Page 2: Table Of Contents
Settings ............................................22 Audio ..............................................23 OSD Setup ..........................................24 Information ..........................................25 LED Indicator ............................................26 Troubleshoot ................................................27 Specification ................................................28 General Specification ........................................28 AOC Monitors Panel Pixel Defect Policy ................................30 Preset Display Modes ........................................32 Pin Assignments ...........................................33 Plug and Play ............................................34... -
Page 3: Safety
Safety National Conventions The following subsections describe national conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 4: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 5: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 6: Cleaning
Cleaning Clean the cabinet regularly with a water-dampened, soft cloth. When cleaning use a soft cotton or microfiber cloth. The cloth should be damp and almost dry, do not allow liquid into the case. Please disconnect the power cord before cleaning the product. -
Page 7: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 8: Setup
Monitor Quick Start Guide Warranty Card Stand Base USB Cable Power Cable HDMI Cable DisplayPort Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 9: Set-Up Stand & Base
Set-up Stand & Base Please setup or remove the base following the steps as below. Setup: Remove: NOTE: Display design may differ from those illustrated. -
Page 10: Adjusting Viewing Angle
Adjusting Viewing Angle To achieve the best viewing experience, it is recommended that the user can make sure they are able to look at their whole face on the screen, then adjust the monitor’s angle based on personal preference. Hold the stand so you will not topple the monitor when you change the monitor’s angle. You are able to adjust the monitor as below: 130mm 90°... -
Page 11: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor and Computer: 6 7 8 9 1. USB3.2 Gen2 downstream 2. USB3.2 Gen2 downstream 3. USB3.2 Gen2 downstream 4. USB3.2 Gen2 downstream+charging 5. USB upstream 6. HDMI 1 7. HDMI 2 8. -
Page 12: Wall Mounting
H=2.0 L=10+X Note: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. Always contact manufacturer for wall-mount installation. * Display design may differ from those illustrated. WARNING: 1. To avoid potential screen damage, such as panel peeling, ensure that the monitor does not tilt downward by more than -5 degrees. -
Page 13: Adaptive-Sync Function
Adaptive-Sync function 1. Adaptive-Sync function works with DisplayPort/HDMI 2. Compatible Graphics Card: Recommended list is as below, also could be checked by visiting www.AMD. Graphics Cards • Radeon™ RX Vega series • Radeon™ RX 500 series • Radeon™ RX 400 series •... -
Page 14: Hdr
It is compatible with input signals in HDR10 format. The display may automatically activate the HDR function if the player and content are compatible. Please contact the device manufacturer and the content provider for information on the compatibility of your device and content. -
Page 15: Adjusting
Adjusting Hotkeys Source/Exit Dual Resolution Dial Point Menu/Enter Power Menu/Enter Press to display the OSD or confirm the selection. Power Press the Power button to turn on the monitor. Dial Point When there is no OSD, press Dial Point button to show / hide Dial Point. Dual Resolution When there is no OSD, press “... -
Page 16: Osd Setting
OSD Setting Basic and simple instruction on the control keys. RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 3840x2160 60 HZ Standard Game Setting Dual Resolution Picture Gaming Mode PIP/PBP Shadow Control Settings Low Input Lag Audio Game Color OSD Setup Adaptive-Sync Information Dial Point... -
Page 17: Game Setting
Game Setting RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 3840x2160 60 HZ Standard Game Setting Dual Resolution Gaming Mode Picture PIP/PBP Shadow Control Settings Low Input Lag Audio Game Color OSD Setup Adaptive-Sync Information Dial Point Sniper Scope Dual UHD 120Hz / UHD Selected Dual Resolution mode. - Page 18 Disable or Enable MBR Sync (Motion Blur Remove). MBR Sync Off / On Note: The MBR Sync function can be adjusted when Adaptive- Sync is turned On, and the input signal is variable frequency. Adjust the response time. Normal Note: Fast 1.
-
Page 19: Picture
Picture RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 3840x2160 60 HZ Standard Game Setting Brightness Picture Contrast PIP/PBP Dark Boost Settings Sharpness Audio Gamma OSD Setup Eco Adjustment Information Color Temp. Brightness 0-100 Backlight Adjustment. Contrast 0-100 Contrast from Digital-register. Enhance the screen details in the dark or bright area to adjust Off / Level 1 / Dark Boost... - Page 20 Blue 0-100 Blue gain from Digital-register. R.Saturation 0-100 Adjust R.Saturation. G.Saturation 0-100 Adjust G.Saturation. B.Saturation 0-100 Adjust B.Saturation. C.Saturation 0-100 Adjust C.Saturation. M.Saturation 0-100 Adjust M.Saturation. Y.Saturation 0-100 Adjust Y.Saturation. R.Hue 0-100 Adjust R.Hue. G.Hue 0-100 Adjust G.Hue. B.Hue 0-100 Adjust B.Hue.
