CC-Link IE TSN Analog-Digital Converter Module
User's Manual
(CC-Link IE TSN Communication Mode)
-NZ2GN2S-60AD4
-NZ2GN2B-60AD4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NZ2GN2S-60AD4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitsubishi Electric NZ2GN2S-60AD4

  • Page 1 CC-Link IE TSN Analog-Digital Converter Module User's Manual (CC-Link IE TSN Communication Mode) -NZ2GN2S-60AD4 -NZ2GN2B-60AD4...
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS (Read these precautions before using this product.) Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle the product correctly. The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable controller system, refer to the user's manual for the CPU module used.
  • Page 4 [Installation Precautions] WARNING ● Shut off the external power supply (all phases) used in the system before mounting or removing a module. Failure to do so may result in electric shock or cause the module to fail or malfunction. [Installation Precautions] CAUTION ●...
  • Page 5 [Wiring Precautions] CAUTION ● When disconnecting the cable from the module, do not pull the cable by the cable part. For the cable with connector, hold the connector part of the cable. For the cable connected to the terminal block, loosen the terminal screw.
  • Page 6: Conditions Of Use For The Product

    Notwithstanding the above restrictions, Mitsubishi Electric may in its sole discretion, authorize use of the PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific applications agreed to by Mitsubishi Electric and provided further that no special quality assurance or fail-safe, redundant or other safety features which exceed the general specifications of the PRODUCTs are required.
  • Page 7: Introduction

    To operate the A/D converter module in CC-Link IE TSN communication mode, set the function setting switch 1 to OFF. ( Page 28 Setting the function setting switches) Relevant products NZ2GN2S-60AD4, NZ2GN2B-60AD4 Unless otherwise specified, this manual describes the program examples in which the remote I/O signals and remote registers are assigned for an A/D converter module as follows.
  • Page 8: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ..............1 CONDITIONS OF USE FOR THE PRODUCT .
  • Page 9 A/D Conversion Method ..............66 Range Switching Function .
  • Page 10 Appendix 10How to Check Production Information and Firmware Version ......213 Checking the production information ............213 Checking the firmware version .
  • Page 11: Relevant Manuals

    RELEVANT MANUALS The following manuals are relevant to this product. Manual name [manual number] Description CC-Link IE TSN Analog-Digital Converter Module User's Part names, specifications, procedures before operation, system configuration, installation, Manual (CC-Link IE TSN Communication Mode) wiring, parameter settings, functions, programming, troubleshooting, I/O signals, and remote [SH-082131ENG] (this manual) buffer memory of the A/D converter module to be used in CC-Link IE TSN communication mode...
  • Page 12: Terms

    TERMS Unless otherwise specified, this manual uses the following terms. Term Description CC-Link IE TSN Class A group of devices and industrial switches compatible with CC-Link IE TSN, ranked according to the functions and performance by the CC-Link Partner Association. For CC-Link IE TSN Class, refer to the CC-Link IE TSN Installation Manual (BAP-C3007ENG-001) published by the CC- Link Partner Association.
  • Page 13: Generic Terms And Abbreviations

    GENERIC TERMS AND ABBREVIATIONS Unless otherwise specified, this manual uses the following generic terms and abbreviations. Generic term/abbreviation Description A/D converter module An abbreviation for the CC-Link IE TSN analog-digital converter module Analog module A generic term for an A/D converter module and a D/A converter module CC-Link IE TSN remote module A generic term for an A/D converter module, a D/A converter module, an I/O module D/A converter module...
  • Page 14: Chapter 1 Part Names

    PART NAMES This chapter describes part names of the A/D converter module. • Spring clamp terminal block type • Screw terminal block type Name Application PW LED Indicates the power supply status of the A/D converter module. • On: Power-on •...
  • Page 15 Name Application A port for the connection to CC-Link IE TSN (RJ45 connector) Connect an Ethernet cable. ( Page 36 Wiring of Ethernet Cable) There are no restrictions on the connection order of the cables for P1 and P2. Same as P1 Terminal block for module power A terminal block for the connection to module power supply (24VDC) and FG.
  • Page 16: Chapter 2 Specifications

    SPECIFICATIONS This chapter describes the specifications of the A/D converter module. General Specifications Item Specifications Operating ambient 0 to 55 temperature Storage ambient -25 to 75 temperature Operating ambient 5 to 95%RH, non-condensing humidity Storage ambient humidity  Vibration resistance Compliant with IEC Frequency Constant...
  • Page 17: Ethernet Communication Specifications

    Ethernet Communication Specifications The following table shows the Ethernet communication specifications for the A/D converter module. Item Description Transmission Data transmission speed • 1Gbps specifications • 100Mbps Communication mode 1000BASE-T Full-duplex 100BASE-TX Interface RJ45 connector (AUTO MDI/MDI-X) Maximum frame size 1518 bytes Maximum segment length 100m...
  • Page 18: Performance Specifications

    Performance Specifications NZ2GN2S-60AD4 Item NZ2GN2S-60AD4 Station type Remote station Communication speed • 1Gbps • 100Mbps CC-Link IE TSN Class • CC-Link IE TSN Class B (factory default) • CC-Link IE TSN Class A CC-Link IE TSN Protocol version CC-Link IE TSN Class B CC-Link IE TSN Protocol version 1.0...
  • Page 19 Item NZ2GN2S-60AD4 Weight 0.13kg *1 The performance specifications vary depending on firmware versions of modules used. ( Page 216 Added and Changed Functions) *2 For details on the I/O conversion characteristics, refer to the following: Page 189 I/O Conversion Characteristics of A/D Conversion *3 Except for the conditions under noise influence.
  • Page 20 NZ2GN2B-60AD4 Item NZ2GN2B-60AD4 Station type Remote station Communication speed • 1Gbps • 100Mbps CC-Link IE TSN Class • CC-Link IE TSN Class B (factory default) • CC-Link IE TSN Class A CC-Link IE TSN Protocol version CC-Link IE TSN Class B CC-Link IE TSN Protocol version 1.0 CC-Link IE TSN Protocol version 2.0 *7*8...
  • Page 21 *1 The performance specifications vary depending on firmware versions of modules used. ( Page 216 Added and Changed Functions) *2 For details on the I/O conversion characteristics, refer to the following: Page 189 I/O Conversion Characteristics of A/D Conversion *3 Except for the conditions under noise influence. *4 This current value is an instantaneous value at which no breakdown occurs in the internal resistance of the module.
  • Page 22: Function List

    Function List This section lists the functions of the A/D converter module. Item Description Reference A/D conversion enable/disable function Allows A/D conversion to be enabled or disabled for each channel. Page 65 A/D Disabling the A/D conversion for unused channels reduces the conversion cycles. Conversion Enable/ Disable Function Page 66...
  • Page 23 Item Description Reference Page 115 Module power supply voltage drop detection Detects voltage drop of the module power supply. function This function makes troubleshooting easy when the voltage of the power supplied Module Power to the A/D converter module drops, or when poor connection in the wiring occurs. Supply Voltage Note that the voltage to be monitored for a module power supply voltage drop is Drop Detection...
  • Page 24: Chapter 3 Procedures Before Operation

    PROCEDURES BEFORE OPERATION This chapter describes the procedures before operation. Setting the IP address/station number setting switches Set the fourth octet of the IP address of the A/D converter module. Page 26 Setting the IP address/station number setting switches Setting the function setting switches Set the network setting function, input range switch enable/disable setting, and range switching function.
  • Page 25 To replace the A/D converter module, follow the procedure described below. • When the input range switch enable/disable setting is disabled, export the parameter setting. This step is not necessary when the device station parameter automatic setting is enabled. • Turn off the A/D converter module power supply and remove the A/D converter module. •...
  • Page 26: Chapter 4 System Configuration

    Install GX Works3 with the following version in accordance with the A/D converter module used. Model Software version NZ2GN2S-60AD4, NZ2GN2B-60AD4 Version 1.055H or later ■CC-Link IE TSN Configurator Setting a communication speed for the A/D converter module and configuring the CC-Link IE TSN Class settings require CC- Link IE TSN Configurator.
  • Page 27: Ethernet Cables

    A profile is required to use the A/D converter module in the CC-Link IE TSN configuration setting. The following table shows the applicable profile versions. Model Firmware version Profile version NZ2GN2S-60AD4, NZ2GN2B-60AD4 "01" or later "00" or later "02" or later "01" or later "03"...
  • Page 28: Chapter 5 Installation And Wiring

