 ▼ Page 54 Page 54 Cha1 ▼...
  • Page 87 MENU Programming example How to enter How to How to save 1 32 72 browse and exit 1. Off ▲ H E L L O 2. On ▼ ▲ 2 32 9 Page 54 Page 54 3 32 7  C 4 32 7...
  • Page 88 MENU Daa Data Settings How to enter How to How to save browse and exit 1. Off ▲ Select the weight data 2. On ▼ aa ▲  y Page 54 Page 54 ▼ ▼   C ▼ a a...
  • Page 89: Ticket Settings

    MENU ck Ticket Settings How to enter How to How to save browse and exit Configure Ticket/label progressive number (1 to 99.999) 1. Off ▲ Visible only if (D-1-1 ,D-2-1, D-3-1, D-5-1, D-7-1 or  p p8 2. On ▼ D-8-2).
  • Page 90 MENU How to enter How to How to save browse and exit mfm Time Format 1. Off ▲ 2. On ▼ Select the date format ▲ Page 54 Page 54 mfm 24 h ▼  C 12 h a al CCK la...
  • Page 91 MENU C39 Barcode 39 Settings How to enter How to How to save browse and exit Bar code 39 1. Off ▲ aC 39 2. On ▼ E-10  ▲ Page 54 Page 54 ▼ y  C ▼ a ...
  • Page 92 MENU aCh Barcode Height Settings How to enter How to How to save browse and exit Barcode height (mm) Visible only if aC39 1. Off ▲ active 2. On ▼ Default = 10  aCh ▲ E-13 (1...99) m=Ck (...255) m=lal Page 54 Page 54...
  • Page 93 MENU c End Ticket Configuration How to enter How to How to save browse and exit This parameter configures the end of the printout: 1. Off ▲ • For thermal printers (D-1-1 ,D-2-1, D-3-1, D-5-1, D-6-2, D-7-1 or D-8-2 2. On ▼...
  • Page 94 MENU lal Label Settings How to enter How to How to save browse and exit Label configuration 1. Off ▲ Visible if = (D-1-1 ,D-2-1, D-3-1, D-5-1, D-6-2, D-7-1 or al 2. On ▼ D-8-2) . ▲ lal E-18 Page 54 Page 54 wh 3...
  • Page 95 MENU BV Label Save How to enter How to How to save browse and exit Saves labels in printer memory. If the label is saved successfully, the labeler 1. Off ▲ produces an auditory confirmation and causes the LEDs to blink briefly. 2.
  • Page 96: Level

    MENU l F. Inclinometer Configuration How to enter How to How to save browse and exit  Port Configuration 1. Off ▲ 2. On ▼ Product not legal for trade. ▲ Page 54 Page 54 Select the port the inclinomoter is connected to ...
  • Page 97 MENU CC Calculation How to enter How to How to save browse and exit Product not legal for trade. 1. Off ▲ 2. On ▼ requires measuring each side of an object with an inclinometer CC ▲ attached to complete calibration. The following is an example of the Page 54 Page 54 sides that would be measured on a object.
  • Page 98 MENU Displays the current inclination value. Measure all sides (the order of sides does not matter). Repeat How to enter How to How to save browse and exit the measurement for each side (4). 1. Off ▲ 2. On ▼ ▲...
  • Page 99: Zero Settings

    MENU Z Zero Settings How to enter How to How to save browse and exit Acquisition of the zero point of inclination. 1. Off ▲ 2. On ▼ Visible only if ≠ ff. ▲  Product not legal for trade. Page 54 Page 54 Z...
  • Page 100: Filter

    MENU fl G. Weighing filters How to enter How to How to save browse and exit 1. Off ▲ To change the responsiveness of the scale. 2. On ▼ This is useful to adjust the scale according to your needs. ▲...
  • Page 101: Screen

    MENU C H. Adjusting the Display How to enter How to How to save browse and exit akl Backlight settings 1. Off ▲ 2. On ▼ ak l ▲ Page 54 Page 54  ▼ y Always on  C ▼...
  • Page 102 MENU Cl Backlight Color Settings How to enter How to How to save browse and exit 1. Off ▲ Cl 2. On ▼ ▲ Cl1 Cl1 = Red Cl2 = Green Page 54 Page 54 ▼ Cl3 = Yellow Cl4 = Blue Cl5 = Purple...
  • Page 103: Batt

