Haws AXION 7260B Installation, Operation & Maintenance Instructions

Eye/face wash

Download this manual

NO. OOO2076521 (0)

INSTALLATION, OPERATION

MAINTENANCE INSTRUCTIONS

Bachweg 3, 3400 Burgdorf, Switzerland

Phone +41 (0) 34 420 60 00 Fax +41 (0) 34 420 60 01

E-mail:

info@haws.ch

website:

www.haws.ch

No. 02080038 (1)

Model 7260B AXION

(Item Number 10004428)

Eye/Face Wash

NOTE TO INSTALLER: Please leave this information with the Maintenance Department.

SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS

MODEL PLEASE CALL:

+41 (0) 34 420 60 00

CUSTOMER SUPPORT:

LOCATION OF UNIT: The Model 7260B AXION Eyewash units should be

installed in close proximity to potential accident areas. It should be clearly

identified, free from obstructions and easy to access.

SUPPLY LINE: The minimum recommended line size is 1/2" G with 30-90 psi (2-6

ATM) flowing pressure. Where sediment or mineral content is a problem, an inlet

filter is recommended.

PLUMBING CONNECTIONS: The inlet supply is female 1/2" G, the waste outlet is

1-1/4" O.D. tailpiece.

11/24

Model 7260B AXION

Page 1 of 4

Need help?

Do you have a question about the AXION 7260B and is the answer not in the manual?

Page 1 NO. OOO2076521 (0) INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS Bachweg 3, 3400 Burgdorf, Switzerland Phone +41 (0) 34 420 60 00 Fax +41 (0) 34 420 60 01 E-mail: info@haws.ch website: www.haws.ch No. 02080038 (1) Model 7260B AXION (Item Number 10004428) Eye/Face Wash NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
Page 2 For more information about Haws products, see our website: www.haws.ch ® © 2024 Haws Corporation – All Rights Reserved ® HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation. 11/24 Model 7260B AXION Page 2 of 4...
Page 3 APPROVED: DATE: SCALE: DRAWING TYPE: PARTS BREAKDOWN SIZE: A SHEET 1 OF 1 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation. PAGE 3 OF 4...
Page 4 DIMENSIONS IN BRACKETS, IN DRAWING SPACE, ARE METRIC [mm]. APPROVED: DATE: 11/12/2024 SCALE: 1:2.5 DRAWING TYPE: INSTALLATION SIZE: A SHEET 1 OF 1 © 2024 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