    INSTALLATION AND WIRING This chapter describes the installation and wiring of the A/D converter module. Setting Switches Setting the IP address/station number setting switches Set the fourth octet of IP address using the IP address/station number setting switches on the front of A/D converter module. The setting of IP address/station number setting switches is enabled when the A/D converter module is powered on.
  • Page 29: Setting Range

    Setting range The setting value must be in the range between 1 and 254. When a value in the range of 1 to 254 is set, the IP address and subnet mask are as follows. • The first three octets of the IP address: Octets one, two, and three from the IP address of the master station are used for operation.
  • Page 30: Setting The Function Setting Switches

    Setting the function setting switches Use the function setting switches on the front of the A/D converter module to set the network setting function, input range switch enable/disable setting, and range switching function. The setting of the function setting switch is enabled when the A/D converter module is powered on. Therefore, set each function when the module is powered off.
  • Page 31: Operation

    ■Settings of the function setting switch 3 to function setting switch 10 The following table lists the settings of the function setting switch 3 to function setting switch10. Function setting switch 3 to function setting switch 10 Setting 3, 5, 7, 9 4, 6, 8, 10 0 to 20mA 4 to 20mA...
  • Page 32 Restrictions The following table lists the restrictions applied when function setting switch 2 is enabled. Item Description Shift function The shift function cannot be used. CH Shifting amount to conversion value settings (RWw2 to RWw5) are ignored. Initial data setting request flag (RY9) When Initial data setting request flag (RY9) is turned on, an operating condition setting change disable error (error code: 3610H) occurs and the operating condition is not changed.
  • Page 33: Installation Environment And Installation Position

    Installation Environment and Installation Position Installation environment Installation location Do not install the A/D converter module in places where: • Ambient temperature is outside the range of 0 to 55; • Ambient humidity is outside the range of 5 to 95% RH; •...
  • Page 34: Installation Direction

    Installation direction The A/D converter module can be installed in six directions. Use a DIN rail (1) to install the A/D converter module. (1) DIN rail (2) Horizontal installation (3) Downward installation (4) Vertical installation (5) Upward installation (6) Horizontal installation (upside down) 5 INSTALLATION AND WIRING 5.2 Installation Environment and Installation Position...
  • Page 35: Installation

    Installation How to mount a module on a DIN rail Installation procedure Hang the upper tabs of the A/D converter module on the top of the DIN rail. Push in the DIN rail hooks of the A/D converter module until they click. Do not slide a module from the edge of the DIN rail when mounting it.
  • Page 36: Wiring To Terminal Block For Module Power Supply And Fg

    Wiring to Terminal Block for Module Power Supply and FG Tightening torque Tighten the terminal block mounting screws within the following tightening torque range. Tightening the screws too much may damage the A/D converter module case. Screw type Tightening torque range Terminal block mounting screw (M2.5 screw) 0.2 to 0.3Nm Wire to be used...
  • Page 37 Connecting and disconnecting the cable To connect the cable, fully insert a wire with a bar solderless terminal into a wire insertion opening. After inserting the wire, pull it lightly to check that it is securely clamped. Continuity can be checked with test terminal (1). Use the following test plug to check continuity.
  • Page 38: Wiring Of Ethernet Cable

    Wiring of Ethernet Cable Wiring method ■Installation procedure Power off the power supply of the A/D converter module and the power supply of the external device. With attention to the orientation of the cable, push the Ethernet cable connector into the A/D converter module until it clicks.
  • Page 39 Precautions ■Laying Ethernet cables • Place the Ethernet cables in a duct or clamp them. If not, dangling cable may swing or inadvertently be pulled, resulting in damage to the module or cables or malfunction due to poor contact. • Do not touch the core of the connector of the cable or the module, and protect it from dirt and dust. If any oil from your hand, or any dirt or dust sticks to the core, it can increase transmission loss, causing data link to fail.
  • Page 40: Wiring To Analog Input Terminal Block

    Wiring to Analog Input Terminal Block Wiring of spring clamp terminal block Wire to be used The following table describes the wire to be connected to the spring clamp terminal block. Wire diameter Type Material Temperature rating 22 to 16 AWG Stranded Copper 75...
  • Page 41 ■Removal procedure Turn the lever to the release lever position and remove the terminal block from the A/D converter module. ■Installation procedure Move the lever to the lock lever position and push the terminal block. When the terminal block is fully pushed in, the hook of the lever hangs on the module and fits the terminal block.
  • Page 42 Connecting and disconnecting the cable ■Connecting the cable Strip the cable as follows. • The strip length of wire: 10mm Insert a wire whose tip was processed into a wire insertion opening (2) and push it all the way in to the back. If the wire cannot be inserted by this method, insert the wire all the way in to the back while pressing the release button (1) using a flathead screwdriver with a tip width of 2.0 to 2.5mm.
  • Page 43: Wiring Of Screw Terminal Block

    Wiring of screw terminal block Tightening torque Tighten the terminal screws within the following tightening torque range. Tightening the screws too much may damage the A/D converter module case. Screw type Tightening torque range Terminal screw (M35.2 screw) 0.43 to 0.57Nm Terminal block mounting screw (M3.5 screw) 0.68 to 0.92Nm Wire to be used...
  • Page 44: Signal Name

    Signal name The following table lists the signal names of the terminal block.  Item Terminal number Signal name Signal name Terminal number Wiring method Loosen the terminal screw. Connect the round solderless terminal (1) as it is. • Do not put oil on the terminal or screw. Doing so may damage the screw. •...
  • Page 45: External Wiring

    External Wiring Using a voltage input signal Signal source -10 to 10V CH1 to CH4 470kΩ 150kΩ 250Ω 470kΩ 150kΩ Shield *1 Use a 2-core shielded twisted pair cable. *2 Indicates the input resistance of the A/D converter module. *3 In any of the following cases, connect the AG terminal to the GND of the external device. ...
  • Page 46 Precautions To obtain the maximum performance from the functions of the A/D converter module and improve the system reliability, external wiring that is noise resistant is required. Precautions for external wiring are as follows. • Use separate cables for the AC control circuit and the external input signals of the A/D converter module to avoid the influence of the AC side surges or induction.
  • Page 47: Chapter 6 Various Settings

    VARIOUS SETTINGS Network Configuration Setting Set the parameters of the A/D converter module with the network parameters written to the CPU module of the master station. For the setting procedure for the master station, refer to the following.  User's manual for the master station used Communication period interval setting When using the A/D converter module in CC-Link IE TSN, set the communication period interval setting as follows.
  • Page 48 ■When the CC-Link IE TSN Class of the A/D converter module is CC-Link IE TSN Class A Set the value at which the "Basic period (communication period interval setting) Magnification" of the A/D converter module becomes 1ms or more and 1.28 seconds or less. Item Description Basic period (Communication period interval setting)
  • Page 49: Communication Mode

    Network topology setting When using the A/D converter module in CC-Link IE TSN, set the network topology setting as follows. Firmware version of A/D converter module Setting item "03" or later • Line topology, star topology, or mixture of star topology and line topology *1*2 •...
  • Page 50 Window Displayed items Item Setting details Setting range RX Setting, RY Setting Points Set the assignment of RX/RY points. 0 to 128 (Default value: 32)  Start The RX/RY start number is displayed.  The RX/RY end number is displayed. RWr Setting, RWw Setting Points Set the assignment of RWr/RWw...
  • Page 51: Parameter Setting

    Parameter Setting The following methods are available for setting parameters of the A/D converter module. • Device station parameter automatic setting (Page 52 Device station parameter automatic setting) • Parameter processing of a device station (Page 58 Parameter processing of a device station) When parameters are set by the device station parameter automatic setting, even if the A/D converter module is replaced due to its failure, the parameters for the A/D converter module are automatically set via the master station.
  • Page 52 Item Setting details Setting range Reference Page 66 A/D Conversion Averaging process setting CH Averaging process Specify "Sampling • Sampling processing setting processing" or "Averaging (Default value) Method processing". • Time average • Count average • Moving average ■Time average CH...
  • Page 53 Item Setting details Setting range Reference Page 75 Scaling Scaling function CH Scaling enable/disable Set whether to enable or • Enable setting disable the scaling. • Disable (Default value) Function CH Scaling upper limit Set the upper limit value of -32000 to 32000 value scale conversion.
  • Page 54: Device Station Parameter Automatic Setting