    MENU a I. Battery Power Supply How to enter How to How to save browse and exit 1. Off ▲ a 2. On ▼  ▲ Page 54 Page 54 ▼ ▼ p lithium polymer (LiPo) battery  C ca a...
  • Page 104: Remote

     a     Remote Control Port Settings   a CO1 aC ▼ ▼ CO2  For remote control pairing information, see the DFWX Series User manual. NOTE: For more information about the external module see, page...
  • Page 105: Analogue Output

    MENU  L. Analogue Output How to enter How to How to save browse and exit 1. Off ▲ 2. On ▼ ▲ Operation proportional to net/gross weight Page 54 Page 54  Proportional to net weight y  C ▼...
  • Page 106 V / mA MENU   How to enter How to How to save browse and exit    1. Off ▲ 2. On ▼    ▲ Page 54 Page 54    C   a...
  • Page 107: Input Configuration

    MENU Adjust the analogue output by increasing or decreasing the value. Minimum variations of at least 10 points are recommended, (231, 232, How to enter How to How to save 233, etc.) browse and exit 1. Off ▲ How to set the value 2.
  • Page 108: Output

    MENU p N. Digital Outputs How to enter How to How to save browse and exit 1. Off ▲ Operation on net weight, gross weight or batching 2. On ▼ ▲ fC N-1-1  The function is disabled Page 54 Page 54 ▼...
  • Page 109 MENU Output activation mode How to enter How to How to save browse and exit C N-1-3 When a point is reached, 1. Off ▲ outputs activates 2. On y ▼ regardless if weight is ▲ stable or unstable ▼ Page 54 Page 54 ...
  • Page 110: Reset

    MENU  O. Factory Configuration Reset How to enter How to How to save browse and exit 1. Off ▲ Function for restoring default ?  configurations keeping the 2. On ▼ stored calibration. a ▲ Page 54 Page 54 a...
  • Page 111 MENU Converter test. Checks signal in ADC points. aCp In case of multiple equalised channels, press P-11 How to enter How to How to save ▲ browse and exit buttons to examine all the channels ▼ 1. Off ▲ selected. 2.
  • Page 112: Advanc

    MENU aC Q. Advanced How to enter How to How to save browse and exit 1. Off ▲ Calibration parameters C 2. On ▼ ▲ Decimal point position (...3) Page 54 Page 54 Cm Q-1-1   C ▼    a...
  • Page 113 MENU Unit of measure How to enter How to How to save  m  browse and exit Q-1-3 1. Off ▲  2. On ▼ ▼ ▲ k Page 54 Page 54 ▼   C ▼ a l al ▼...
  • Page 114 MENU How to enter How to How to save For multi-range scales, set the second weighing range. browse and exit 1. Off ▲   a2 How to set the value Q-1-6 2. On ▼ ▲ ▲ ▼ a3 Page 54 Page 54 Example of multi-range configuration at 1500/3000 kg, division 0,5/1 ...
  • Page 115 MENU Equalisation qalp How to enter How to How to save browse and exit NOTE: is only visible if the function (Q-1-7) is activat- 1. Off qalp qal ▲ ed in the menu (Q-1-1). Ca 2. On ▼ ▲ The equalisation wizard requests to acquire the zero point with scale unloaded and to later place a weight of about 1/8 of the maximum capacity Page 54 Page 54...
  • Page 116 MENU Ca Multi-point Calibration \ Linearization (1001 + F) How to enter How to How to save browse and exit NOTE: Before calibrating, configure the decimals (C - Q-1-1), 1. Off ▲ the division ( - Q-1-2) and the capacity (a...
  • Page 117 MENU fl Stability Filter (Internal Use Only) How to enter How to How to save browse and exit 1. Off ▲  fl 2. On ▼ Stability time in ms ▲ m (...2) Page 54 Page 54 ▼ Scale Divisions a...
  • Page 118 MENU ml Metrological Parameters How to enter How to How to save browse and exit ZERO key zeroing percentage 1. Off ▲ 2. On ▼ 2  pC With approved scale (...2) Q-6-1 ▲ With non-approved scale   (...5) Page 54 Page 54 ...
  • Page 119 MENU Zero tracking sensitivity How to enter How to How to save browse and exit The number of stable scale division automatically zeroed by the time config- 1. Off ▲ ured in the k  p parameter 2. On ▼ ▲...
  • Page 120 MENU Start-up Auto Zeroing function and auto zeroing maximum percentage How to enter How to How to save browse and exit z Q-6-6 1. Off ▲ 2. On ▼  ▲ ▼ Page 54 Page 54 y ▼ C pC 1...
  • Page 121  k  p Tilt sensor managed (nor-  C  mally closed) al z ▼ pC Calaj aC p Calma NOTE: If the indicator is approved, this step is read-only. fl  NOTE: The DFWX only accepts Dini Argeo Title Sensors.
  • Page 122 MENU Reactivation of the print function. This function avoids accidental double exe- How to enter How to How to save cution of the same operation (printout or totalization). browse and exit 1. Off ▲ 2. On ▼ ▲ aC Page 54 Page 54 z...
  • Page 123 MENU Alibi memory reset How to enter How to How to save browse and exit ? Only visible if alibi al  Q-11 1. Off ▲ memory option is 2. On ▼ pC present ▲ Reset is not possible if instrument is legal Page 54 Page 54 for trade...
  • Page 124: Update Firmware

