MINISFORUM MS-A2 Manual

New gen mini workstation series

Advertisement

New Gen Mini Workstation Series
Copyright @ 2024-2025 Micro Computer (HK) Tech Limited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-A2 and is the answer not in the manual?

Questions and answers

Summary of Contents for MINISFORUM MS-A2

  • Page 1 New Gen Mini Workstation Series Copyright @ 2024-2025 Micro Computer (HK) Tech Limited.
  • Page 2: Safety Precautions

    MINISFORUM. 6.In addition to the warranty terms, MINISFORUM is not legally responsible for damage or injury caused directly or indirectly by using this product, especially those caused by failure to operate in accordance with safety guidelines.
  • Page 3: Conventions Used In This Manual

    Conventions Used In This Manual Note:--- This message contains additional instructions for this item. Important!--- This information contains instructions that must be followed. Warning!--- This message contains information about user safety and product safety. Package Contents Ac Power Adapter */ Power Cord */ HDMI®...
  • Page 4 Interface Power Button The power button allows you to turn the Mini PC on /off. You can press the power button to put your Mini PC to sleep mode or press it for 10 seconds to force shutdown your Mini PC. 3.5mm Combo Jack This connector is used to connect audio output signals to a power amplifier or headphones.
  • Page 5 Getting Started With Your Mini PC Connect the display to the Mini PC‘s HDMI® port / TYPE-C port. Connect the keyboard and mouse. Connect the provided power adapter to your Mini PC. Turn on the power and start the Mini PC. If the Mini PC is frozen or slow to respond, To put your Mini PC on Sleep mode, press press and hold the power button at least for...
  • Page 6 Installation Guide While pressing the button, pull out the motherboard case. DIY DDR First remove the radiator, and then insert the memory into the memory slot as shown. DIY PCIE Expansion Card First use a tool to unscrew the positioning clamp screw, press the positioning clamp to take it out, and remove the baffle.
  • Page 7 Insert the expansion card into the motherboard slot in an oblique direction, and insert the expansion card parallel into the PCIE slot with both hands. Note: Only half-height single-slot PCIE expansion cards are supported Warn! The correct way to disassemble the expansion card is as shown in the figure, and be careful not to pinch your hands.
  • Page 8 Turn it over and use tools to remove the heat dissipation bracket. DIY Customized U.2 To M.2 Assemble the U.2 hard drive to the U.2 to custom M.2 adapter card and lock the screws. Insert the U.2 to private M.2 adapter card into the M.2 slot, align it and tighten the fixing screws, and finally connect the power cable.
  • Page 9 DIY SSD Insert the SSD card into the card slot at an angle and secure it with screws. M.2 NVME 2280 SSD Note: To installation 22110 SSD, you need to use a tool to unscrew the hexagonal screw post first. M.2 NVME 22110 SSD Re-tighten the screws of the heat dissipation bracket and install the motherboard case into the chassis.
  • Page 10 FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 11 生产商: 深圳市美高电子设备有限公司 网址: https://www.miniscloud.com 地址: 深圳市龙岗区平湖街道禾花社区富康路6号深业物流平湖 中心厂房B(宝能智创谷B栋)201、206-208、217-222 电话: 0755-84659450 售后技术支持 网址: https://www.minisforum.com/new/support 电话: 400-090-9901 Contact information Manufacturer: Micro Computer (HK) Tech Limited Website: https://www.miniscloud.com Address: FLAT/RM 18, 28/F, Shui On Centre, 6-8 Harbour Road, Waterfront Wan Chai , Hong Kong TEL:...