    Device station parameter automatic setting The device station parameter automatic setting writes the A/D converter module parameters to the CPU module. The A/D converter module parameters are saved in the CPU built-in memory or the SD memory card. The parameters are automatically set in the A/D converter module via the master station when the A/D converter module joins or returns to the network.
  • Page 55 Double-click the item to be set, and enter the setting value. To save the parameter setting values in a CSV file, click the [Export] button. To read the parameter setting values from a CSV file, click the [Import] button. Click the [Close with Reflecting the Setting] button to close the "Parameter of Device Station" window. Select [Close with Reflecting the Setting] and close the "CC-Link IE TSN Configuration"...
  • Page 56 Click the [Detail] button for "Device Station Setting" to display the "CC-Link IE TSN Configuration - Device Station Setting" window. Check that the checkbox for the write target A/D converter module is selected. Select the checkbox if not selected. In the "CC-Link IE TSN Configuration - Device Station Setting" window, only the device stations whose "Parameter Automatic Setting"...
  • Page 57 When changing the parameters Operating procedure Display the "Online Data Operation" window. [Online]  [Read from PLC] Select the read source "Device Station Setting" checkbox. Click the [Detail] button for "Device Station Setting" to display the "CC-Link IE TSN Configuration - Device Station Setting"...
  • Page 58 Double-click "Detail Setting" beside the "Parameter Automatic Setting" checkbox to display the "Parameter of Device Station" window. Check that "Method selection" is set to "Parameter auto-setting". Select the items to be changed, and set new values. Click the [Close with Reflecting the Setting] button to close the "Parameter of Device Station" window. Select [Close with Reflecting the Setting] and close the "CC-Link IE TSN Configuration"...
  • Page 59 Check that the checkbox for the write target A/D converter module is selected. Select the checkbox if not selected. Click the [OK] button to close the "CC-Link IE TSN Configuration - Device Station Setting" window. Write the set parameters to the CPU module of the master station and reset the CPU module of the master station, or turn off and on the power supply of the programmable controller.
  • Page 60: Parameter Processing Of A Device Station

    Parameter processing of a device station The device station parameter processing writes the A/D converter module parameters to the A/D converter module. Parameter setting Operating procedure Display the "CC-Link IE TSN Configuration" window. [Navigation window]  [Parameter]  [Module Information]  Model  [Basic Settings]  [Network Configuration Settings] Open the "Parameter of Device Station"...
  • Page 61 Double-click the item to be set, and enter the setting value. To save the parameter setting values in a CSV file, click the [Export] button. To read the parameter setting values from a CSV file, click the [Import] button. Click the [Execute Parameter Processing] button. Follow the on-screen instructions and click the [Yes] button.
  • Page 62 When changing the parameters Operating procedure Display the "CC-Link IE TSN Configuration" window. [Navigation window]  [Parameter]  [Module Information]  Model  [Basic Settings]  [Network Configuration Settings] Open the "Parameter of Device Station" window. Select an A/D converter module from the station list, right-click, and select [Parameter of Device Station]. Set "Method selection"...
  • Page 63 Select the items to be changed, and set new values. • Click [Copy "Read Value" to "Write Value/Setting Value"] button and paste the value. • Select the items to be changed, and set new values. Click the [Execute Parameter Processing] button. Follow the on-screen instructions and click the [Yes] button.
  • Page 64: Precautions

    Precautions When using the master station in multicast mode ■When the firmware version is "03" or later Cyclic frames of multicast are not relayed via an Ethernet device (or a remote station of CC-Link IE TSN Class A) connected to an A/D converter module. ■When the firmware version is "02"...
  • Page 65: Chapter 7 Functions

    FUNCTIONS This chapter describes the details of the functions available in the A/D converter module, and the setting procedures for those functions. For details on remote I/O signals, remote register, and remote buffer memory, refer to the following: Page 158 Remote I/O Signal Page 167 Remote Register Page 171 Remote Buffer Memory Setting method...
  • Page 66: Each Function In The Sequence

    Each Function in the Sequence An analog input value and digital operation value are processed by the functions in the order shown below. If multiple functions are enabled, the output of the first-processed function is used as the input of the next function. Input signal error detection function (...
  • Page 67: A/D Conversion Enable/Disable Function

    A/D Conversion Enable/Disable Function This function allows A/D conversion to be enabled or disabled for each channel. Disabling the A/D conversion for unused channels reduces the conversion cycles. Setting method Operating procedure Use "CH A/D conversion enable/disable setting" in "A/D conversion enable/disable setting". 7 FUNCTIONS 7.3 A/D Conversion Enable/Disable Function...
  • Page 68: A/D Conversion Method

    A/D Conversion Method Set whether to perform sampling processing or averaging processing for each channel. Sampling processing For the A/D converter module, analog input values are stored in CH Digital operation value (RWr2 to RWr5) in each sampling cycle. The sampling cycle of the A/D converter module varies depending on the number of channels used (number of channels where A/D conversion is enabled).
  • Page 69: Moving Average

    Count average A/D conversion is executed for a specified number of times, and the total value excluding the maximum and minimum values is averaged and stored in CH Digital operation value (RWr2 to RWr5). The time taken for the mean value calculated through the count average processing to be stored in CH Digital operation value (RWr2 to RWr5) changes depending on the sampling cycle.
  • Page 70 Setting method Operating procedure Sampling processing Set "CH A/D conversion enable/disable setting" to "Enable". Set "CH Averaging process setting" to "Sampling processing". Averaging processing Set "CH A/D conversion enable/disable setting" to "Enable". Specify the type of averaging processing for "CH Averaging process setting". Set the value of averaging processing in "CH...
  • Page 71: Range Switching Function

    Range Switching Function Set the input range for each channel. An input range can be selected from the following. • Voltage: 1 to 5V, 0 to 5V, -10 to 10V, 0 to 10V • Current: 4 to 20mA, 0 to 20mA Setting method Operating procedure Set "CH...
  • Page 72: Input Signal Error Detection Function

    Input Signal Error Detection Function This function simply detects a disconnection of an analog input signal. The following figure schematically shows how the input signal error detection works in the A/D converter module. Detection range Out of detection range Included The input value is Analog input value normal.
  • Page 73 Detection condition When the following condition is satisfied, a disconnection is simply detected. Input range Simple disconnection detection condition Analog input value  2mA 4 to 20mA Analog input value  0.5V 1 to 5V *1 If the analog input range is other than the above range, CH Simple disconnection detection setting error (error code: 342H) is stored in Latest error code (RWr0), Error flag (RXA) turns on, and the ERR.
  • Page 74 Setting method Operating procedure Set "CH A/D conversion enable/disable setting" to "Enable". Set "CH Input signal error detection setting" to "Simple disconnection detection". 7 FUNCTIONS 7.7 Input Signal Error Detection Function...
  • Page 75: Warning Output Function (Process Alarm)

    Warning Output Function (Process Alarm) A warning is output if the digital operation value enters the predefined warning output range. The following figure schematically shows how the warning output behaves in the A/D converter module. Warning output range Out of warning output range Digital operation value A warning Included...
  • Page 76 Notification The module enters the following state and a warning is output when the digital operation value is equal to or more than the process alarm upper upper limit value, or equal to or less than the process alarm lower lower limit value (entering the warning output range).
  • Page 77: Scaling Function

    Scaling Function Scaling function allows scale conversion on a digital output value within the range of the scaling upper limit value and the scaling lower limit value, both of which are set at desired values. This function saves many steps to create a scale conversion program.
  • Page 78 Example of the scaling setting When the following setting is used for the channel 1 with the set input range of 0 to 5V: • "CH1 Scaling enable/disable setting": "Enable" • "CH1 Scaling upper limit value": 12000 • "CH1 Scaling lower limit value": 4000 digit (1) 12000 16000...
  • Page 79: Shift Function

    7.10 Shift Function This function adds (shifts) the set conversion value shift amount to a digital output value. Changes to the conversion value shift amount are applied to the digital operation value in real time, allowing fine adjustment to be easily performed when the system starts.
  • Page 80: Setting Example

    Setting example For channel 1 to which the input range 0 to 5V is set, when a conversion value shift amount of 10 is added to an A/D converter module with the following I/O characteristics 16000 15990 V: Analog input voltage (V) (1) CH1 Digital output value (2) CH1 Digital operation value (RWr2) Analog input voltage...
  • Page 81 Example of combined use of scaling function and shift function When the following setting is used for the channel 1 with the set input range of 0 to 5V: • "CH1 Scaling enable/disable setting": "Enable" • "CH1 Scaling upper limit value": 12000 •...
  • Page 82: Cc-Link Ie Tsn Network Synchronous Communication Function

    7.11 CC-Link IE TSN Network Synchronous Communication Function This function performs A/D conversion with a synchronization cycle of the master station that supports the CC-Link IE TSN Network synchronous communication function. This enables an A/D converter module to operate at the same timing as other remote stations on the same network. Applicable version When using the CC-Link IE TSN Network synchronous communication function, check the versions of A/D converter modules and master stations that support this function.
  • Page 83: Setting Method

