AOC 912Sw Service Manual

AOC 912Sw Service Manual

19" lcd color monitor

Advertisement

19" LCD Color Monitor
Service
Service
Service
Description
Table Of Contents......................................................1
Revision List........................................................2
1. Monitor Specification...............................................3
2. LCD Monitor Description........................................4
3. Operation Instruction............................................5
3.1. General Instructions.........................................5
3.2. Control Button......................................................5
3.3 Adjusting the Picture..........................................6
4. Input/Output Specification.......................................8
4.1. Input Signal Connector.........................................8
4.2. Factory Preset Display Modes...........................8
5. Panel Specification.........................................9
5.1. General Feature...............................................9
5.2. Optical Characteristics....................................10
5.3 Electrical Characteristics..............................10
6. Block Diagram.....................................................11
6 . 1 S o f t w a r e F l o w C h a r t ... ... ... ... ... ... ... . . . 11
6.2.Electrical Block Diagram...........................13
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

TABLE OF CONTENTS

Page
Description
7. Schematic.....................................................15
7.1 Main Board....................................................15
7.2 Power Board...............................................20
8.PCB Layout...............................................22
8.1. Main Board.................................................22
8.2. Power Board..........................................25
8.3. Key Board...............................................27
9. Maintainability................................................28
9.2. Trouble Shooting.......................................29
9.2.1 Main Board..........................................29
9.2.2 Power Board.......................................32
9.2.3 Key Board..........................................34
11. Monitor Exploded View.....................................36
12. BOM List.....................................................37
13. Different Parts List..............................................46
SAFETY NOTICE
1
AOC 912Sw
Horizontal Frequency
30-83 kHz
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 912Sw and is the answer not in the manual?

Questions and answers

Summary of Contents for AOC 912Sw

  • Page 1: Table Of Contents

    19" LCD Color Monitor AOC 912Sw Service Service Service Horizontal Frequency 30-83 kHz TABLE OF CONTENTS Description Page Description Page 7. Schematic……………........15 Table Of Contents..……......…..1 7.1 Main Board..………........15 Revision List.…........……..2 1. Monitor Specification......………..3 7.2 Power Board.….……........20 8.PCB Layout..……........22 2. LCD Monitor Description……………………………..4 8.1.
  • Page 2: Revision List

    19" LCD Color Monitor AOC 912Sw Revision List Revision Date Revision History TPV Model Mar.-22-2007 Initial release T97HM5DKWCMMFE May.-08-2007 Add TPVDW Model in Item 13 T97SM5MDWCA4NE T98SM5DKWCA1NGE Nov.-07-2008 Add TPVDW Model in Item 13 T98SM5DKWCA1NBE T98SM5DKWCA2NGE...
  • Page 3: Monitor Specification

    19" LCD Color Monitor AOC 912Sw 1. Monitor Specifications Model number 912Sw Driving system TFT Color LCD Size 48cm(19.0" 16:10) Pixel pitch 0.285mm(H) x 0.285mm(V) LCD Panel Video R, G, B Analog lnterface Separate Sync. H/V TTL Display Color 16.2million Colors...
  • Page 4: Lcd Monitor Description

    19" LCD Color Monitor AOC 912Sw 2. LCD Monitor Description The LCD MONITOR will contain a main board, a power board, an audio board and a key board which house the flat panel control logic, brightness control logic and DDC.
  • Page 5: Operation Instruction

    19" LCD Color Monitor AOC 912Sw 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The control buttons are located in the front of the monitor. By changing these settings, the picture can be adjusted to your personal preferences.
  • Page 6: Adjusting The Picture

    19" LCD Color Monitor AOC 912Sw 3.3 Adjusting the Picture Adjustment steps: 1. Press the MENU-button to activate the OSD window. 2. Press < or > to select the desired function. 3. Press the MENU-button to select the function that you want to adjust.
  • Page 7 19" LCD Color Monitor AOC 912Sw Main Main Sub Menu Menu Menu Menu Description Icon Item Icon Item Contrast Contrast from Digital-register. Luminance Brightness Backlight Adjustment Focus Adjust Picture Phase to reduce Horizontal-Line noise Image Setup Clock Adjust picture Clock to reduce Vertical-Line noise.
  • Page 8: Input/Output Specification

