Sears CRAFTSMAN 944.604390 Repair Parts Manual

Sears CRAFTSMAN 944.604390 Repair Parts Manual

24.0 hp electric start 48" mower automatic transmission lawn tractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REPAIR
PARTS
MANUAL
MODEL NO.
944.604390
IMPORTANT:
Read and fol low
all Safety Rules
and In struc tions
Be fore Op er at ing
This Equip ment
* The power rating as declared by the engine manufacturer is the average gross power output at the specifi ed RPM of a typical production engine for the engine model mea-
sured using SAE Standards for engine gross power. Please refer to the engine manufacturer for details.
587756224 Rev. 9
24.0 HP
ELECTRIC START
48" MOWER
AUTOMATIC TRANSMISSION
LAWN TRACTOR
Sears Canada, Inc., Toronto, Ontario M5B 2B8
*
11.09.15 BD/TH
Printed in the U.S.A.