    Setting method Calculate synchronization cycles from the formula below. Synchronization cycle = Basic period (Communication period interval setting)  Magnification Item Description Basic period (Communication period interval setting) Setting values of the communication period interval setting of master station parameters Magnification Magnification that is determined by the following master station parameters •...
  • Page 84: Operating Procedure

    Operating procedure Display the "CC-Link IE TSN Configuration" window. [Navigation window]  [Parameter]  [Module Information]  Model  [Basic Settings]  [Network Configuration Settings] Set "Network Synchronous Communication" to "Synchronous". • To use the CC-Link IE TSN Network synchronous communication function for the A/D converter module, enable the CC-Link IE TSN Network synchronous communication function of the master station.
  • Page 85: Timing Chart

    Restrictions This section describes restrictions to use the CC-Link IE TSN Network synchronous communication function. Restrictions to use this function with other functions Function name Restrictions A/D conversion method This method operates only when sampling processing is specified. Specifying time average, count average, or moving average would result in an error.
  • Page 86: Cc-Link Ie Tsn Class Setting Function

    7.12 CC-Link IE TSN Class Setting Function Set the CC-Link IE TSN Class (CC-Link IE TSN Class B or CC-Link IE TSN Class A) of the A/D converter module and save it in the non-volatile memory. The settings of the CC-Link IE TSN Class are stored in the non-volatile memory inside the A/D converter module, and CC- Link IE TSN Class B is set by factory default.
  • Page 87 Applicable version • The A/D converter modules with firmware version "06" or later support this function. • A/D converter modules with the firmware version that does not support this function operate with CC-Link IE TSN Class B. Page 216 Added and Changed Functions •...
  • Page 88 Display the "Function setting of remote station batch/individual execution function" window. [Tool]  [Function setting of Remote station batch/individual execution function...] The A/D converter modules are detected. Set "Process to be executed" to "CC-Link IE TSN Class read". 7 FUNCTIONS 7.12 CC-Link IE TSN Class Setting Function...
  • Page 89 Select the checkboxes for the A/D converter modules on which CC-Link IE TSN Class read is to be executed. When the [Execute] button is clicked, the following window appears. Click the [OK] button. 7 FUNCTIONS 7.12 CC-Link IE TSN Class Setting Function...
  • Page 90 Check that "Result" is "Normal completion". The "Read value" is displayed in the CC-Link IE TSN Class. In CC-Link IE TSN Class read, the CC-Link IE TSN Class in which the A/D converter module is currently operating is read. Set "Processed to be executed" to "CC-Link IE TSN Class write". 7 FUNCTIONS 7.12 CC-Link IE TSN Class Setting Function...
  • Page 91 Select the checkboxes for the A/D converter modules on which CC-Link IE TSN Class write is to be executed, and set "Write value" to CC-Link IE TSN Class. The "Write value" that the A/D converter module can be set to using CC-Link IE TSN Class write are as follows.
  • Page 92 Check that "Result" is "Normal completion". Turn off the A/D converter module power supply with CC-Link IE TSN Class set. • After executing "CC-Link IE TSN Class write", turn the module power supply off and on to operate with the set CC-Link IE TSN Class.
  • Page 93 The A/D converter modules are detected. Set "Process to be executed" to "CC-Link IE TSN Class read". 7 FUNCTIONS 7.12 CC-Link IE TSN Class Setting Function...
  • Page 94 Select the checkboxes for the A/D converter modules on which CC-Link IE TSN Class read is to be executed. When the [Execute] button is clicked, the following window appears. Click the [OK] button. 7 FUNCTIONS 7.12 CC-Link IE TSN Class Setting Function...
  • Page 95 Check that "Result" is "Normal completion". The "Read value" is displayed in the CC-Link IE TSN Class. In CC-Link IE TSN Class read, the CC-Link IE TSN Class in which the A/D converter module is currently operating is read. Set "Processed to be executed" to "CC-Link IE TSN Class write". 7 FUNCTIONS 7.12 CC-Link IE TSN Class Setting Function...
  • Page 96 Select the checkboxes for the A/D converter modules on which CC-Link IE TSN Class write is to be executed, and set "Write value" to CC-Link IE TSN Class. When the [Execute] button is clicked, the following window appears. Click the [OK] button. 7 FUNCTIONS 7.12 CC-Link IE TSN Class Setting Function...
  • Page 97 Check that "Result" is "Normal completion". Power off and on the A/D converter module power supply with CC-Link IE TSN Class set. CC-Link IE TSN Class setting in the network configuration settings Set the "CC-Link IE TSN Class" of the A/D converter module in the CC-Link IE TSN Configuration window of the network configuration settings.
  • Page 98 Monitoring setting status Method for monitoring using remote I/O signals The setting status of the CC-Link IE TSN Class can be checked by using the CC-Link IE TSN Class setting status (RXE). CC-Link IE TSN Class setting status (RXE) CC-Link IE TSN Class setting status CC-Link IE TSN Class A CC-Link IE TSN Class B Method for monitoring according to selected station communication status monitor...
  • Page 99: Communication Speed Setting Function

    7.13 Communication Speed Setting Function This function sets the communication speed of A/D converter module (1Gbps or 100Mbps), and saves the setting in the non- volatile memory. The communication speed 1Gbps is set to the non-volatile memory by factory default. System configuration Connect the personal computer with CC-Link IE TSN Configurator installed to the A/D converter modules targeted for the communication speed setting.
  • Page 100: Setting Method

    Setting method The procedure of communication speed setting slightly varies depending on its timing. • Set at the module start-up • Set while the module is operating Set at the module start-up The following describes the procedure to set a communication speed at the module start-up. Connect A/D converter modules to the external power supply if needed.
  • Page 101 Set "Process to be executed" to "Communication speed read". Select checkboxes of the A/D converter modules on which the communication speed read is to be executed. When the [Execute] button is clicked, the following window appears. Click the [OK] button. 7 FUNCTIONS 7.13 Communication Speed Setting Function...
  • Page 102 Check that "Result" is "Normal completion". The communication speed is displayed in "Read value". A value to be read out by the communication speed read is an actual communication speed with which the A/ D converter module is operating. Set "Process to be executed" to "Communication speed write". 7 FUNCTIONS 7.13 Communication Speed Setting Function...
  • Page 103 Select checkboxes of the A/D converter modules on which the communication speed write is to be executed, and set the communication speed to "Write value". The "Write value" that the A/D converter module can be set to using communication speed write are as follows.
  • Page 104 Check that "Result" is "Normal completion". Turn off the module power supply of the A/D converter modules on which the communication speed setting has been executed. To operate the A/D converter modules with a newly set communication speed, turn off and on the module power supply after the execution of communication speed write.
  • Page 105 Set while the module is operating The following describes the procedure to set a communication speed while the module is operating. Connect the personal computer with CC-Link IE TSN Configurator installed to the A/D converter modules targeted for the communication speed setting, by using Ethernet cables. Display the "Function setting of remote station batch/individual execution function"...
  • Page 106 Select checkboxes of the A/D converter modules on which the communication speed read is to be executed. When the [Execute] button is clicked, the following window appears. Click the [OK] button. 7 FUNCTIONS 7.13 Communication Speed Setting Function...
  • Page 107 Check that "Result" is "Normal completion". The communication speed is displayed in "Read value". A value to be read out by the communication speed read is an actual communication speed with which the A/ D converter module is operating. Set "Process to be executed" to "Communication speed write". 7 FUNCTIONS 7.13 Communication Speed Setting Function...
  • Page 108 Select checkboxes of the A/D converter modules on which the communication speed write is to be executed, and set the communication speed to "Write value". When the [Execute] button is clicked, the following window appears. Click the [OK] button. 7 FUNCTIONS 7.13 Communication Speed Setting Function...
  • Page 109 Check that "Result" is "Normal completion". Turn off and on the module power supply of the A/D converter modules on which the communication speed setting has been executed. Monitoring a set value Which value is set as the communication speed can be checked by using Communication speed setting status (RXD). Communication speed setting status (RXD) Set value of communication speed 100Mbps...
  • Page 110 Precautions • The following table lists error codes that are displayed in "Error code" of CC-Link IE TSN Configurator if the communication speed write has been completed with an error. When the other error codes are displayed, refer to the manual of CC-Link IE TSN Configurator to take actions.
  • Page 111: Slmp Communication Function