    19" LCD Color Monitor AOC 912Sw 4. Input/Output Specification 4.1 Input Signal Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Green Detect Cable Blue Ground Ground DDC-Serial Data Ground H-Sync R-Ground V-Sync G-Ground DDC-Serial Clock B-Ground 15 - Pin Color Display Signal Cable 4.2 Factory Preset Display Modes...
  • Page 9: Panel Specification

    19" LCD Color Monitor AOC 912Sw 5 Panel Specification 5.1 Display Characteristics 5.2 Optical Characteristics...
  • Page 10: Electrical Characteristics

    19" LCD Color Monitor AOC 912Sw 5.3 Parameter guide line for CCFL Inverter TFT LCD Module: Back Light Unit:...
  • Page 11: Block Diagram

    19" LCD Color Monitor AOC 912Sw 6. Block Diagram 6.1 Software Flow Chat...
  • Page 12 19" LCD Color Monitor AOC 912Sw 1) MCU initialize. 2) Is the EPROM blank? 3) Program the EPROM by default values. 4) Get the PWM value of brightness from EPROM. 5) Is the power key pressed? 6) Clear all global flags.
  • Page 13: Electrical Block Diagram

    19" LCD Color Monitor AOC 912Sw 6.2 Electric Block Diagram 6.2.1 Main Board Crystal (14.318MHz) LCD interface (X401) (CN101) EEPROM Scalar TSUM16AWK M24C16 (Include MCU, ADC, OSD) (U403) (U401) H sync V sync D-Sub Connector (CN405) EEPROM M24C02 (U404)
  • Page 14 19" LCD Color Monitor AOC 912Sw 6.2.2 Inverter / Power Board AC inlet Filter Rectifier and Transform Rectifier and 12V/5V filter filter D908, D909 To main board Start circuit R904, R931, R938 OVP/OCP circuit Switching circuit Feedback PWM control circuit IC902, IC&MOSFET...
  • Page 15: Schematic

    19" LCD Color Monitor AOC 912Sw 7. Schematic 7.1 Main Board TSUM16AWK SCHEMATIC XGA/SXGA LVDS OUTPUT GNDR GNDR GNDG GNDG GNDB GNDB HSY NC HSY NC VCC1.8 VCC3.3 +12V VSY NC VSY NC DDCA_SDA DDCA_SDA DDCA_SCL DDCA_SCL DET_VGA DET_VGA DDC_WP DDC_WP VCC1.8...
  • Page 16 19" LCD Color Monitor AOC 912Sw SOT-223 U701 VCTRL +3V3 NC/LT1117-18 R702 +3V3 1/16W   C701 C703 C704 VCC1.8 22uF/50V C702 VCC1.8 22uF/50V D701 Q702 SMAL140 R703 PZT2907A BL_ADJ(DC)   1/16W 0V ~ 3.3V 4.7K D702 0V ~ 5V 4.7K 4.7K...
  • Page 17 19" LCD Color Monitor AOC 912Sw CN405 R491 PC5V   1/16W FB410   1/16W DB15 RED+ R434   1/16W C432 0.047uF RED- GREEN+ FB411 1/16W R435 1/16W C433 0.047uF     GREEN- BLUE+ FB412   1/16W R436   1/16W C434 0.047uF...
  • Page 18 19" LCD Color Monitor AOC 912Sw VDVI VMPLL VPLL AVDD VDDP VDDC VCC1.8 FB401 VDDC VCC3.3 FB402 AVDD VCC1.8 600 OHM VCC3.3 600 OHM C403 C407 VCC3.3 22uF/50V 0.1uF VCTRL VCTRL C404 C405 C406 0.1uF 0.1uF 0.1uF NC/LVACKP/NC R490 RIN0P...
  • Page 19 19" LCD Color Monitor AOC 912Sw PB[0..5] PB[0..5] CN102 CN103 PA[0..7] RB1P PA[0..7] PA[0..7] RB1N PA[0..7] LVACKP RB2P RA3N FB0N RB3N RA1P LVACKM RB2N RA3P FB0P RB3P RA1N LVA2P RB3P RA2P LVA2M RB3N RA2N FB1N RB2N RA2N LVA1P RA2P FB1P...
  • Page 20: Power Board

