- Page 1 Industrial Spare Parts Customer Support www.argos-support.co.uk 0345 640 2020 Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 29/08/20...
- Page 2 Safety and Care Advice Product Details 2001629-HAB TURNER RAIL BLACK - SINGLE 1175738-HAB TURNER RAIL WHITE - SINGLE IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. • Keep children and animals away • Assemble the item as close to • We do not...
- Page 3 Fittings (Shown to scale) Bag 1 35mm Double Ended 32mm Screw x4 40mm Screw x8 Machine Screw x2 Allen Key x1...
-
Page 4: Tools Required
Tools required Phillips screwdriver Ruler/tape (small & medium) measure Mallet Eye protection (when using a hammer or glue) - Page 5 Panels Top Rail x 1 Support Bar x 2 Side Bars x 2 (44cm x 2.2cm) (43.5cm x 2cm) (150cm x 45cm) Shoe Rack x 1 Shelf x 1 Rail End x 2 (43.5cm x 40.6cm) (43.3cm x 36cm) (4.5cm x 2.2cm)
- Page 6 35mm Double Ended 32mm Screw x4 40mm Screw x8 Machine Screw x2 Allen Key x1 35mm Double EndedMachine Screw x2...
- Page 7 32mm Screw x4 Allen Key x1 40mm Screw x8...
- Page 8 Assembly Is Complete...
