WT415
Cat No.
Assembly Instructions - Please keep for future reference
Cadiz Rattan 4 Seater Cube Set
No. People
Assembly Time
50 - 80
Minutes
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the JDW customer helpline: 0871 231 2000
Advertisement
Related Manuals for N Brown Group Cadiz WT415
Summary of Contents for N Brown Group Cadiz WT415
- Page 1 WT415 Cat No. Assembly Instructions - Please keep for future reference Cadiz Rattan 4 Seater Cube Set No. People Assembly Time 50 - 80 Minutes Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the JDW customer helpline: 0871 231 2000...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • • • Check you have all the Make sure you have We do not recommend the components and tools enough space to lay out use of power listed on the next pages.
-
Page 3: Exploded View
Exploded View... -
Page 4: Components - Fixings
Components - Panels Please check that you have all the components listed below before constructing your item. Part No Description Components - Fixings Please check that you have all the components listed below before constructing your item. M6x35mm M6x25mm M6x15mm Tools Required Allan Key Ruler - Use this to measure your screws (mm) - Page 5 Assembly Instructions Note: All Bolt Head Caps and Nut Caps should not be attached before finally tightening all Bolts with the Allen Key. Only tighten all bolts when you are satisfied with the alignment of all components. Step 1 • Connect the chair right armrest part (Part A) with the back part (Part B),...
- Page 6 Step 3 • Connect the chair left armrest part (Part D) with the seat part (Part C), fasten them by bolts (Part K) and washers (Part N). Step 4 • Connect the chair left armrest part (Part D) with the back part (Part B), fasten them by bolts (Part K) and...
- Page 7 Step 5 • Put the seat cushion (Part I) on the seat, put the back pillow (Part J) on the seat cushion. Step 6 • Connect the two table leg tube (Part E and Part F), fasten them by bolts (Part L) and washers (Part N).
- Page 8 Step 7 • Put the table top frame on the ground. Connect the table leg tube (Part E and Part F) with the table top (Part G), fasten them by bolts (Part L and Part M) and washers (Part N). Step 8 •...
- Page 9 Manchester M60 6ES...