    F901   0805 KIA431A-AT/P C913 FUSE R922 R924   0805 2.4K   0805 1% CN901 AOC (Top Victory) Electronics Co., Ltd. SOCKET Title 1.POWER OUTPUT 12V & 5 V Size Document Number G1899-1-HP-X-1-060720 Date: Friday , July 21, 2006 Sheet...
  • Page 21 C831 C827 BAV99 R824 BAV99 0.0033uF/16V 470pF/50V D805 BAV99 Q805 750Ω 1/8W AM9945 AOC (Top Victory) Electronics Co., Ltd. Title HP W19 series 17" 19'' 4 LAMPS INVERTER R830 R831 82KΩ 1/8W 7.5K   0805 Size Document Number G1899-1-HP-X-1-060720 Date:...
  • Page 22: Pcb Layout

    19" LCD Color Monitor AOC 912Sw 8. PCB Layout 8.1 Main Board...
  • Page 23 19" LCD Color Monitor AOC 912Sw...
  • Page 24 19" LCD Color Monitor AOC 912Sw...
  • Page 25: Power Board

    19" LCD Color Monitor AOC 912Sw 8.2 Power Board...
  • Page 26 19" LCD Color Monitor AOC 912Sw...
  • Page 27: Key Board

    19" LCD Color Monitor AOC 912Sw 8.3 Key Board...
  • Page 28: Maintainability

    19" LCD Color Monitor AOC 912Sw 9. Maintainability 9.1 Equipments and Tools Requirement Voltmeter. Oscilloscope. Pattern Generator. DDC Tool with an IBM Compatible Computer. Alignment Tool. LCD Color Analyzer. Service Manual. User Manual.
  • Page 29: Trouble Shooting

    19" LCD Color Monitor AOC 912Sw 9.2 Trouble Shooting 9.2.1 Main Board No Power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the...
  • Page 30 19" LCD Color Monitor AOC 912Sw No Picture (LED orange) No picture The button if under X401 oscillate Replace X401 control waveform is normal Check reset circuit of Check Correspondent U401 is normal component Measure U702 Vout=3.3V Q702 Vc=1.8V Replace U401...
  • Page 31 19" LCD Color Monitor AOC 912Sw White Screen White screen Measure C725 (+) =5V Checks Q704, Q706, are broken Replace Q704, Q706 Check CN101 connector or Check X401 solder normal? Replace X401 Replace CN101 or re-solder Replace U401 Replace PANEL...
  • Page 32: Power Board

    19" LCD Color Monitor AOC 912Sw 9.2.2 Power Board 1. No Power No power Check to CN902 Pin1, 2 =12V and Pin3, 4 = 5 V Check Interface board Check AC line volt 120V or 220V Change F901, Check BD901, Q903, IC901...
  • Page 33 19" LCD Color Monitor AOC 912Sw 2. W/LED No Backlight Check C811 (+) =12V Check adapter circuit Check ON/OFF signal Check Interface board Check IC801 PIN2=5V Check Q801,Q802,Q803 Check the Pin1, Pin15 of IC801 have square wave Check IC801 Check Q805,Q806 have the output of square wave at short time.
  • Page 34: Key Board

    19" LCD Color Monitor AOC 912Sw 9.2.3 Key Board OSD is unstable or not working Is Keypad board connecting normally? Connect Keypad Board Replace Button Switch Is Button Switch normally? Replace Keypad Board Is Keypad board normally? Check main board...
  • Page 35: White-Balance, Luminance Adjustment

    6500 color temp. parameter is x = 313±20, y = 329 ±20, Y =180 cd/m 3. Into factory mode of 912Sw Turn on power, press the MENU button, pull out the power cord, and then plug the power cord. Then the factory OSD will be at the left top of the panel.
  • Page 36: Monitor Exploded View

    19" LCD Color Monitor AOC 912Sw 11. Monitor Exploded View...
  • Page 37: Bom List

