Summary of Contents for STATESMAN EDC60B2
- Page 1 Double Oven / User Manual EDC60B2 EDC60S2 EDC60W2...
- Page 2 Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference. Icon Type Meaning...
-
Page 3: Table Of Contents
CONTENTS 1.SAFETY INSTRUCTIONS ....................4 1.1 General Safety Warnings ...................4-6 1.2 Installation Warnings ......................7 1.3 During Use ........................7-9 1.4 During Cleaning and Maintenance ................9-10 Disposal of your old machine....................10 2.INSTALLATION AND PREPARATION FOR USE ............11 2.1 Instructions for the Installer ..................11 2.2 Electrical Connection and Safety..................12 2.3 Anti-tilting kit .........................13 2.4 Adjusting the feet ......................13... -
Page 4: Safety Instructions
1. SAFETY INSTRUCTIONS • Carefully read all instructions before using your appliance and keep them in a convenient place for reference when necessary. • This manual has been prepared for more than one model therefore your appliance may not have some of the features described within. - Page 5 WARNING: Danger of fire: Do not store items on the cooking surfaces. WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. • For models which incorporate a hob lid, clean any spillages off the lid before use and allow the cooker to cool before closing the lid.
- Page 6 • Your appliance is produced in accordance with all applicable local and international standards and regulations. • Maintenance and repair work should only be carried out by authorised service technicians. Installation and repair work that is carried out by unauthorised technicians may be dangerous.
-
Page 7: Installation Warnings
• Please keep children and animals away from this appliance. 1.2 inStallation WarninGS • Do not operate the appliance before it is fully installed. • The appliance must be installed by an authorised technician. The manufacturer is not responsible for any damage that might be caused by incorrect placement and installation by unauthorised people. - Page 8 • Take care when opening the oven door during or after cooking. The hot steam from the oven may cause burns. • Do not put flammable or combustible materials in or near the appliance when it is operating. • Always use oven gloves to remove and replace food in the oven.
-
Page 9: During Cleaning And Maintenance
• Do not place heavy or flammable items (e.g. nylon, plastic bags, paper, cloth, etc.) into the drawer. This includes cookware with plastic accessories (e.g. handles). CAUTION: The inside surface of the storage compartment may get hot when the appliance is in use. -
Page 10: Disposal Of Your Old Machine
Disposal of your old machine This symbol on the product or on its packaging indicates that this product should not be treated as household waste. Instead it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 11: Installation And Preparation For Use
2. INSTALLATION AND dryer. PREPARATION FOR USE • The appliance can be placed close to other furniture on condition that, in the WARNING : This appliance must be area where the appliance is set up, the installed by an authorised service furniture’s height does not exceed the person or qualified technician, height of the cooktop. -
Page 12: Electrical Connection And Safety
2.2 eleCtriCal ConneCtion anD Safety • If the appliance is not connected to the mains with a plug, a all-pole WARNING: The electrical connection disconnector (with at least 3 mm contact of this appliance should be carried out spacing) must be used in order to meet by an authorised service person or the safety regulations. -
Page 13: Anti-Tilting Kit
• Green/Yellow (Earth) wire to the terminal marked "PE". • Brown (Live) wire to the terminal Wall Anti- marked "L". tilting bracket • Blue (Neutral) wire to the terminal marked "N". • For this connection, a ‘Twin and Earth 6242Y’ type cable should be used. Product Dimensions A (mm) B (mm) -
Page 14: Product Features
3. PRODUCT FEATURES Important: Specifications for the product vary and the appearance of your appliance may differ from that shown in the figures below. List of Components 1. Cooktop 2. Control Panel 3. Top Oven Door Handle 4. Top Oven Door 5. -
Page 15: Use Of Product
4. USE OF PRODUCT decreased or until one of the cooking zones is activated. 4.1 hob ControlS Hints and Tips Ceramic Heater Important: When ceramic heaters are The ceramic heater is controlled by a 6 operated in higher heat settings, the position knob. -
Page 16: Main Oven Functions
well away from the hob during operation heating elements ensures that food is and until it has fully cooled after cooked evenly. You will find this setting operation. ideal for cooking cakes, baked pasta, lasagne, and pizza. We recommend that •... -
Page 17: Cleaning And Maintenance
within a deep tray. It is recommended to use this accessory for grilling steaks, meatballs and similar food. 5. CLEANING AND MAINTENANCE 5.1 CleaninG The Deep Tray WARNING: Switch off the appliance The deep tray is best used for cooking and allow it to cool before cleaning is stews. - Page 18 Cleaning the Glass Parts • Clean the glass parts of your appliance on a regular basis. • Use a glass cleaner to clean the inside and outside of the glass parts. Then, rinse and dry them thoroughly with a dry cloth.
- Page 19 Removal of the Inner Glass Removal of the Oven Door You must remove the oven door glass Before cleaning the oven door glass, you must remove the oven door, as shown before cleaning, as shown below. below. 1. Push the glass in the direction of B and 1.
-
Page 20: Maintenance
5.2 MaintenanCe When contacting our Authorised Service WARNING: The maintenance of this Centre, Ensure you have the following appliance should be carried out by an authorised service person or qualified data information: Model, Serial number. technician only. This information can be found on the rating Changing the Oven Lamp plate. -
Page 21: Troubleshooting &Transport
6. TROUBLESHOOTING & TRANSPORT 6.1 troubleShootinG If you still have a problem with your appliance after checking these basic troubleshooting steps, please contact an authorised service person or qualified technician. Problem Possible Cause Solution Check the household fuse for the appliance. The hob or cooking zones There is no power supply. -
Page 22: Technical Specifications
7. TECHNICAL SPECIFICATIONS 7.1 enerGy fiChe Brand Model EDC60B2 EDC60S2 EDC60W2 Type of Oven ELECTRIC Mass 49,3 Upper Energy Efficiency Index - conventional 106,3 Cavity Energy Efficiency Index - fan forced Energy Class Energy consumption (electricity) - conventional kWh/cycle 0,75... -
Page 23: Energy Fiche
7.2 enerGy fiChe Brand Model EDC60B2 EDC60S2 EDC60W2 Type of Hob Electric Number of Cooking Zones Heating Technology-1 Hotplate Size-1 Ø14,5 Energy Consumption-1 Wh/kg 193,0 Heating Technology-2 Hotplate Size-2 Ø14,5 Energy Consumption-2 Wh/kg 194,0 Heating Technology-3 Hotplate Size-3 Ø18,0 Energy Consumption-3... - Page 24 UK Address: Statesman 38 Bluestem Road, Ipswich, IP3 9RR EU Address: Castle Electrical Factors Ltd, Dundalk, A91 KA9R, IR 52000000...