- Page 21 Full / Aspect / 1:1 / 17” (4:3) / 19” (4:3) / 19” (5:4) / 19”W (16:10) / 21.5”W (16:9)/ Image Ratio Select image ratio for display. 22”W (16:10)/ 23”W (16:9) / 23.6”W (16:9) / 24”W (16:9) Note: 1). When “HDR Mode” is enable, the items “Contrast”, “Dark Boost”, “Gamma”, “Eco Adjustment”, “Color Temp.”, “Color Space”...
-
Page 22: Pip/Pbp
PIP/PBP RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 3840x2160 60 HZ Standard Game Setting PIP/PBP Mode Picture Main Source PIP/PBP Sub Source Settings Audio Size Audio Position OSD Setup Swap Information PIP/PBP Mode Off / PIP / PBP Disable or Enable PIP or PBP. Main Source Select main screen source. - Page 23 3) When PBP/PIP is enabled, the compatibility of the main screen/sub-screen input source is shown in the following table: Main source HDMI1 HDMI2 HDMI1 Sub source HDMI2 Main source HDMI1 HDMI2 HDMI1 Sub source HDMI2...
-
Page 24: Settings
Settings RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 3840x2160 60 HZ Standard Game Setting Language Picture Input Select PIP/PBP Break Reminder Settings Off Timer DDC/CI Audio Reset OSD Setup Information Language Select the OSD language. Input Select Auto / HDMI1 / HDMI2 / DP Select Input Signal Source. -
Page 25: Audio
Audio RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 3840x2160 60 HZ Standard Game Setting Volume Picture Mute PIP/PBP Settings Audio OSD Setup Information Volume 0-100 Volume Adjustment. Mute Off / On Mute the volume. -
Page 26: Osd Setup
OSD Setup RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 3840x2160 60 HZ Standard Game Setting Transparence Transparence Transparence Picture H. Position H. Position H. Position V. Position V. Position V. Position PIP/PBP Time out Time out Time out Settings User Key Audio OSD Setup... -
Page 27: Information
Information RESOLUTION REFRESH RATE GAMING MODE BRIGHTNESS INPUT SOURCE 60 HZ Standard 3840x2160 Game Setting Model Name U27G4R Resolution 3840(H)x2160(V)/60Hz Picture PIP/PBP Sync Adaptive-Sync Settings Audio Firmware Version xxxxxxxxxxxxx Serial Number xxxxxxxxxxxxx OSD Setup Information... -
Page 28: Led Indicator
LED Indicator Status LED Color Full Power Mode White Active-off Mode Orange... -
Page 29: Troubleshoot
Please refer to Regulation & Service Information which is in the CD manual or www.aoc.com (to find the model you purchase in your country and to Regulation & Service find Regulation & Service Information in Support page. -
Page 30: Specification
Specification General Specification Model name U27G4R Driving system TFT Color LCD Viewable Image Size 68.4 cm diagonal Panel Pixel pitch 0.15525mm(H) x 0.15525mm(V) Video HDMI lnterface & DisplayPort Interface Display Color 1.07B Colors Horizontal scan range 30k~360kHz Horizontal scan 596.16mm... - Page 31 Note: [1]The maximum number of display colors supported by this product is 1.07 billion, and the setting conditions are as follows (there may be differences due to the output limitation of some graphics cards) (“V”:support, “\” :nonsupport): HDMI2.1 DisplayPort1.4 YCbCr420 YCbCr420 YCbCr444 YCbCr444 RGB...
-
Page 32: Aoc Monitors Panel Pixel Defect Policy
Monitor panels used in the monitors are sometimes unavoidable. No manufacturer can guarantee that all panels will be free from pixel defects, but AOC guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty. This notice explains the different types of pixel defects and defines acceptable defect levels for each type. - Page 33 Pixel Defect Tolerances In order to qualify for repair or replacement due to pixel defects during the warranty period, a Monitor panel in a AOC panel monitor must have pixel or sub pixel defects exceeding the tolerances listed in the web manual.
-
Page 34: Preset Display Modes
Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION(±1Hz) FREQUENCY(KHz) FREQUENCY(Hz) 640×480@60Hz 31.469 59.94 640×480@67Hz 66.667 640×480@72Hz 37.861 72.809 640×480@75Hz 37.5 640×480@100Hz 51.08 99.769 640×480@120Hz 61.91 119.518 DOS MODE 720×400@70Hz 31.469 70.087 800×600@56Hz 35.156 56.25 800×600@60Hz 37.879 60.317 800×600@72Hz 48.077 72.188 SVGA 800×600@75Hz 46.875 800×600@100Hz... -
Page 35: Pin Assignments
Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name TMDS Data 2+ TMDS Data 0- DDC/CEC Ground TMDS Data 2 Shield TMDS Clock + +5V Power TMDS Data 2- TMDS Clock Shield Hot Plug Detect TMDS Data 1+ TMDS Clock-... -
Page 36: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