    19" LCD Color Monitor AOC 912Sw 12. BOM List T97HM5DKWCMMFE Location Part No. Description 026G 800504 7 BARCODE LABEL 041G780061553A TCO'03 CARD 052G 1185 MIDDLE TAPE 052G 1186 SMALL TAPE Conductive Tape 45mm *25mm *0.08mm (单导) 052G 1207 A Conductive Tape 75mm *45mm *0.08mm (单导)...
  • Page 38 19" LCD Color Monitor AOC 912Sw 040G 45762412B CBPC LABEL 055G 23524 WELDING FLUX WITHOUT PB 055G 100611 TIN STICK W/O PB C717 067G215V100 7N KY50VB10-M-CC3 5*11.5MM 10uF M 50V C418 067G215V100 7N KY50VB10-M-CC3 5*11.5MM 10uF M 50V C712 067G215V101 4N KY25VB100M-CC3(6.3*11) 100uF M 25V...
  • Page 39 19" LCD Color Monitor AOC 912Sw R451 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W R452 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W R470 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W R487 061G0603103 RST CHIPR 10 KOHM +-5% 1/10W R489 061G0603103...
  • Page 40 19" LCD Color Monitor AOC 912Sw C424 065G0603104 32 CHIP 0.1UF 50V X7R C426 065G0603104 32 CHIP 0.1UF 50V X7R C427 065G0603104 32 CHIP 0.1UF 50V X7R C428 065G0603104 32 CHIP 0.1UF 50V X7R C429 065G0603104 32 CHIP 0.1UF 50V X7R...
  • Page 41 19" LCD Color Monitor AOC 912Sw D411 093G 39147SEM ZMM5V6ST D412 093G 39147SEM ZMM5V6ST D407 093G 64 42 P BAV70 SOT23 BY PAN JIT D403 093G 6433P BAV99 D404 093G 6433P BAV99 D405 093G 6433P BAV99 D425 093G 39S 45 T...
  • Page 42 19" LCD Color Monitor AOC 912Sw PT802 080GL19T 8DN1 X'FMR DARFONTK.2006M.101 PT801 080GL19T 8DN1 X'FMR DARFONTK.2006M.101 CN901 087G 501 27 RF GP AC SOCKET CN902 095G8014 12569 WIRE HARNESS 0P1G1730 8120 SCREW 705G 980 61S01 R905 ASS'Y 705G 980 61S02...
  • Page 43 19" LCD Color Monitor AOC 912Sw R912 061G0805103 RST CHIPR 10K OHM +-5% 1/8W R815 061G0805104 RST CHIPR 100K OHM +-5% 1/8W R913 061G0805104 RST CHIPR 100K OHM +-5% 1/8W R813 061G0805105 RST CHIPR 1M OHM +-5% 1/8W R846 061G0805105...
  • Page 44 19" LCD Color Monitor AOC 912Sw R906 061G1206470 RST CHIPR 47 OHM +-5% 1/4W R935 061G1206470 RST CHIPR 47 OHM +-5% 1/4W R934 061G1206470 RST CHIPR 47 OHM +-5% 1/4W R805 061G1206471 RST CHIPR 470 OHM +-5% 1/4W R919 061G1206471...
  • Page 45 19" LCD Color Monitor AOC 912Sw D805 093G 6433S DIODE BAV99 SEMTECH D806 093G 6433S DIODE BAV99 SEMTECH ZD801 093G 39S 24 T RLZ 5.6B LLDS ZD902 093G 39S 24 T RLZ 5.6B LLDS ZD903 093G 39S 38 T PTZ 9.1B...
  • Page 46: Different Parts List

    19" LCD Color Monitor AOC 912Sw 13. Different Parts List Diversity of T97SM5MDWCA4NE compared with T97HM5DKWCMMFE Location Part No. Description 026G 800504 H BARCODE 040G 45760819A DATE/MODEL LABEL 040G 58162435A P/N LABEL FOR MANUAL PE BAG 041G 68623 1A Certificated card...
  • Page 47 19" LCD Color Monitor AOC 912Sw H41G780061520A CENTER LIST Q52G 1185 66 Big tape for aoc carton Diversity of T98SM5DKWCA2NGE compared with T97HM5DKWCMMFE Location Part No. Description 026G 800504 2H BAR CODE 040G 58162435A P/N LABEL FOR MANUAL PE BAG...
