MINISFORUM MS-A1 Quick Start Manual

Hide thumbs Also See for MS-A1:

Advertisement

Table of Contents

Copyright @ 2022 Micro Computer (HK) Tech Limited.
Disclaimer And Safety Instructions /
免责声明与安全须知 /
Haftungsausschluss Und Sicherheit-
shinweise /
免責事項と安全上の注意事項 /
Descargo De Responsabilidad E
Instrucciones De Seguridad /
Dichiarazioni E Istruzioni Di
Sicurezza /
Avis De Non-responsabilité Et
Instructions De Sécurité /
User Manual /
用户手册 /
Bedienungsanleitung /
取扱説明書 /
Manual De Usuario /
Manuale D'uso /
Manuel Utilisateur /
MINI PC
English （ 1 ）
中文
（10）
Deutsch（19）
日本語 （28）
español（37）
Italiano （46）
Français（55）
English （ 2 ）
中文
（11）
Deutsch（20）
日本語 （29）
español（38）
Italiano （47）
Français（56）

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MINISFORUM MS-A1

Summary of Contents for MINISFORUM MS-A1

  • Page 1 MINI PC Copyright @ 2022 Micro Computer (HK) Tech Limited. Disclaimer And Safety Instructions / English （ 1 ） 免责声明与安全须知 / 中文 （10） Haftungsausschluss Und Sicherheit- Deutsch（19） shinweise / 免責事項と安全上の注意事項 / 日本語 （28） Descargo De Responsabilidad E español（37） Instrucciones De Seguridad / Dichiarazioni E Istruzioni Di Italiano （46）...

  • Page 2: Safety Precautions

    DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF MINISFORUM HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

  • Page 3: Conventions Used In This Manual

    Maintenance Guideline Do not step on the power cord or put anything on your Mini PC. Do not spill water or any other liquid over this product. There's still some current passing through even when the system is off. To avoid severe damage caused by possible electric shock, plug out all power cables from sockets temporarily before cleaning or moving this product.

  • Page 4: Getting To Know Your Mini Pc

    Getting To Know Your Mini PC Reset Hole Power Button 3.5mm Combo Jack USB2.0 Port USB3.2 Port Air Vent Power Input OCulink Port RJ-45 LAN Port USB2.0 Port DisplayPort USB3.0 Gen2 Port Type-C Port HDMI™ Port Interface Power Button The power button allows you to turn the Mini PC on /off. You can press the power button to put your Mini PC to sleep mode or press it for 10 seconds to force shutdown your Mini PC.
  • Page 5 RJ-45 LAN Port This RJ-45 network interface supports standard Ethernet cables and can be connected to a local area network. (Transmission speed 2.5Gbps) DisplayPort This DisplayPort supports 8K@60Hz/4K@240Hz display output. It can transmit digital audio information while transmitting video signals. HDMI™...
  • Page 6 Getting Started With Your Mini PC Connect the display to the Mini PC‘s HDMI™ port、DP port or Type-C port. Connect the keyboard and mouse. Connect the provided power adapter to your Mini PC. Turn on the power and start the Mini PC. If the Mini PC is frozen or slow to respond, To put your Mini PC on Sleep mode, press the press and hold the power button at least for...
  • Page 7 Installation Guide Remove the two screws from the bottom cover using the tool, then use the included tool to pull out the motherboard slot at the position shown in the diagram. Warning: Only use the clip at the position shown in the diagram. DIY CPU First remove the screws from the back of the motherboard's CPU cooling assembly, then remove the screws from the front of the motherboard's cooling module and remove the...
  • Page 8 Reinstall the cooling module onto the motherboard, securing the screws of the cooling module on the front of the motherboard to the screws of the CPU cooling assembly on the back. DIY Customized U.2 To M.2 Assemble the U.2 hard drive to the U.2 to custom M.2 adapter card and lock the screws. Insert the U.2-to-private-M.2 adapter card into the M.2 slot and align it with the positioning post.
  • Page 9 DIY SSD Use the tool to remove the SSD cooling module from both sides. Align the SSD card with the slot notch and insert it at an angle, then secure it with a screw. The SSD on the CPU side does not require a locking screw. M.2 NVME 2280 SSD Front Side (CPU side) Back Side...
  • Page 10 FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