    29. FIRMWARE UPDATE Verify Firmware Version Visit www.diniargeo.com to review DFWX "Last Firmware Revision News" and determine the most current firmware version. Restart the DFWX. Press and hold when 888888 displays. Release the button. Select from the menu. prG.ver diAG 888888 diaG adC.uv...
  • Page 125 9. The firmware update software briefly processes the update and then begins to update the firmware. 10. The firmware progress bar fills as the instrument is updated. 11. When firmware has been updated, the progress bar is filled and a success prompt displays. 12.
  • Page 126: Silo Calibration

    30. SILO CALIBRATION Silo calibration is comprised of three different calibrations: Reference, Zero Acquisition, and Span Acquisition. Zero Acquisition and Span Acquisition can be completed at different instances. For example, it is not uncommon to complete Zero Acquisition and then Span Acquisition the following day.
  • Page 127: Communication Strings

    31. COMMUNICATION STRINGS Short String 01ST,GS, 0.0,kg<CR><LF> where Code 485 of the instrument (2 characters), only if communication mode 485 is enabled Scale status (2 characters): US - Unstable weight ST - Stable weight NOTE: If parameter ZER.STR is enabled (D-9-5), ZR (Zero status) replaces the ST status when the weight is in zero range (the →0←...
  • Page 128 Extended String and Extended String 2 011, ST, 0.0,PT 20.8, 0, 00.00000,kg,-----<CR><LF> where Code 485 of the instrument (2 characters), only if communication mode 485 is enabled ASCII 049 character ASCII 044 character Scale status (2 characters): US - Unstable weight ST - Stable weight NOTE: If parameter ZER.STR is enabled (D-9-5), ZR (Zero status) replaces the ST status when the weight is in zero range (the →0←...
  • Page 129: Custom String

    Custom String Configuration can only be carried out using DiniTools in the “CUSTOM STREAM FORMATTING” section. The maximum length of the string configuration field is 100 characters. Fixed alphanumeric characters or variable macros may be used inside. There are also “tokens” that define the characters that a variable (<>) will become in the string when the indicator is in weighing mode.
  • Page 130: Available Token

    Available Token Token Format Description Token value (standard) Weight sign Sign of the displayed The string will show the character <P> weight set in tokens: <PG> Sign of the gross weight Positive polarity token “<P>” “SPACE” if the weight is positive <PN>...
  • Page 131: Bits

    Bits Bit used Type Name Description Fixed Bit value = 0 Used to complete the byte Fixed Bit value = 1 Used to complete the byte Variable Net weight 1 if the displayed weight is net 0 if the displayed weight is gross Variable Weight equals to zero 1 if the gross weight is equal to zero (zero indication on the screen)
  • Page 132 Example of custom string configuration to replicate the standard Dini Argeo string: String definition <S>,<M>,<P><W7.>,<U><CR><LF> Gross mode token “<M>” Net mode token “<M>” Tare mode token “<M>” Preset tare weight token “<M>” Unit token “<U>” Depending on the unit of measure Positive polarity token “<P>”...
  • Page 133: Communication Commands

