- Page 1 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC File: CANALUMODRPD22EC Page 1 of 14 04/09/2024...
-
Page 2: Parts List
Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC Parts List Part Description Image Roof Panel Carton 1 Front Panel Left Side Panel Right Side Panel Carton 2 Rear Door File: CANALUMODRPD22EC Page 2 of 14 04/09/2024... - Page 3 Nut Head Cover Left Water Channel Right Water Channel M8 x 20 Hex Bolt Kit 3 M8 Spring Washer M8 Flat Washer 6 x 3/8” Flat Head Self Taping Screw Front Rubber Plug and Play File: CANALUMODRPD22EC Page 3 of 14 04/09/2024...
-
Page 4: Tools Required For Installation
• Recommend using Silicone over the corner rubber caps to ensure canopy is fully waterproof • Tools Required for Installation Box Cutter 5mm Allen Key Phillips Head 13mm 12mm 10mm Screwdriver 10mm 12mm 13mm Torque Wrench File: CANALUMODRPD22EC Page 4 of 14 04/09/2024... - Page 5 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC Canopy Assembly 1. Assemble Rear Door to Roof Panel Rear Door Brackets File: CANALUMODRPD22EC Page 5 of 14 04/09/2024...
- Page 6 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC File: CANALUMODRPD22EC Page 6 of 14 04/09/2024...
- Page 7 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC 2. Assemble Side Panel Note: Lift up rear door before sliding the side panel into side roof frame File: CANALUMODRPD22EC Page 7 of 14 04/09/2024...
- Page 8 Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC 3. Assemble Front Panel Front Panel Brackets Note: Pre-assemble fasteners by hand then tighten by tool 5mm Allen Key 10mm File: CANALUMODRPD22EC Page 8 of 14 04/09/2024...
- Page 9 Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC 4. Securing Side Panel to Roof Note: Pre-assemble fasteners by hand then tighten by tool 13mm Rear Corner Cover Connect Brake Light File: CANALUMODRPD22EC Page 9 of 14 04/09/2024...
- Page 10 Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC 5. Assemble Rear Water Channel Water Channel Note: Pre-assemble fasteners by hand then tighten by tool Note: Pre-assemble fasteners by hand then tighten by tool 12mm 10mm File: CANALUMODRPD22EC Page 10 of 14 04/09/2024...
- Page 11 Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC 6. Attach Front Corner Cover LH-RH Clean surface before applying tape glue 7. Attach Rear Corner Cover LH-RH Clean surface before applying tape glue File: CANALUMODRPD22EC Page 11 of 14 04/09/2024...
- Page 12 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC 8. Install Bracket to Truck Bed 9. Attach front rubber pad on the front panel bed File: CANALUMODRPD22EC Page 12 of 14 04/09/2024...
-
Page 13: Canopy Installation
To prevent damage to the D-rubber during installation, it is important that the canopy is lifted & lowered in place. Do not drag the canopy across the vehicles tub rail. • Once the canopy is centered, install clamps. File: CANALUMODRPD22EC Page 13 of 14 04/09/2024... - Page 14 Assembly & Installation Guide Product: Aluminium Canopy Vehicle: Ford Ranger 2022+ (Next Gen) Extra Cab Part No. CANALUMODRPD22EC 11. Install Gas Struts Connecting Plug & Play Harness File: CANALUMODRPD22EC Page 14 of 14 04/09/2024...
