Current Lumination LCA Series Installation Manual

Controller box

Advertisement

Quick Links

Controls Accessory
(LCA Series, Controller Box)
BEFORE YOU BEGIN
Read these instructions completely and carefully.
Save these instructions for future use.
RISK OF FIRE OR ELECTRICAL SHOCK
• Turn power off before inspection, installation or removal.
• Properly ground electrical enclosure.
• Follow all NEC and local codes.
• Do not make or alter any open holes in an enclosure of wiring or
electrical components during kit installation.
• Fixture may fall down if not installed properly,
follow installation instructions.
• Wear safety glasses and proper aid during installation and maintenance.
• Luminaire wiring and electrical parts may be damaged when drillingfor
installation of LED retrofit it. Check for enclosed wiring and components.
Install this kit only in the luminaires that has the construction features
and dimensions shown in the photographs and/or drawings.
• Above ceiling access required.
Save These Instructions
These instructions do not purport to cover all details or variations in components nor to provide for every possible contingency to be
met in connection with installation, operation or maintenance. Should further information be desired or should particular problem arise
which are not covered sufficiently for the puchaser's purpose, the matter should be referred to Current. Current does not claim liability
for any installation not performed according to this guide or not performed by a qualified electrician.
Prepare Electrical Wiring
Electrical Requirements
• The LCA Controller Box must be supplied with
120V/277V, 50/60Hz, for LCAMBXXXXFM.
Grounding Instructions
• The grounding and bonding of the overall system shall
be done in accordance with National Electric Code (NEC)
Article 600 and local codes.
WARNING / AVERTISSEMENT
LED.com
© 2023 Current Lighting Solutions, LLC. All rights reserved. Information and specifications subject to change
without notice. All values are design or typical values when measured under laboratory conditions.
RISQUES D'INCENDIE OU DE DÉCHARGES ÉLECTRIQUES
• Coupez l'alimentation avant d'inspecter, installer ou déplacer le luminaire.
• Assurez-vous de correctement mettre à la terre le boîtier d'alimentation électrique.
• Respectez tous les codes NEC et codes locaux.
• Ne pas percer ou altérer les trous d'un boitier contenant fil ou composanélectrique
durant l'installation.
• Le luminaire peut tomber s'il nest pas installé correctement, suivre les instructions
d'installation.
• Porter des lunettes de sécurité et les aides appropriées lors de l'installation et de
l'entretien.
• Câblage du luminaire et pièces électriques peuvent être endommagés lors du fraisage
pour l'installation du kit de conversion à DEL. Vérifier le câblage et lecomposants clos.
• Installez ce kit uniquement dans les appareils d'éclairage qui a les caractéristiques de
la construction et les dimensions indiquées dans les photographies et/ou dessins.
• Accès requis au-dessus du plafond.
Installation Guide
(Rev 05/17/23)
IND273-Lumination-Controller-Box-Accessory-Installation-Guide
Page 1 of 9
