Current GlowCraft LED Controller Reference Manual

1. Features:

● 5V to 24V Power Supply Input Range
○ 12V Automotive Optimized
○ Auto-Shutdown
○ Ultra low power in sleep mode
● 2 Internal 5V Power Supply Outputs
○ Up to 4A per Output
● 8 Voltage Input Triggers
○ Assign functions in software
● Up to 6 LED Output Data Channels
○ Control up to 6 Separate LED
strings. ~1000 LEDs / Channel
● Audio Line-Level Input
○ LEDs triggered from music
● Compatible with many addressable LED
standards
○ WS2811/WS2812/WS2813, etc
○ SPI RGB
● External Connectivity
○ WIFI
○ CANBus
● 2 Differential Data Range Extender
○ RS-422 (DMX)
● Automotive Rated Components
● Compact Robust Enclosure:
○ Water-Resistant IP67 Rated
○ 5.26" x 4.58" x 1.43"
● Designed, Assembled & Tested in USA

3. Description:

The GlowCraft LED controller by Current Electric Labs is a versatile and powerful device
for creating stunning addressable LED creations.
GlowCraft is a compact and robust device that can natively control up to about 6000
addressable LED pixels. With 6 separate data output channels, your system can mix and match
any of the popular standards, such as WS2811/WS2812/WS2813/etc. The 8 user assignable
5-24V input channels can be used to interface with standard automotive triggers like Brake,
Turn Signal, Reverse, etc or buttons and switches for real time interactive functionality. Trigger
functionality can be extended by using the built-in CANBus interface.
The GlowCraft controller uses automotive standard DTM connectors and has a wide
input voltage range of 5V to 24V, making it suitable for various power sources, specifically
(R2) Current Electric Labs
GlowCraft LED Controller - Reference Manual

2. Applications:

● Automotive Lighting
● Outdoor LED Displays
● Multi-Channel Interactive Art Installation
