RE446
Cat No.
Assembly Instructions - Please keep for future reference
Kempton Coffee Set Brown
No. People
Assembly Time
30 - 60
Minutes
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the JDW customer helpline: 0871 231 2000
Advertisement
Related Manuals for N Brown Group Kempton RE446
Summary of Contents for N Brown Group Kempton RE446
- Page 1 RE446 Cat No. Assembly Instructions - Please keep for future reference Kempton Coffee Set Brown No. People Assembly Time 30 - 60 Minutes Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the JDW customer helpline: 0871 231 2000...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Make sure you have • We do not recommend the components and tools enough space to lay out use of power listed on the next pages.
- Page 3 Exploded View...
- Page 4 Components - Panels Please check that you have all the components listed below before constructing your item. Part No Description...
-
Page 5: Components - Fixings
Components - Fixings Please check that you have all the components listed below before constructing your item. M6x25mm M6x30mm M6x15mm Tools Required Allan Key Ruler - Use this to measure your screws (mm) - Page 6 Assembly Instructions Note: All Bolt Head Caps and Nut Caps should not be attached before finally tightening all Bolts with the Allen Key. Only tighten all bolts when you are satisfied with the alignment of all components. Step 1 • Connect the table leg part (Part A) with the side part (Part B), fasten...
- Page 7 Step 3 • Connect another table side part (Part B) with the leg part, fasten them by bolts (Part L) and washers (Part N). Step 4 • Add the adjusting knob (Part O) to the bottom of the table leg. Put the table top part (Part C) into the table middle...
- Page 8 Step 5 • Put the table glass (Part K) on the table top. Step 6 • Connect the chair right armrest part (Part J1) with the chair back part (Part D) by insert. Fasten them together by bolts (Part M) and washers(Part N).
- Page 9 Step 8 • Connect the chair left armrest part (Part J2) with the chair back part by insert and bolts (Part M) and washers (Part N). • Fasten the armrest part with the chiar front part by bolts (Part L) and washers(Part N).
- Page 10 Step 11 • Connect the sofa right armrest part (Part J1) with the sofa back part (Part G) by insert. Fasten them together by bolts (Part M) and washers (Part N). Step 12 • Fasten the sofa front part (Part H) with the right armrest part by bolts (Part L) and...
-
Page 11: Care And Cleaning
Step 14 • Put the sofa seat part (Part I) into the sofa seat. Add the adjusting knob (Part O) to the bottom of the armrest. Step 15 • Put the sofa seat cushion (Part P) on the seat. CARE AND CLEANING: 1. - Page 12 Manchester M60 6ES...
