Haws 7460 Axion Installation Operation & Maintenance

Eye wash

Download this manual

HAWS AG • Bachweg 3 • CH-3401 Burgdorf • Switzerland • www.haws.ch

HAWS Corporation • P.O.Box 2070 • 1455 Kleppe Lane • Sparks,Nevada 89431/USA www.hawsco.com

Model

7460 Axion

NOTE TO INSTALLER: please leave this information with the maintenance department.

1 1/4" G

Waste

THESE DIMENSIONS MAY VARY +/- 12,7mm (1/2")

SCALE 1:8

Legally-stipulated dimensions:

Ensure that there is a minimum clearance of 150mm (6") with respect to the nearest

wall or obstacle.

Height above floor level: 800mm - 1200mm (2' 7 1/2" - 3' 11 1/4").

Free access to the eywash station 7460 Axion must be guaranteed all times. The operator

is responsible for the observance of this requirement.

Jeannine Ruf

HAWS DRINKING FAUCET COMPANY

INSTALLATION, OPERATION & MAINTENANCE INSRUCTIONS

Eye Wash

300 1

7460 Axion

376

112

1/2" G

Supply

•

No.

2080056

1/4

10.10.2011

Need help?

Do you have a question about the 7460 Axion and is the answer not in the manual?

Page 1 Height above floor level: 800mm - 1200mm (2' 7 1/2" - 3' 11 1/4"). Free access to the eywash station 7460 Axion must be guaranteed all times. The operator is responsible for the observance of this requirement.
Page 2 Eye Wash 2080056 Shower location: The eyewash station 7460 Axion must be installed in the vicinity of potential danger zones. It must be highly visible and easily accessible. Connection conduit: You are recommended to use a 1/2" G conduit, capable of withstanding pressures of 2 - 6 BAR (30 - 90 PSI).
Page 3 PART NO. 2080056 THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR HEREWITH IS NOT TO BE REPRODUCED, USED, OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT ECN NO. SHEET 3 OF 4 THE PERMISSION OF HAWS CORPORATION. SCALE 1:7...
Page 4 PART NO. 2080056 THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR HEREWITH IS NOT TO BE REPRODUCED, USED, OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT ECN NO. SHEET 4 OF 4 THE PERMISSION OF HAWS CORPORATION. SCALE 1:7...