    32. COMMUNICATION COMMANDS in the serial commands and the respective responses Address 485 of the instrument (2 characters), only if communication mode 485 is enabled ASCII terminator character 13 (0D) (1 character) <CR> ASCII terminator character 10 (0A) (1 character) <LF>...
  • Page 134 SPECIFIC COMMANDS FOR ALIBI MEMORY (OPTIONAL ON DFWX/DFWXB) Save Requests nnPID<CR><LF> request to save the weighing Command successful registration Response nnPIDss,c,wwwwwwwwwwuu,ppttttttttttuu,xxxxx-yyyyyy<CR><LF> no registration nnPIDss,c,wwwwwwwwwwuu,ppttttttttttuu,NO<CR><LF> where: weight status (2 characters) Tilt error condition (NO RECORDING) Overload condition (NO RECORDING) Underload condition (NO REGISTRATION) Stable weight Unstable weight (NO RECORDING) Scale number (1 character)
  • Page 135: Programming Errors

    33. PROGRAMMING ERRORS MESSAGE DESCRIPTION SOLUTION Check the presence of the board inside the al.err “Alibi memory” board (optional) not detected indicator. If present, check it is not damaged and is installed correctly. Check the presence of the board inside the er.1.b.x indicator.
  • Page 136: Faq - Frequently Asked Questions

    34. FAQ - FREQUENTLY ASKED QUESTIONS Calibration Can I change the maximum capacity without recalibrating? Yes, change the parameters (Q-1-5, Q-1-6, Q-1-7) (see page 113). RANGE 1,2,3 Can I change the division without recalibrating? Yes, change the parameter (Q-1-4) (See page 113) Can I change the position of the decimal point without recalibrating? Yes, change the parameter (Q-1-1) and the value of the calibration points...
  • Page 137: Battery Removal

    35. BATTERY REMOVAL This section discusses how to remove and replace batteries found in DFWX series indicators. Depending on options, DFWX indicators can contain up to two batteries: • 3V CR2032 battery on optional ALIBI module. • 3.7V LiPo battery is standard in DFWXB, DFWXXB-HGX, DFWXB-WiFi and DFWXB-WIF-HGX models...
  • Page 138 Turn off the indicator. Disconnect the indicator power cable from the power outlet. Place instrument on an anti-static surface. Use a 7 mm wrench to remove retaining nuts on instrument's back panel. Set back panel aside. CAUTION: Handle the back panel carefully as it is attached to the indicator's ground circuit. CAUTION: A ground wire is attached to the back panel, detach ground retaining nut and wire with 5.5 mm wrench if needed.
  • Page 139 Observe the two battery access slots on the rear of the battery bracket. Carefully push the battery from the rear access slots with non-conductive tool until it slides out of the battery bracket. Insert a new battery with negative side toward PCB and positive side toward back cover. Reinstall cover using retaining nuts and 7 mm wrench.
  • Page 140: Battery Removal/Replacement

    (ESD) when working inside the enclosure or removing parts from the enclosure. WARNING: Dispose of battery to according local laws and regulations. WARNING: When replacing the battery, use original batteries supplied by Dini Argeo. Battery Removal Procedure Turn off the indicator.
  • Page 141 Remove back panel retaining nuts with a 7 mm wrench. CAUTION: A ground wire is attached to the back panel, detach ground retaining nut and wire with 5.5 mm wrench if needed. Disconnect the battery cable from battery charging board on J2 (see wiring digram on page 20).
  • Page 142 Remove the Phillips screw retaining the battery mounting bracket. NOTE: This mounting screw also holds the power supply in place on one side. Ensure to reattach the mounting screw if the battery is not replaced. Detach the hex standoff retaining the battery mounting bracket.
  • Page 143 Carefully remove the battery and bracket from the enclosure. WARNING: Risk of fire and explosion. Do not burn, crush, disassemble or short-circuit batteries. Battery replacement: Reverse the previous procedure, ensuring the battery power cable faces up. When complete, plug charging cable in J2 in the battery charging board.
  • Page 144 NOTES This publication, or portions thereof, may not be duplicated without written permission from the Manufacturer. All information contained in this manual is based on the data available at the time of its publication; the Manufacturer reserves the right to make changes to its products at any time without notice and without incurring any penalty.
  • Page 145 NOTES DFWX...
  • Page 146 NOTES DFWX...
  • Page 147 NOTES DFWX...
  • Page 148 Stamp of the authorised service centre HEAD OFFICE Via Della Fisica, 20 41042 Spezzano di Fiorano, Modena - Italy Tel. +39 0536 843418 - Fax +39 0536 843521 SERVICE ASSISTANCE Via Dell’Elettronica, 15 41042 Spezzano di Fiorano, Modena - Italy Tel.

Table of Contents