    7.14 SLMP Communication Function SLMP can be used to communicate with the A/D converter module. For details on SLMP, refer to the following. SLMP Reference Manual Applicable version The A/D converter modules with firmware version "06" or later support this function. Page 216 Added functions Applicable commands SLMP command...
  • Page 112 SLMP communications end code If the A/D converter module returns an abnormal response, the following code or error code is stored in the end code. End code Description and cause Action C059H Incorrect command/sub-command specification. Review the command/subcommand and resend it. C05CH Incorrect request specification.
  • Page 113: Firmware Update Function

    (1) A/D converter modules targeted for firmware update Firmware update file When the firmware update file is necessary, please consult your local Mitsubishi representative. The file name of firmware update file is listed below. Model name File name NZ2GN2B-60AD4, NZ2GN2S-60AD4 CCIET_AD.SYF 7 FUNCTIONS 7.15 Firmware Update Function...
  • Page 114: Setting Method

    Setting method Setting the CC-Link IE TSN Firmware Update Tool is required to update firmware for A/D converter modules. For details, refer to the "Help" of the CC-Link IE TSN Firmware Update Tool. "Network Configuration Settings" window Set the following items in the "Network Configuration Settings" window. Item Description Module Name...
  • Page 115 "Application Settings" window Set the following items in the "Application Settings" window. Classification Item Setting range Description PC Settings IP Address 0.0.0.1 to Set the IP address of the personal computer. 223.255.255.254 Port Number 0, 49152 to 65535 Set 0. FTP Settings FTP Mode "Active Mode"...
  • Page 116 Error Error name Description and cause Action information 0003H Module error An error has occurred on the module during Turn off and on the module power supply, and firmware update. restart the CC-Link IE TSN Firmware Update Tool. If this error persists, the failure of the module is a possible cause.
  • Page 117: Module Power Supply Voltage Drop Detection Function

    7.16 Module Power Supply Voltage Drop Detection Function This function detects a voltage drop of the module power supply. This function makes troubleshooting easy when the voltage of the power supplied to the A/D converter module drops, or when poor connection in the wiring occurs. Note that the voltage to be monitored for a module power supply voltage drop is 20.4V. Operation If a drop in the voltage of the module power supply is detected, the module enters the following state and an error is notified.
  • Page 118: Snmp Agent Function

    7.17 SNMP Agent Function This function allows the A/D converter module to operate as an SNMP agent. SNMP is a protocol for monitoring and controlling network devices on a network. Setting method The SNMP community name can be set with the SNMP community name setting function of the master station. If the SNMP community name is not set, the A/D converter module operates with the SNMP community name as "public".
  • Page 119 Supported SNMP version and MIB The following shows the SNMP versions and MIBs supported by the A/D converter module. • SNMP version: v2c • Supported MIB: MIB-II (RFC1213) Standard MIB The following table lists the standard MIB. : Available, : Not available Item Supported ...
  • Page 120: Chapter 8 Programming

    PROGRAMMING This chapter describes the programming of the A/D converter module. Precautions for Programming This section describes the precautions for creating CC-Link IE TSN programs. Program for cyclic transmission For a program for cyclic transmission, provide interlock between the following link special relay (SB) and the link special register (SW).
  • Page 121: When The Function Setting Switch 2 Is Not Used

    • Master/local module: RJ71GN11-T2 (Start I/O number: 0000H to 001FH) • Input module: RX40C7 (Start I/O number: 0020H to 002FH) (2) Remote station (IP address/station number setting switches: 1) • A/D converter module: NZ2GN2S-60AD4 (Analog input: CH1, CH2, CH3) ■Assignment of link devices X1000 ·...
  • Page 122 Digital operation value read command RX40C7 (X20 to X2F) Error reset command Maximum value/minimum value read command Maximum value/minimum value reset command X1009 Initial data setting completion flag NZ2GN2S-60AD4 (RX0 to RX1F) X100A Error flag X100B Remote READY X1010 CH1 A/D conversion completed flag...
  • Page 123 Device Description D2002 CH1 Digital operation value Device for storage D2003 CH2 Digital operation value D2004 CH3 Digital operation value D2010 CH1 Maximum value D2011 CH1 Minimum value D2012 CH2 Maximum value D2013 CH2 Minimum value D2014 CH3 Maximum value D2015 CH3 Minimum value D2030...
  • Page 124 Setting method Operating procedure Create a project. [Project]  [New] For "CPU Parameter" in "Link Direct Device Setting", set "Extended Mode (iQ-R Series Mode)". [CPU Parameter]  [Memory/Device Setting]  [Link Direct Device Setting]  [Link Direct Device Setting] When writing the module parameters of the RJ71GN11-T2 to the CPU module with the engineering tool, set "Extended Mode (iQ-R Series Mode)"...
  • Page 125 Display the "CC-Link IE TSN Configuration" window and set parameters as follows. [Navigation window]  [Parameter]  [Module Information]  Model  [Basic Settings]  [Network Configuration Settings] If the A/D converter module firmware version is "06" or later, set "CC-Link IE TSN Class" on the "CC-Link IE TSN Configuration"...
  • Page 126 Click the [Close with Reflecting the Setting] button to close the "Parameter of Device Station" window. Select [Close with Reflecting the Setting] and close the "CC-Link IE TSN Configuration" window. Display the refresh parameter setting window and set as follows. [Navigation window] ...
  • Page 127: Program Example

    Program example 8 PROGRAMMING 8.2 When the Function Setting Switch 2 Is Not Used...
  • Page 128 (17)Read the digital operation value. (46)Detect Input signal error detection flag and Warning output flag. (75)Read the latest alarm code. (92), (107)Processing at warning occurrence (110), (135)Processing at input signal error occurrence (disconnection detection) (138), (155), (172)Read the maximum and minimum values. (181), (199)Reset the maximum and minimum values.
  • Page 129: When The Function Setting Switch 2 Is Used

    • Input module: RX40C7 (Start I/O number: 0020H to 002FH) (2) Remote station (IP address/station number setting switches: 1) • A/D converter module: NZ2GN2S-60AD4 (Analog input: CH1, CH2, CH3, CH4) Programming conditions Digital operation values obtained from A/D conversion on CH1, CH2, CH3, and CH4 of the A/D converter module are read.
  • Page 130 Device Description X1009 Initial data setting completion flag NZ2GN2S-60AD4 (RX0 to RX1F) X100A Error flag X100B Remote READY X1010 CH1 A/D conversion completed flag X1011 CH2 A/D conversion completed flag X1012 CH3 A/D conversion completed flag X1013 CH4 A/D conversion completed flag...
  • Page 131 Setting method Operating procedure Create a project. [Project]  [New] For "CPU Parameter" in "Link Direct Device Setting", set "Extended Mode (iQ-R Series Mode)". [CPU Parameter]  [Memory/Device Setting]  [Link Direct Device Setting]  [Link Direct Device Setting] When writing the module parameters of the RJ71GN11-T2 to the CPU module with the engineering tool, set "Extended Mode (iQ-R Series Mode)"...
  • Page 132 Display the "CC-Link IE TSN Configuration" window and set parameters as follows. [Navigation window]  [Parameter]  [Module Information]  Model  [Basic Settings]  [Network Configuration Settings] If the A/D converter module firmware version is "06" or later, set "CC-Link IE TSN Class" on the "CC-Link IE TSN Configuration"...
  • Page 133 Program example 8 PROGRAMMING 8.3 When the Function Setting Switch 2 Is Used...
  • Page 134 (17)Read the digital operation value. (50), (67), (84)Read the maximum and minimum values. (93), (111)Reset the maximum and minimum values. (114)Read the latest error code. (129), (142)Clear the latest error code. 8 PROGRAMMING 8.3 When the Function Setting Switch 2 Is Used...
  • Page 135: Chapter 9 Maintenance And Inspection

    MAINTENANCE AND INSPECTION The A/D converter module has no special item to be inspected. However, to maintain the best condition of the system, perform the inspection in accordance with the items described in the MELSEC iQ-R Module Configuration Manual. 9 MAINTENANCE AND INSPECTION...
  • Page 136 MEMO 9 MAINTENANCE AND INSPECTION...
  • Page 137: Chapter 10 Troubleshooting

    TROUBLESHOOTING This chapter describes errors that may occur while the A/D converter module is used, and their troubleshooting. 10.1 CC-Link IE TSN/CC-Link IE Field Diagnostics For CC-Link IE TSN, monitor the status and conduct an operation test. For details on CC-Link IE TSN/CC-Link IE Field diagnostics, refer to the following. ...
  • Page 138 Communication speed setting function • If the communication speed different from that of the currently-operating module has been set and remote reset is performed after that, a remote reset disable error (communication speed setting) (error code: 1091H) occurs, and the A/D converter module is not reset.
  • Page 139: Checking The Leds

