- Page 1 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 File: CANALUMODF150 Page 1 of 14 04/09/2024...
-
Page 2: Parts List
Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 Parts List Part Description Image Roof Panel Carton 1 Front Panel Left Side Panel Right Side Panel Carton 2 Rear Door File: CANALUMODF150 Page 2 of 14 04/09/2024... - Page 3 Middle Clamp Assembly Rear Clamp Assembly Left Water Channel Right Water Channel M8 x 20 Hex Bolt Kit 3 M8 Spring Washer M8 Flat Washer 6 x 3/8” Flat Head Self Taping Screw Front Rubber File: CANALUMODF150 Page 3 of 14 04/09/2024...
-
Page 4: Tools Required For Installation
• Check all parts are included per parts list Tools Required for Installation Box Cutter 5mm Allen Key Phillips Head 13mm 12mm 10mm Screwdriver Canopy Assembly 1. Assemble Rear Door to Roof Panel File: CANALUMODF150 Page 4 of 14 04/09/2024... - Page 5 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 Rear Door Brackets File: CANALUMODF150 Page 5 of 14 04/09/2024...
- Page 6 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 2. Assemble Side Panel Note: Lift up rear door before sliding the side panel into side roof frame File: CANALUMODF150 Page 6 of 14 04/09/2024...
- Page 7 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 3. Assemble Front Panel Front Panel Brackets Note: Pre-assemble fasteners by hand then tighten by tool 5mm Allen Key 10mm File: CANALUMODF150 Page 7 of 14 04/09/2024...
- Page 8 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 4. Connect electric wiring Front Rear File: CANALUMODF150 Page 8 of 14 04/09/2024...
- Page 9 Vehicle: Ford F-150 Part No. CANALUMODF150 5. Securing Side Panel to Roof Front Corner Cover LH-RH Note: Pre-assemble fasteners by hand then tighten by tool Rear Corner Cover LH-RH 13mm Connect Brake Light File: CANALUMODF150 Page 9 of 14 04/09/2024...
- Page 10 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 6. Assemble Water Channel Water Channel Note: Pre-assemble fasteners by hand then tighten by tool 12mm 10mm File: CANALUMODF150 Page 10 of 14 04/09/2024...
- Page 11 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 7. Attach Front Corner Cover LH-RH Clean surface before applying tape glue 8. Attach Rear Corner Cover Clean surface before applying tape glue File: CANALUMODF150 Page 11 of 14 04/09/2024...
- Page 12 To prevent damage to the D-rubber during installation, it is important that the canopy is lifted & lowered in place. Do not drag the canopy across the vehicles tub rail. • Once the canopy is centered, install clamps. • File: CANALUMODF150 Page 12 of 14 04/09/2024...
- Page 13 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 10. Installing Gas Struts File: CANALUMODF150 Page 13 of 14 04/09/2024...
- Page 14 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford F-150 Part No. CANALUMODF150 11. Connecting Plug & Play Harness Plug & Play Harness File: CANALUMODF150 Page 14 of 14 04/09/2024...
