Natural gas conversion kit
Hide thumbs Also See for 814-6805-S:
Table of Contents

Advertisement

Quick Links

Download this manual
Equipo de Conversión a Gas Natural
PROFESSIONAL INSTALLATION MANUAL
MANUAL DE INSTALACIÓN PROFESIONAL
CONVERTS THE FOLLOWING CHARMGLOW GRILLS FROM PROPANE TO
NATURAL GAS: MODEL NUMBERS 810-1750-S, 810-8501-S, 810-9520-S,
810-6805-S, 814-6805-S, 814-6807-S, 810-1880-S AND 810-8533-S
IF YOU DO NOT HAVE THE PROFESSIONAL INSTALLATION MANUAL, PLEASE
CONVIERTE LAS SIGUIENTES PARRILLAS CHARMGLOW DE PROPANO A GAS
NATURAL: NÚMEROS DE MODELO 810-1750-S, 810-8501-S, 810-9520-S,
SI USTED NO TIENE EL MANUAL PROFESIONAL DE INSTALACIÓN, VISITE
POR FAVOR WWW.BRINKMANN.NET O LA LLAMADA (800) 527-0717.
WARNING
HAZARDOUS EXPLOSION MAY RESULT IF THESE
WARNINGS AND INSTRUCTIONS ARE IGNORED. READ
AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN
THIS MANUAL TO AVOID PERSONAL INJURY,
INCLUDING DEATH OR PROPERTY DAMAGE.
Natural Gas Conversion Kit
VISIT WWW.BRINKMANN.NET OR CALL (800) 527-0717.
810-6805-S, 814-6805-S, 814-6807-S, 810-1880-S Y 810-8533-S
ASSEMBLY AND OPERATING INSTRUCTIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
GUARDE ESTE MANUAL PARA REFERENCIA FUTURA
INSTRUCCIONES AL PROPIETARIO
ADVERTENCIA
SE PUEDE PRODUCIR UNA EXPLOSIÓN PELIGROSA SI SE
HACE CASO OMISO A ESTAS ADVERTENCIAS E
INSTRUCCIONES. LEA Y SIGA TODAS LAS ADVERTENCIAS
E INSTRUCCIONES EN ESTE MANUAL PARA EVITAR
LESIONES PERSONALES, INCLUSO LA MUERTE, O LOS
DAÑOS MATERIALES.
NOTICE TO
PROFESSIONAL INSTALLER:
LEAVE THESE INSTRUCTIONS WITH
THE GRILL OWNER FOR FUTURE
REFERENCE.
AVISO PARA EL
INSTALADOR:
ENTREGUE ESTAS
DE LA PARRILLA PARA
REFERENCIA FUTURA.