    10.2 Checking the LEDs This section describes how to troubleshoot the system by the LEDs. When the PW LED does not turn on When the PW LED does not turn on, check the following items. Check item Action Is any LED other than the PW LED turned on? When any LED other than the PW LED turns on, the possible cause is a hardware failure.
  • Page 140: When The Alm Led Flashes

    When the ALM LED flashes When the ALM LED flashes, check the following item. Check item Action Has any input signal error occurred in the A/D converter module? Check Input signal error detection flag (RWrA). When the P1 LINK LED or P2 LINK LED turns off When the P1 LINK LED or P2 LINK LED turns off, check the following items.
  • Page 141 Check item Action Is another module that is powered off or in the middle of remote reset • Power on the A/D converter module(s) that is off because an A/D converter connected between the master station and the A/D converter module? module becomes disconnected when it is off.
  • Page 142 When the DATA LINK LED flashes When the DATA LINK LED flashes, check the following items. Check item Action Do the IP addresses match? Match the IP address of the A/D converter module with the IP address that is set in the network configuration settings of the master station.
  • Page 143 Check item Action Is the device station parameter automatic setting completed with an error Check Device station parameter automatic setting execution result details when the device station parameter automatic setting is enabled? (SW0194) and the event history of the master/local module, and take the corrective actions corresponding to the stored error code.
  • Page 144: Unit Test

    10.3 Unit Test The purpose of a unit test is to check if there is any abnormality in the A/D converter module hardware. Power off the power supply of the A/D converter module. Connect P1 and P2 of the A/D converter module with an Ethernet cable. Set the IP address/station number setting switches and function setting switches as follows.
  • Page 145: Troubleshooting By Symptom

    10.4 Troubleshooting by Symptom Troubleshooting by symptom is suitable for the case where modules fail to operate normally even though no error has occurred in the A/D converter module. If an error occurs in the A/D converter module, identify the cause of the error using the engineering tool.
  • Page 146 When the digital operation value is out of the accuracy range When the digital operation value is out of the accuracy range, check the following item. Check item Action Is any measure against noise taken? Take measures to reduce noise, such as using a shielded cable for connection.
  • Page 147: How To Check Error Codes And Alarm Codes

    10.5 How to Check Error Codes and Alarm Codes Error and alarm codes can be checked with the following methods. • Checking by using CC-Link IE TSN/CC-Link IE Field diagnostics • Checking by Latest error code (RWr0) • Checking by Latest alarm code (RWr1) •...
  • Page 148 To initialize the error history, click the [Delete Error/Event History] button. Checking by Latest error code (RWr0) Check the latest error code with the remote register of the master/local module. Operating procedure [Online]  [Monitor]  [Device/Buffer Memory Batch Monitor] When the refresh target device for Latest error code (RWr0) is W1100 How to clear an error How to clear an error depends on the error type.
  • Page 149 Set "Method selection" to "Error clear request", and click the [Execute] button. When the following window appears, click the [Yes] button. When the following window appears, click the [OK] button. An error on the A/D converter module is cleared. 10 TROUBLESHOOTING 10.5 How to Check Error Codes and Alarm Codes...
  • Page 150 Checking by Latest alarm code (RWr1) Check the latest alarm code with the remote register of the master/local module. Operating procedure [Online]  [Monitor]  [Device/Buffer Memory Batch Monitor] When the refresh target device for Latest alarm code (RWr1) is W1101 10 TROUBLESHOOTING 10.5 How to Check Error Codes and Alarm Codes...
  • Page 151: Error Code List

    10.6 Error Code List The error codes are classified into the following three types. Classification Description Major error This error is a sign that recovery is impossible, with the RUN LED turning off. Moderate error This error is a sign that the module cannot continue to operate, with the ERR. LED turning on.
  • Page 152 Error code Classification Error name Description and cause Action (hexadecimal) 1053H Minor error Communication speed save limit The upper limit for the number of times Communication speed changes made error a communication speed setting is in and after this error will not be saved saved is reached.
  • Page 153 Error code Classification Error name Description and cause Action (hexadecimal) 1072H Minor error IP address change not reflected IP address setting was executed via • Although the analog module saved the engineering tool after the the set IP address in the non-volatile communications with the master memory, the change in the IP station started.
  • Page 154 Error code Classification Error name Description and cause Action (hexadecimal) 2011H Moderate error Non-volatile memory data error The IP address and subnet mask • The module will be automatically (IP address) stored in the non-volatile memory are recovered immediately after the abnormal.
  • Page 155 Error code Classification Error name Description and cause Action (hexadecimal) 2220H Moderate error Synchronous communication When CC-Link IE TSN Network • Change the synchronization cycle of error 2 synchronous communication function the master station to a longer cycle. is used, synchronous communication •...
  • Page 156 Error code Classification Error name Description and cause Action (hexadecimal) 350H Moderate error CH Scaling setting out-of-range CH Scaling lower limit value Set CH Scaling lower limit value (address: 01H) and CH Scaling (address: 01H) and CH Scaling upper limit value (address: 01H) are upper limit value (address: 01H) to set to values out of the range of - values in the range of -32000 to...
  • Page 157 Communication system error codes Error code Classification Error name Description and cause Action (hexadecimal) *1*2 D000H Minor error Communication setting error 1 Invalid network settings are received. • Turn off and on the module power supply. • If this error persists, the failure of the module is a possible cause.
  • Page 158 Error code Classification Error name Description and cause Action (hexadecimal) *1*2 D026H Minor error Synchronization cycle setting The synchronization cycle set in the Adjust the synchronization cycle of the error master station is not supported by the master station and then turn off and on module.
  • Page 159: List Of Alarm Codes

    10.7 List of Alarm Codes Here is the list of alarm codes:  indicates the number of the channel where an alarm has occurred. Alarm code Classification Alarm name Description and cause Action (hexadecimal) 0C0H Minor error CH Process alarm (upper limit) A process alarm (upper limit) has When the digital operation value occurrence...
  • Page 160: Appendices

    APPENDICES Appendix 1 Remote I/O Signal List of remote I/O signals This section lists I/O signals for a master/local module. The I/O signals assignment shown assumes that the remote I/O signals of the A/D converter module are assigned to RX0 to RX2F and RY0 to RY2F.
  • Page 161: Details Of Remote Input Signals

    Details of remote input signals Initial data setting completion flag ■Device number Name Device number Initial data setting completion flag ■Description This flag turns on when the following is performed and the operation conditions are changed. Write the parameters to the remote buffer memory area using the REMTO instruction. Turn on Initial data setting request flag (RY9).
  • Page 162 Error flag ■Device number Name Device number Error flag ■Description Error flag (RXA) turns on when an error occurs. To clear Latest error code (RWr0), turn on and off Error clear request flag (RYA). • When a minor error occurs Latest error code (RWr0) 0000H (Error code)
  • Page 163 • When a major error occurs Latest error code (RWr0) 0000H (Error code) Error flag (RXA) Error clear request flag (RYA) Remote READY (RXB) Executed by the A/D converter module. Executed by the program. (1) An error occurs. (2) When a major error occurs, it is not cleared even by executing an error clear request. Remote READY ■Device number Name...
  • Page 164 Input range switch enable/disable setting status flag ■Device number Name Device number Input range switch enable/disable setting status flag ■Description This flag can be used to check the input range switch enable/disable setting status. • Enable: ON • Disable: OFF The input range switch enable/disable setting status is set with the function setting switch.
  • Page 165: A/D Conversion Completed Flag

    A/D conversion completed flag ■Device number Name Device number A/D conversion completed flag RX10 RX11 RX12 RX13 ■Description • This flag turns on when A/D conversion of the channel whose A/D conversion enable/disable setting (address: 0102H) is set to A/D conversion enabled. •...
  • Page 166 Input signal error detection signal ■Device number Name Device number Input signal error detection signal RX1C ■Description When Input signal error detection setting (address: 010FH) is set to Simple disconnection detection (4H), this signal turns on when disconnection is detected for any channel whose A/D conversion enable/disable setting (address: 0102H) is set to A/D conversion enabled.
  • Page 167: Maximum Value/Minimum Value Reset Completed Flag

    Maximum value/minimum value reset completed flag ■Device number Name Device number Maximum value/minimum value reset completed flag RX1D ■Description This flag turns on when Maximum value/minimum value reset request (RY1D) is turned on and off, and the values stored in CH...
  • Page 168: Details Of Remote Output Signals

