Magicshine SEEMEE R300 User Manual

Hide thumbs

Advertisement

Table of Contents

EN
SEEMEE R300
USER MANUAL
IN THE BOX
USB-C
charging cable
MJ-6556
Saddle mount
SEEMEE R300
Seat post mount
(sold separately)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEEMEE R300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Magicshine SEEMEE R300

Summary of Contents for Magicshine SEEMEE R300

  • Page 1 SEEMEE R300 USER MANUAL IN THE BOX USB-C charging cable MJ-6556 Saddle mount SEEMEE R300 Seat post mount (sold separately)

  • Page 2: Start Guide

    2. DO NOT disassemble, modify, remanufacture, puncture, or damage the device or batteries. 3. The SEEMEE R300 radar taillight does not replace cyclist attentiveness and good judgment. Always operate the bicycle in a safe manner. Failure to do so could result in severe injury or death.
  • Page 3 Note: Place your bike computer and taillight within 3 meters. Keep 10 meters away from other ANT+ sensors when pairing. 1. Turn on SEEMEE R300 and activate its radar function. 2. Turn on your bike computer, go to Menu>Sen- sors>Add Sensors> Radar>Search All.

  • Page 4: Memory Function

    With a connected bike computer, enter "Light Mode" and select the corresponding brightness level. Or customize the taillight lighting mode on a compatible computer, e.g., automatically adjust the lighting mode and brightness according to ambient light. MEMORY FUNCTION: When the taillight is turned on again, it will automatically turn to the last selected lighting mode.
  • Page 5 OUTPUT / RUNTIME RADAR RADAR LUMENS 15LM 14.5h 32.7h HIGH 50LM 19.5h NIGHT FLASH 10-50LM 11.9h 26.5h DAY FLASH 38.4h 0-100LM 16.2h ECO FLASH 100h 0-3-3-10LM GROUP RIDE MODE 20.1h ONLY RADAR MODE 26.3h *The taillight modes are subject to the identification display of the bike computer's Light Mode control interface.
  • Page 6 Low mode and stay within 10 meters, the taillight automatically switches to Group Ride mode. PELOTONSYNC FLASH MODE: When two or more SEEMEE R300 taillights come close and flash in the same pattern, they automatically switch to PelotonSync Flash mode. Click the button to exit PelotonSync Flash mode and switch to other modes.

  • Page 7: Battery Indicator

    CHARGING / BATTERY INDICATOR When the taillight is off, click the power button to display the remaining battery level for 3 seconds. Charging: Flashing red Fully charged: Constant green for 2 minutes Standard charging time approx. 2.15 hours (5V 2A) BATTERY INDICATOR 100%-40%: Constant green 39%-11%: Constant red...

  • Page 8: How To Install

    HOW TO INSTALL 1. INSTALL ON SEAT POST 2. INSTALL UNDER SADDLE (OPTIONAL)
  • Page 9 90°...

  • Page 10: Fcc Statement

    FCC STATEMENT Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
