Your Work Never Looked Better
USER MANUAL
TABLE OF CONTENTS
FOR YOUR SAFETY -------------------------------------------------- 1
SAFETY PRECAUTIONS -------------------------------------- 2
BEFORE YOU OPERATE THE MONITOR ---------------------- 3
FEATURES -------------------------------------------------------- 3
PACKING LIST --------------------------------------------------- 3
INSTALLATION INSTRUCTIONS ---------------------------
CONTROLS AND CONNECTORS -------------------------- 4
OPERATING INSTRUCTIONS ------------------------------------- 5
GENERAL INSTRUCTIONS ---------------------------------- 5
HOW TO ADJUST A SETTING ------------------------------ 6
ADJUSTING THE PICTURE ---------------------------------- 7
POWER MANAGEMENT FEATURE -----------------------
PLUG AND PLAY ------------------------------------------------ 9
TECHNICAL SUPPORT(FAQ) -------------------------------------10
APPENDIX ---------------------------------------------------------------11
SPECIFICATIONS ------------------------------------------
FACTORY PRESET TIMING TABLE -----------------------13
CONNECTOR PIN ASSIGNMENT ------------------------- 13
LIMITED THREE-YEAR WARRANTY -----------------------14-15
Thank you very much for choosing the AOC Color Monitor.
We recommend that you take a few minutes to read carefully through this brief
but comprehensive manual before installing and switching on the monitor.
Please keep this manual in a safe place for you future reference.
Plug & Play Drivers for the AOC Spectrum Series Monitors are available
at AOC's Web Site: www.aoc-europe.com
9Elr/9ElrA
9Elr+/9ElrA+
1
ENGLISH
DEUTSCH
FRANÇAIS
3
ESPAÑOL
ITALIANO
7
11-12
Advertisement
Table of Contents
Related Manuals for AOC Spectrum 9Elr
Summary of Contents for AOC Spectrum 9Elr
-
Page 1: Table Of Contents
We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a safe place for you future reference. Plug & Play Drivers for the AOC Spectrum Series Monitors are available at AOC’s Web Site: www.aoc-europe.com... - Page 2 Before operating the monitor please read this manual thoroughly. This manual should be retained for future reference. FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 PRECAUTIONS ? Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement. ? Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance.
-
Page 4: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR FEATURES 48.3cm(19”) Color Monitor Crisp, Clear Display for Windows Supports Resolutions up to 1600 ? 1200 Power Management Ergonomic Design (MPR II Approved) Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE MONITOR PACKAGE The product package should include the following items: Monitor Owner's Manual... -
Page 5: Power Cord
POWER CORD Power Source: 1. Make sure the power cord is the correct type that required in your area. 2. This monitor has a universal power supply that allows operation in either 100/120V AC or 220/240V AC voltage area ( No user adjustment is required. ) 3. -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS The power switch is located at front panel of the monitor. Press the power switch to turn the monitor on or off. The other control knobs are located at the base of the monitor (See Figure 3). By changing these settings, the picture can be adjusted to your personal preferences. -
Page 7: How To Adjust A Setting
NOTES Do not install the monitor in a location near heat sources such as radiators or air ducts , or in a place subject to direct sunlight , or excessive dust or mechanical vibration or shock. Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your monitor. -
Page 8: Adjusting The Picture
ADJUSTING THE PICTURE The description for function control LEDS CONTRAST Adjust the picture contrast. BRIGHTNESS Adjust the picture brightness. H-SIZE Adjust the picture’ s horizontal size. H-CENTER Adjust the horizontal position of the picture. V-SIZE Adjust the picture’ s vertical size. V-CENTER Adjust the vertical position of the picture. -
Page 10: Plug And Play
Suspend Mode When the V-sync signal from the computer is off, the monitor enters into Suspend Mode which reduces the power consumption to less than 15W. The screen becomes dark, and the power indicator turns to orange. From Suspend Mode, the screen reappears instantaneously when the keyboard or the mouse is touched again. - Page 11 Plug & Play DDC1/2B Feature This monitor is equipped with VESA DDC1/2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
-
Page 12: Technical Support(Faq)
TECHNICAL SUPPORT (FAQ) Problem & Question Possible Solution Power LED is not on *Check if the Power Switch is in the ON position *Power Cord should be connected No Plug & Play *Check if the PC system is Plug & Play compatible *Check if the Video Card is Plug &... -
Page 13: Appendix
APPENDIX SPECIFICATIONS CRT Size 48.3cm(19"), 90º deflection, 29mm neck, Viewable Image 45.7cm (18"), diagonal Size Type 0.27mm dot pitch. Video 0.7Vpp, R,G,B Analog Input Separate Sync. TTL Level H./V.- Sync. Positive / Negative Scanning H-Frequency 30kHz - 95kHz Frequency V-Frequency 50Hz-160Hz Max. - Page 14 Switch Power On/Off switch UP/Down Key Function Key Volume(9EA/9ElrA) External Controls: Functions Contrast Brightness H-Center H-Size V-Center V-Size Pincushion Trapezoid Rotation Degauss Recall Plug & Play DDC1/2B Power Management EPA, VESA DPMS Power Consumption ( Maximum ) 120 Watts Pre-set Display Area 346mm x 260mm Audio Output Rated Power 1W rms...
-
Page 15: Factory Preset Timing Table
FACTORY PRESET TIMING TABLE HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY FREQUENCY 720 × 400 31.5kHz 70Hz 640 × 480 31.5kHz 60Hz VESA/85 640 × 480 43.3kHz 85Hz VESA/85 800 × 600 53.7kHz 85Hz VESA/85 1024 × 768 68.7kHz 85Hz VESA/85 1280 × 960 85.9kHz 85Hz VESA/85...