    Details of remote output signals Initial data setting request flag ■Device number Name Device number Initial data setting request flag ■Description Turn on this flag after writing parameters to the remote buffer memory with a program. Upon completion of the change of operating conditions, Initial data setting completion flag (RX9) turns on. For the timing of turning the flag on and off, refer to the following.
  • Page 169: Appendix 2 Remote Register

    Appendix 2 Remote Register List of remote register areas This section lists remote register areas for a master/local module. The remote register area assignment shown assumes that the remote register areas of the A/D converter module are assigned to RWr0 to RWr1F and RWw0 to RWw1F. Remote register (RWr) is the information input from the A/D converter module to the master/local module.
  • Page 170: Details Of Remote Register Areas

    Details of remote register areas Latest error code ■Device number Name Device number Latest error code RWr0 ■Description The error code is stored when an error occurs. Turning on Error clear request flag (RYA) after eliminating the cause of the error clears the error code. The errors that have occurred in the past can be checked from the engineering tool.
  • Page 171 Input signal error detection flag ■Device number Name Device number Input signal error detection flag RWrA ■Description The input signal status of each channel can be checked. Fixed to "0". OFF: Normal, ON: Disconnection detection ■The state of Input signal error detection flag (RWrA) •...
  • Page 172 Shifting amount to conversion value ■Device number Name Device number CH Shifting amount to conversion value RWw2 RWw3 RWw4 RWw5 ■Description Set the conversion value shift amount used for the shift function as 16-bit signed binary data. The shifted and added digital operation value is stored in CH...
  • Page 173: Appendix 3 Remote Buffer Memory

    Appendix 3 Remote Buffer Memory This section describes the remote buffer memory. The remote buffer memory consists of addresses for the parameter area, monitor area, and module control data area. Data can be read or written from/to remote buffer memory areas by using SLMP commands or dedicated instructions. For SLMP commands, refer to the following.
  • Page 174: Parameter Area

    Parameter area Module-based parameter data : Applicable, : Not applicable Address Name Default Read Write value Decimal Hexadecimal 256, 257 0100H, 0101H Use prohibited      0102H A/D conversion enable/disable setting 0000H   0103H Range setting 0000H ...
  • Page 175: Error History Area

    Monitor area Module-based monitor data : Applicable, : Not applicable Address Name Default Read Write value Decimal Hexadecimal 1536 0600H CH1 Maximum value     1537 0601H CH1 Minimum value 1538 0602H CH2 Maximum value    ...
  • Page 176 Module control data area Station-based control data : Applicable, : Not applicable Address Name Default Read Write value Decimal Hexadecimal 4096 1000H Error history clear command     4097 1001H Error history clear completed   4098 1002H Parameter area initialization command ...
  • Page 177: Details Of Remote Buffer Memory

    Details of remote buffer memory This section describes the remote buffer memory areas of the A/D converter module. A/D conversion enable/disable setting Address Name Address A/D conversion enable/disable setting 0102H Description Enable or disable A/D conversion for each channel. Fixed to "0". 0: A/D conversion enabled (default value) 1: A/D conversion disabled If a value other than the above is set, the setting values of lower 4 bits are used for operation.
  • Page 178 Averaging process setting Address Name Address Averaging process setting 0105H Description Set sampling processing or averaging processing for each channel. There are the following types of averaging processing: time average, count average, and moving average. Setting value The following table lists the setting values. Processing method Setting value Sampling processing...
  • Page 179 Input signal error detection setting Address Name Address Input signal error detection setting 010FH Description Set the condition to detect input signal errors for each channel. Setting value The following table lists the setting values. Detection method for input signal error Setting value Disable 0H (Default value)
  • Page 180: Setting Range

    Process alarm Address Name Address CH Process alarm lower lower limit value 0112H 0116H 011AH 011EH CH Process alarm lower upper limit value 0113H 0117H 011BH 011FH CH Process alarm upper lower limit value 0114H 0118H 011CH 0120H CH Process alarm upper upper limit value 0115H 0119H 011DH...
  • Page 181 Scaling Address Name Address CH Scaling lower limit value 0134H 0136H 0138H 013AH CH Scaling upper limit value 0135H 0137H 0139H 013BH Description Set the lower limit value and upper limit value of the scale conversion range. For details on the scaling function, refer to the following: Page 75 Scaling Function Setting range -32000 to 32000 (Default value: 0)
  • Page 182 Setting range monitor Address Name Address Setting range monitor 0610H Description The set input range value can be checked. When A/D conversion enable/disable setting (address: 0102H) is set to A/D conversion disabled, the range is not changed and the value of Setting range monitor (address: 0610H) is not updated. Monitored value The following table lists the monitored values.
  • Page 183 Parameter automatic setting status monitor Address Name Address Parameter automatic setting status monitor 0612H Description The parameter automatic setting status can be checked. Monitored value The following table lists the monitored values. Parameter automatic setting status Monitored value Details Unexecuted 0H (Default value) Parameter automatic setting execution is not in progress.
  • Page 184 Error history data 1 to 16 Address Name Address Error history data 1 to 16 0A00H to 0AFFH Description Up to 16 errors that have occurred in the module are stored. The following table lists the description stored in Error history data 1 (address: 0A00H to 0A0FH). Address 0A00H Error code...
  • Page 185 Error history clear command Address Name Address Error history clear command 1000H Description The error history stored in the module is cleared. Fixed to "0". (1) Error history clear command • 0: Not commanded (default) • 1: Commanded Operation of error history clear When Error history clear command (address: 1000H) is set to Commanded (1), the error history is cleared.
  • Page 186 Parameter area initialization command Address Name Address Parameter area initialization command 1002H Description This command resets parameters stored in the remote buffer memory and non-volatile memory to the default values. The A/D converter module can be restored when a non-volatile memory data error (parameter) (error code: 2010H) occurs. Fixed to "0".
  • Page 187: Supported Version

    Appendix 4 IP Address Setting Function Using the Engineering Tool An IP address can be set for A/D converter module using the engineering tool. To set an IP address using the engineering tool, set the IP address/station number setting switches to 0. When an IP address is set while those switches are set to a value other than 0, IP address change disable error 1 (error code: 1070H) occurs and the IP address will not be set.
  • Page 188 Display the "IP Address Setting" window. [CC-Link IE TSN Configuration]  [Online]  [IP Address Setting] Click the [Real Machine Information Detection] button. The information on the actual device connected to the master station is obtained. When a duplicated IP address is used for the A/D converter module and master station, the A/D converter module with a duplicated IP address is not displayed on the list.
  • Page 189 When indicator display has successfully started, the RUN LED of the A/D converter module flashes. The execution results are displayed at the bottom of the window. Enter the IP address to set in "IP Address" and click the [Setting] button. Follow the displayed message and click the [Yes] button.
  • Page 190 Precautions • When a value out of the range for the IP address is set, an IP address setting error (error code: D011H) occurs and the IP address will not be set. (Page 27 Setting range) • When an IP address is set for the A/D converter module using the engineering tool, the IP address is saved in the non- volatile memory and is reflected to the operation.
  • Page 191: Appendix 5 I/O Conversion Characteristics Of A/D Conversion

    Appendix 5 I/O Conversion Characteristics of A/D Conversion I/O conversion characteristics of A/D conversion mean the slope connecting the offset value and gain value for converting an analog signal (voltage or current input) from outside of the A/D converter module to a digital value. Offset value The analog input value (voltage or current) corresponding to the digital output value 0 Gain value...
  • Page 192 • Use a value within the practical analog input range for each input range. If a value is out of the range, the maximum resolution and accuracy may not fall within the range of performance specifications. (Do not use the value in the dotted line region in the graph of voltage input characteristics.) •...
  • Page 193: Current Input Characteristics

    Current input characteristics The following graph shows the current input characteristics. digit 16383 16000 -384 -16000 -16384 digit: Digital output value mA: Analog input current (mA) (a) Analog input practical range Range setting Offset value Gain value Digital output value Maximum resolution 0 to 20mA 20mA...
  • Page 194: Appendix 6 Accuracy Of A/D Conversion

    Appendix 6 Accuracy of A/D Conversion Accuracy of A/D conversion is the accuracy of the maximum value of digital output value. An input characteristic change by changing the input range does not sacrifice the accuracy, which is maintained within the described range of the performance specifications.
  • Page 195: Appendix 7 Cc-Link Ie Tsn Processing Time

    Appendix 7 CC-Link IE TSN Processing Time The CC-Link IE TSN processing time is the time taken for the A/D converter module to retrieve an analog input value and store the data in the master station CPU module device. The CC-Link IE TSN processing time is determined by the following processing time. Data link processing time = SM + LS + Remote station processing time •...
  • Page 196: Appendix 8 Standard Mib

