- Page 1 2CDC 550 004 D0201 │ 06.2014 Technical Manual Heating Actuator Heating Actuator HA-M-0.6.1 (6254/0.6) HA-M-0.12.1 (6254/0.12)
- Page 2 Overview of types _____________________________________________________________________ 7 Function overview _____________________________________________________________________ 8 Description of functions _________________________________________________________________ 9 Device overview of 6gang heating actuator HA-M-0.6.1 _______________________________________ 13 Device overview of 12gang heating actuator HA-M-0.12.1 _____________________________________ 13 Technical data ____________________________________________________________________ 14 Overview of HA-M-0.6.1 and HA-M-0.12.1 _________________________________________________ 14...
- Page 3 Please keep this manual in a safe place. If you pass the device on, also include this manual. If you require additional information or have questions about the device, please contact ABB STOTZ-KONTAKT GmbH or visit our Internet site at: www.abb.com/freeathome │3...
- Page 4 However, residual hazards remain. Read and adhere to the safety instructions to pre- vent such hazards. ABB STOTZ-KONTAKT GmbH accepts no liability for failure to observe the safety in- structions. Used symbols The following symbols point to particular dangers involved in the use of the device and provide practical instructions.
- Page 5 ® ABB-free@home Safety Intended use The heating actuator must only be operated within the specified technical data. The heating actuator is a rail mounting device for installing in distributors. The heating actuator serves for the activation of valves via thermoelectric actuating drives for room temperature control.
- Page 6 ® ABB-free@home Environment Environment Always dispose of the packaging material and electric devices and their compo- nents via the authorized collecting depots and disposal companies. The products meet the legal requirements, in particular the laws governing elec- tronic and electrical devices and the REACH ordinance.
- Page 7 Three channels can be protected together by a circuit-breaker. Note Basic information about system integration is contained in the system man- ual. It is available for downloading at www.abb.com/freeathome. Scope of supply The scope of supply contains the heating actuator including bus terminal for cou- pling to the free@home bus.
- Page 8 ® ABB-free@home Product description Function overview The following table provides an overview of the possible functions and applica- tions of the device: Icon in the operating surface Information Name: Heating actuator Function: For the activation of valves in heating cir-...
- Page 9 Depending on the difference between both temperatures (control deviation) the room temperature controller creates a control value that is transmit- ted to the heating actuator (HA-M-0.6.1 or HA-M-0.12.1). The heating actuator, in dependence of the control value, controls one or several thermal actuating drives which set the valves in the heating or cooling circuit.
- Page 10 ® ABB-free@home Product description 4.4.1 Heating actuator, heating valves This function is to be selected if only one heating system (e.g. floor heating, heat- ers, etc.) is to be controlled (no cooling). The channel of the heating actuator, which sets the valve in the pre-run of the heating circuit, is to be linked with the room temperature controller in menu "Linking"...
- Page 11 ® ABB-free@home Product description 4.4.3 Actuator for heating and cooling, valve for heating and cooling This function is to be selected if a heating system is used for which the same cir- cuit, e.g. dependent on the season, is used for heating or cooling. The respective...
- Page 12 ® ABB-free@home Product description 4.4.5 Controlling parallel heating and cooling circuits If several thermal systems which have appropriate heating and cooling circuits are operated parallel to heating and cooling, a thermal actuating drive is to be used for each valve of a circuit of a system. The corresponding channels are, de- pending on the connected heating or cooling system, to be configured as "Valve...
- Page 13 ® ABB-free@home Product description Device overview of 6gang heating actuator HA-M-0.6.1 Fig. 5: Device overview of 6gang heating actuator Device identification during commissioning Identification LED Bus connection terminal Connecting terminals for thermal actuating drives Device overview of 12gang heating actuator HA-M-0.12.1 Fig.
- Page 14 ® ABB-free@home Technical data Technical data Overview of HA-M-0.6.1 and HA-M-0.12.1 Parameters Value Power supply 24 V DC (via the bus) Bus subscribers 1 (12 mA) Connection (free@home) Bus connection terminal: 0.4 - 0.8 mm Line type J-Y(St)Y, 2 x 2 x 0.8 mm...
- Page 15 ® ABB-free@home Technical data Rail mounting device Modular installation device, (MDRC) Pro M Installation width 4 or 8 modules à 18 mm Design Installation depth 64.5 mm Plastic, basalt grey Housing, colour (RAL 7012) 72 x 90 x 64.5 mm (W x H x D) Dimensions 144 x 90 x 64.5 mm (W x H x D)
- Page 16 ® ABB-free@home Technical data Dimensions Note All dimensions are in mm. Heating Actuator HA-M-0.6.1 Fig. 7: Dimensions of 6gang heating actuator Heating Actuator HA-M-0.12.1 Fig. 8: Dimensions of 12gang heating actuator │16 Technical Manual 2CDC 550 004 D0201...
