Haws 7260 Axion Installation Operation & Maintenance

Eye wash

Download this manual

HAWS AG • Bachweg 3 • CH-3401 Burgdorf • Switzerland • www.haws.ch

HAWS Corporation • P.O.Box 2070 • 1455 Kleppe Lane • Sparks,Nevada 89431/USA www.hawsco.com

Model

7260 Axion

NOTE TO INSTALLER: please leave this information with the maintenance department.

THESE DIMENSIONS MAY VARY +/- 12,7mm (1/2")

SCALE 1:10

Legally-stipulated dimensions:

Ensure that there is a minimum clearance of 150mm (6") with respect to the nearest

wall or obstacle.

Height above floor level: 800mm - 1200mm (2' 7 1/2" - 3' 11 1/4").

Free access to the eywash station 7260 Axion must be guaranteed all times. The operator

is responsible for the observance of this requirement.

Jeannine Ruf

HAWS DRINKING FAUCET COMPANY

INSTALLATION, OPERATION & MAINTENANCE INSRUCTIONS

Eye Wash

285 1

1/2" G

Supply

1 1/4" G

Waste

7260 Axion

•

No.

377

112

2080036/1

1/4

13.09.2011

Need help?

Do you have a question about the 7260 Axion and is the answer not in the manual?

Page 1 Height above floor level: 800mm - 1200mm (2' 7 1/2" - 3' 11 1/4"). Free access to the eywash station 7260 Axion must be guaranteed all times. The operator is responsible for the observance of this requirement.
Page 2 Eye Wash 2080036/1 Shower location: The eyewash station 7260 Axion must be installed in the vicinity of potential danger zones. It must be highly visible and easily accessible. Connection conduit: You are recommended to use a 1/2" G conduit, capable of withstanding pressures of 2 - 6 BAR (30 - 90 PSI).
Page 3 REV. 2080036/1 THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR HEREWITH IS NOT TO BE REPRODUCED, USED, OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT ECN NO. SHEET 3 OF 4 SCALE 1:10 THE PERMISSION OF HAWS CORPORATION.
Page 4 REV. 2080036/1 THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR HEREWITH IS NOT TO BE REPRODUCED, USED, OR DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT ECN NO. SHEET 4 OF 4 SCALE 1:10 THE PERMISSION OF HAWS CORPORATION.