    Appendix 8 Standard MIB The following tables list the details on the standard MIB. System group (1.3.6.1.2.1.1.) R: Read, W: Write Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil System sysDescr 1.3.6.1.2.1. DisplayStri Description of the system String ...
  • Page 197 Interface group (1.3.6.1.2.1.2.) R: Read, W: Write Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   Interface ifNumber 1.3.6.1.2.1. INTEGER Number of interfaces -2147483648 to 2147483647 ifTable ifTable 1.3.6.1.2.1. SEQUENC Information table for each ...
  • Page 198 Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   ifEn ifInErrors 1.3.6.1.2.1. Counter Number of received 0 to 4294967295 2.2.1.14 packets that could not be delivered to the upper protocol due to an error ...
  • Page 199 AddressTranslation group (1.3.6.1.2.1.3.) R: Read, W: Write Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil      atTable atTable 1.3.6.1.2.1. SEQUENC Information table for each E OF address conversion IfEntry information atEntry atEntry...
  • Page 200 IP group (1.3.6.1.2.1.4.) R: Read, W: Write Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil • 1: forwarding  ipForwardin 1.3.6.1.2.1. INTEGER Whether to operate as an   IP forwarding gateway Operate •...
  • Page 201 Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   ipFragFails 1.3.6.1.2.1. Counter Number of IP datagrams 0 to 4294967295 Counter 4.18 discarded because they value could not be fragmented ipFragCreat 1.3.6.1.2.1. Counter Number of IP datagram 0 to 4294967295 ...
  • Page 202 Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   ipRouteIfIn 1.3.6.1.2.1. INTEGER Each ipRouteEntry ID -2147483648 to 4.21.1.2. 2147483647 Communica tion destination IP address   ipRouteMet 1.3.6.1.2.1. INTEGER 1st routing path for the -2147483648 to ric1 4.21.1.3.
  • Page 203 Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   ipRouteMa 1.3.6.1.2.1. IpAddress Subnet mask for the Subnet mask Subnet 4.21.1.11. destination IP address mask Communica tion destination IP address   ipRouteMet 1.3.6.1.2.1.
  • Page 204 ICMP group (1.3.6.1.2.1.5.) R: Read, W: Write Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil ICMP icmpInMsg 1.3.6.1.2.1. Counter Total number of ICMP 0 to 4294967295  Counter  messages received value  ...
  • Page 205 Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   ICMP icmpOutEc 1.3.6.1.2.1. Counter Number of ICMP echo 0 to 4294967295 Counter hoReps 5.22 response messages sent value icmpOutTi 1.3.6.1.2.1. Counter Number of ICMP 0 to 4294967295 ...
  • Page 206 UDP group (1.3.6.1.2.1.7.) R: Read, W: Write Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil udpInDatag 1.3.6.1.2.1. Counter Number of UDP 0 to 4294967295  Counter  rams datagrams delivered to value UDP users ...
  • Page 207 SNMP group (1.3.6.1.2.1.7.) R: Read, W: Write Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   SNMP snmpInPkts 1.3.6.1.2.1. Counter Total number of SNMP 0 to 4294967295 Counter messages received from value TP (transport service) snmpOutPk 1.3.6.1.2.1.
  • Page 208 Classific OID value Type Detailed explanation Description Setting Remarks ation (SubTree) port avai value labil   SNMP snmpOutTo 1.3.6.1.2.1. Counter Number of sent SNMP 0 to 4294967295 Counter oBigs 7.20 messages with error- value status 'tooBig'   snmpOutN 1.3.6.1.2.1.
  • Page 209: Reference Information

    Reference information List of interface types Interface name other regular1822 hdh1822 ddn-x25 rfc877-x25 ethernet-csmacd iso88023-csmacd iso88024-tokenBus iso88025-tokenRing iso88026-man starLan proteon-10Mbit proteon-80Mbit hyperchannel fddi lapb sdlc basicISDN primaryISDN propPointToPointSerial softwareLoopback ethernet-3Mbit nsip slip ultra frame-relay List of routing protocols Protocol name other local netmgmt...
  • Page 210: Appendix 9 Emc And Low Voltage Directives

    Appendix 9 EMC and Low Voltage Directives In each country, laws and regulations concerning electromagnetic compatibility (EMC) and electrical safety are enacted. For the products sold in the European countries, compliance with the EU's EMC Directive has been a legal obligation as EMC regulation since 1996, as well as the EU's Low Voltage Directive as electrical safety regulation since 1997.
  • Page 211: Installation In A Control Panel

    ■Immunity requirements Standard Test item Test details Standard value EN61131-2: 2017 EN61000-4-2 Static electricity is applied to the • 30M to 230MHz QP: 40dBV/m Electrostatic discharge immunity cabinet of the equipment. (measured over 10m) • 230M to 1000MHz QP: 47dBV/m (measured over 10m) EN61000-4-3 Electric fields are radiated to the...
  • Page 212: External Power Supply

    Use shielded cables for external wiring and ground the shields of the external wiring cables to the control panel with the AD75CK cable clamp (manufactured by Mitsubishi Electric Corporation). (Ground the shield section 20 to 30cm away from the module.)
  • Page 213 Others ■Ferrite core A ferrite core has the effect of reducing radiation noise in the 30MHz to 100MHz band. It is recommended to attach ferrite cores if shielded cables coming out of the control panel do not provide sufficient shielding effects.
  • Page 214: Requirements To Compliance With The Low Voltage Directive

    Requirements to compliance with the Low Voltage Directive The module operates at the rated voltage of 24VDC. The Low Voltage Directive is not applied to the modules that operate at the rated voltage of less than 50VAC and 75VDC. APPX Appendix 9 EMC and Low Voltage Directives...
  • Page 215: Appendix 10How To Check Production Information And Firmware Version

    Appendix 10 How to Check Production Information and Firmware Version Checking the production information The production information of A/D converter module can be checked with the following. • Rating plate • CC-Link IE TSN/CC-Link IE Field diagnostics Checking on the rating plate MODEL PW TERMINAL MAC ADD.
  • Page 216: Checking The Firmware Version

    Checking the firmware version Check the firmware version of an A/D converter module with the following. • "Station Information List" window of CC-Link IE TSN/CC-Link IE Field Diagnostics • CC-Link IE TSN Firmware Update Tool For a module on which a firmware update has not been performed yet, the firmware version can be checked with the production information.
  • Page 217: Appendix 11 Software Licenses And Copyright

    Appendix 11 Software Licenses and Copyright This section describes the licenses and copyrights to the software used in this product. MD5 Message-Digest Algorithm This product includes code that was developed by RSA Data Security, Inc. Copyright  1991-2, RSA Data Security, Inc. License to copy and use this software is granted provided that it is identified as the "RSA Data Security, Inc.
  • Page 218: Appendix 12Added And Changed Functions

    Appendix 12 Added and Changed Functions This section lists functions added to or changed in the A/D converter module. Added functions The following table shows the functions that were added to the A/D converter module and the versions supporting these functions.
  • Page 219: Appendix 13External Dimensions

    Appendix 13 External Dimensions External dimensions of the A/D converter module is as follows. • Spring clamp terminal block type 35.5 (1) Center of DIN rail (Unit: mm) • Screw terminal block type 35.5 21.5 (1) Center of DIN rail (Unit: mm) APPX Appendix 13 External Dimensions...
  • Page 220: Index

    INDEX ... . . 163 ......12 A/D conversion completed flag P1 LINK LED .
  • Page 221 MEMO...
  • Page 222: Revisions

    Japanese manual number: SH-082130-I This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.
  • Page 223: Warranty

    WARRANTY Please confirm the following product warranty details before using this product. 1. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be repaired at no cost via the sales representative or Mitsubishi Service Company.
  • Page 224: Information And Services

    INFORMATION AND SERVICES For further information and services, please contact your local Mitsubishi Electric sales office or representative. Visit our website to find our locations worldwide. MITSUBISHI ELECTRIC Factory Automation Global Website Locations Worldwide www.MitsubishiElectric.com/fa/about-us/overseas/ TRADEMARKS QR Code is either a registered trademark or a trademark of DENSO WAVE INCORPORATED in the United States, Japan, and/or other countries.
  • Page 226 SH(NA)-082131ENG-I(2504)MEE MODEL: CCIETSN-AD-U-E HEAD OFFICE: TOKYO BLDG., 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS: 1-14, YADA-MINAMI 5-CHOME, HIGASHI-KU, NAGOYA 461-8670, JAPAN When exported from Japan, this manual does not require application to the Ministry of Economy, Trade and Industry for service transaction permission. Specifications subject to change without notice.