- Page 17 ® ABB-free@home Technical data Connection diagram Heating Actuator HA-M-0.6.1 Fig. 9: Electrical connection of 6gang heating actuator │17 Technical Manual 2CDC 550 004 D0201...
- Page 18 ® ABB-free@home Technical data Heating Actuator HA-M-0.12.1 Fig. 10: Electrical connection of 12gang heating actuator │18 Technical Manual 2CDC 550 004 D0201...
- Page 19 ® ABB-free@home Mounting Mounting Safety instructions for mounting Danger Risk of death due to electrical voltage Dangerous currents flow through the body when coming into direct or indi- rect contact with live components. This results in electric shock, burns or even death.
- Page 20 ® ABB-free@home Mounting Danger Risk of death due to short-circuit Risk of death due to electrical voltage of 230 V during short-circuit in the low-voltage line. » During mounting observe the spatial division (> 10 mm) of SELV electric circuits to other electric circuits.
- Page 21 ® ABB-free@home Mounting Installation/mounting The device is a rail mounting device for installing in distributors for easy installa- tion on 35 mm mounting rails according to DIN EN 60 715. The device can be mounted in any position. The stick-on label is to be removed and glued into the list (see system manual System Access Point).
- Page 22 ® ABB-free@home Mounting Electrical connection » The electrical connection is made via screw terminals. The bus connection is established by means of the enclosed bus connection terminal. The terminal designation is located on the housing. » The bus line connection is established by means of the enclosed bus con- nection terminal (red/black).
- Page 23 ® ABB-free@home Commissioning Commissioning Commissioning is always carried out via the Web-based surface of the System Access Point. The System Access Point establishes the connection between the free@home participants and the smartphone, tablet or PC. It is used to identify and program the participants during commissioning.
- Page 24 ® ABB-free@home Commissioning Allocation of devices and specifying channels The devices connected to the system must be identified, i.e. they are allocated to a room according to their function and are given a descriptive name. The allocation is made via the allocation function of the Web- based user interface of the System Access Point.
- Page 25 ® ABB-free@home Commissioning Fig. 12: Allocation A pop-up window opens automatically which lists all the devices suitable for the application selected. The desired device can be identified in two ways. │25 Technical Manual 2CDC 550 004 D0201...
- Page 26 ® ABB-free@home Commissioning Identification via serial number Fig. 13 Identification via serial number » Compare the short 3-digit number of the identification label with the numbers in the list and in this way identify the device you are searching for and, if nec- essary, also the channel.
- Page 27 ® ABB-free@home Commissioning Assigning a name Fig. 14: Assigning a name » Enter a name that is easy to understand and under which the application is to be displayed later (e.g. "Living room heating"). » Press the tick at the bottom right to take over the entry.
- Page 28 ® ABB-free@home Commissioning Setting options per channel General settings and parameter settings can be made for each channel. The settings are made via the allocation function of the Web- based user interface of the System Access Point. Device selection Fig. 15: Device selection »...
- Page 29 ® ABB-free@home Commissioning 7.2.1 Heating actuator settings Changing the name Deleting the channel via "X" Selection of function (see sec- tion 4.3) Selection of channel contact type Specifying the control value to be ap- plied during a fault │29 Technical Manual 2CDC 550 004 D0201...
- Page 30 ® ABB-free@home Commissioning Linking The heating actuators created via the allocation function can now be linked with a second device (e.g. room temperature controller). The linking in the list view is then made via the linking function of the Web-based user interface of the System Access Point.
- Page 31 ® ABB-free@home Updating options Updating options A firmware update is carried out via the Web-based user interface of the System Access Point. For this, visit the free@home website www.abb.com/freeathome. │31 Technical Manual 2CDC 550 004 D0201...
- Page 32 ® ABB-free@home Maintenance Maintenance The device is maintenance-free. In case of damage (e.g., during transport or stor- age), do not perform repairs. Once the device is opened, the warranty is void! Access to the device must be guaranteed for operation, testing, inspection, maintenance and repairs (according to DIN VDE 0100-520).
- Page 33 69123 Heidelberg, Germany content of this document without prior notice. Telephone: +49 2351 956-1600 The respective agreed-upon conditions apply to orders. ABB accepts no responsibility for E-mail: knx.helpline@de.abb.com possible errors or incompleteness in this www.abb.com/freeathome document.
